2023 HIGHLIGHTS PRODUCT CATALOG WWW.BTECHAVMOUNTS.COM B-TECH AV MOUNTS PROFESSIONAL AUDIO VISUAL MOUNTING SOLUTIONS EST. 1972
B-TECH AV MOUNTS 2 WELCOME TO THE NEW 2023 B-TECH AV MOUNTS HIGHLIGHTS CATALOG B-Tech AV Mounts LLC launched in the US in 2018 and has rapidly become one of B-Tech's fastest growingmarkets. B-Tech AV Mounts LLC is located in Brea, California withafullystocked warehouse based in Santa Fe Springs CA. and handles sales, distribution, marketing and product development for the North American market. Alongside our sales representatives who sell the B-Tech product range throughout the country, there is our exclusive distribution partners Exertis Almo for North America and Exertis Pro AV Canada for Canada. Screens and other AV equipment are such integral parts of the world around us that almost all vertical markets need quality mounting solutions. B-Tech's award winning professional products can be found installed across the globe in all types of public and commercial environments, including retail, broadcast, control rooms, corporate, education, exhibitions & conferences, health care, hospitality & leisure, museums & information centers, rental & stage, sporting arenas & transport hubs. B-TECH NORTH AMERICA WELCOME TO THE 2023 HIGHL IGHTS CATALOG All products throughout the catalog feature QR codes that you can scan to visit the product's dedicated web page. There, you can find the full product specification and list of features, product images, assembly manuals and the full product specification sheets. QR CODES B-TECH AV MOUNTS LLC +1 888 792 8188 AMERICAS@BTECHAVMOUNTS.COM B-TECH AV MOUNTS PROUD MEMBERS OF:
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 3 Our full line catalog contains over 150 pages of mounting solutions for any application view online at WWW.BTECHAVMOUNTS.COM One of the most extensive ranges of mounting solutions within the industry Multiple options to suit a range of price points 1000s of possible solutions using product from our stocked, modular component systems Most wall mounts combine with our component systems, meaning we can often fulfill bespoke requirements from stock PRODUCT RANGE We are able to produce complex quotes, such as for dvLED installations with an ultra-fast turnaround Dedicated technical support team to answer technical questions Same-day dispatch from most B-Tech locations Our dedicated inside sales team has over 20 years combined experience in AV mounting From our global network of offices we offer sales & technical support in a number of different languages We are the only true global mounting company, with B-Tech facilities consisting of sales offices & stocked warehouses in all key territories Products are technically well designed & incredibly robust Tested to TUV & UL standards to give users confidence of their reliability All of our products are designed by our in-house engineering team to ensure the highest quality & innovation We have vast experience in the AV industry, celebrating our 50th anniversary in 2022 Global partnerships with display technology manufacturers Winner of the highly acclaimed Manufacturer of the Year Award at the AV Awards Winner in the Best AV Accessory category at the InAVation Awards for our Curved dvLED Mounting System WHY CHOOSE B-TECH? CONTENTS Welcome to the B-Tech AV Mounts Highlights Catalog Pg. 2 Contents Pg. 3 Why Choose B-Tech? Pg. 3 COMPLETE MOUNTING SOLUTIONS QUICK REFERENCE GUIDES Pg. 4-11 Menu Board Mounting Systems Pg. 12-13 Videowall Mounting Systems Pg. 14-19 Modular Videowall Mounts Pg. 20-21 dvLED Mounting Solutions Pg. 22-23 Digital Signage Mounts Pg. 24-25 Flat Screen Wall & Ceiling Mounts Pg. 26-27 Desk Mounts Pg. 28-29 Carts & Floor Stands Pg. 30-31 Unified Communications & Video Conferencing Pg. 32-33 AV Storage Mounts Pg. 34 Speaker Mounts Pg. 35 Projector Mounts Pg. 36-37 COMPONENTS RANGE OVERVIEW & MOUNTING GUIDES Pg. 38-48 CONTENTS SALES SUPPORT LOCAL SERVICE ON A GLOBAL SCALE MANUFACTURING HERITAGE
B-TECH AV MOUNTS 4 MODULAR VIDEOWALL MOUNTS POP-OUT SYSTEM X MENU BOARD MOUNTS WALL MOUNTED CEILING MOUNTED BT8330 Max screen size: 75" Max load: 110lbs per screen F its universal patterns: up to VESA 900 (Vertical fixing) BT8331 Max screen size: 75" Max load: 110lbs per screen Fits universal patterns: up to VESA 900 (Vertical fixing) BT8332 Max screen size: 75" Max load: 110lbs per screen Fits universal patterns: up to VESA 900 (Vertical fixing) BT8333 Max screen size: 75" Max load: 110lbs per screen Fits universal patterns: up to VESA 900 (Vertical fixing) MULTI-SCREEN & DIGITAL SIGNAGE MOUNTS BT8312 Max screen size: 75" Max load: 110lbs Fits VESA® patterns: 200x100 to 600x400 Distance from wall: 2.7" - 8.8" BT8309 Max screen size: 42" Max load: 55lbs Fits VESA® patterns: 75x75 up to 200x200 Distance from wall: 2.9" - 7.5" BT8310XL Max screen size: 120" Max load: 275lbs Fits VESA® patterns: 200x100 to 600x400 Distance from wall: 4" - 11.5" DIGITAL SIGNAGE WALL MOUNTED ROTATION BT7550 Max screen size: 65" Max load: 154lbs Fits VESA® patterns: up to 400x400 Screen rotation: 90° PORTRAIT COLUMN/PILLAR BT8322 Max screen size: 65" Max load: 176lbs Fits universal patterns: up to 600x400mm Distance from wall: 1.4" BT7832 Max load: 110lbs Adjustable width: 5.5" - 29.5" COMPLETE MOUNT ING SOLUT IONS XXL SLIMLINE POP-OUT CURVED SYSTEM X VIDEOWALL MOUNTS WALL MOUNTED CEILING MOUNTED BT8340 Max screen size: 75" Max load: 110lbs per screen Fits universal patterns: VESA 900 BT8341 Max screen size: 705" Max load: 110lbs per screen Fits universal patterns: VESA 900 BT8342 Max screen size: 75" Max load: 110lbs per screen Fits universal patterns: VESA 900 BT8343 Max screen size: 75" Max load: 110lbs per screen Fits universal patterns: VESA 900 (Vertical fixing) POP-OUT CURVED
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 5 DIRECT VIEW LED MOUNTS WALL MOUNTED FREESTANDING MOBILE BOLT DOWN SYSTEM X CURVED VIDEOWALL MOUNTS FREESTANDING MOBILE BOLT DOWN SYSTEM X VIDEOWALL FLOOR STANDS FREESTANDING MOBILE BOLT DOWN BT8371 Max screen size: 75" Max load: 110lbs per screen Fits universal patterns: VESA 900 (Vertical fixing) BT8372 Max screen size: 75" Max load: 110lbs per screen Fits universal patterns: VESA 900 (Vertical fixing) BT9340-FM Front mounted BT9340-RM Rear mounted BT9370-FM Front mounted BT9370-RM Rear mounted BT9371-FM Front mounted BT9371-RM Rear mounted BT9372-FM Front mounted BT9372-RM Rear mounted BT8373 Max screen size: 75" Max load: 110lbs per screen Fits universal patterns: VESA 900 (Vertical fixing) BT8376 Max screen size: 75" Max load: 110lbs per screen Fits universal patterns: VESA 900 (Vertical fixing) BT8374 Max screen size: 75" Max load: 110lbs per screen Fits universal patterns: VESA 900 (Vertical fixing) This reference guide gives a quick overview of the B-Tech range of Multi-Screen Videowall Mounts. Products with a page number are featured in this mini catalog. For all other products, please visit www.btechavmounts.com for full specifications. BT8375 Max screen size: 75" Max load: 110lbs per screen Fits universal patterns: VESA 900 (Vertical fixing) BT8370 Max screen size: 75" Max load: 110lbs per screen Fits universal patterns: VESA 900 (Vertical fixing) COMPLETE MOUNT ING SOLUT IONS The configuration icon means this product can be configured to your requirements using the online configuration tool at www.btechavmounts.com/systemx-configurator SCREEN SPECIFIC MOUNTS LG LAA015F LG LAEB015 SAMSUNG IAB 110" SAMSUNG IAB 146" BT9340-LAA015F BT9370-LAA015F BT9371-LAA015F BT9372-LAA015F Wall Mounted Mobile Stand Bolt Down Stand Floor Stand LAA015F 130" ALL-IN-ONE DVLED SCREEN LAEB015 136" ALL-IN-ONE DVLED SCREEN IAB 110" SERIES ALL-IN-ONE MODULAR TV IAB 146" SERIES ALL-IN-ONE MODULAR TV Mobile Stand Bolt Down Stand Floor Stand BT83LAEB015-S BT83LAEBO15-M BT83LAEB015-B Floor Stand BT9370-SAM110 Floor Stand BT9370-SAM146 *To be used with Samsung provided brackets *To be used with Samsung provided brackets
B-TECH AV MOUNTS 6 SYSTEM X FLOOR STANDS FREESTANDING TWIN SCREEN VIDEOCONFERENCING FLOOR-TO-WALL BOLT-DOWN FREESTANDING MODE-AL FLOOR STANDS FLOOR-TO-WALL FLOOR-TO-CEILING BOLT-DOWN PREMIUM CARTS MOBILE FLAT SCREEN FLOOR STANDS FLIP ROTATION BT8562 Max screen size: 75" Max load: 154lbs Fits VESA® patterns: up to 600x400 Dimensions: H:74" W:40.5" D:30.2" BT8564 Max screen size: 65" - 120" Max load: 285lbs Fits VESA® patterns: up to 1000x600 Dimensions: H:75" W:48.5" D:30.2" BT8566 Max screen size: 75" Max load: 154lbs Screen rotation: 90° Fits VESA® patterns: up to 600x400 Dimensions: H:76" W:42.3" D:34" BT8700 Max screen size: 75" Max load: 154lbs Fits VESA® patterns: up to 600x400 Dimensions: H:54" W:27.7" D:6.5" BT8701 Max screen size: 75" Max load: 154lbs Fits VESA® patterns: up to 600x400 Dimensions: H:77.5" W:27.7" D:6.5" BT8702 Max screen size: 75" Max load: 154lbs Fits VESA® patterns: up to 600x400 Dimensions: H:80.7-106.3" W:27.7" D:8.3" BT8703 Max screen size: 75" Max load: 154lbs Fits VESA® patterns: up to 600x400 Dimensions: H:51.5" W:27.7" D:8.3" BT8704 Max screen size: 75" Max load: 154lbs Fits VESA® patterns: up to 600x400 Dimensions: H:75.2" W:27.7" D:8.3" XL PORTRAIT BTF840 Max screen size: 39" - 75" Max load: 155lbs Fits VESA® patterns: up to 600x400 Dimensions: H:72.5" W:35" D:23.8" BTF843 Max screen size: 65" - 85" Max load: 155lbs Fits VESA® patterns: up to 800x600 Dimensions: H:72.5" W:35" D:23.8" TALL TALL DUAL STACK LANDSCAPE DUAL STACK PORTRAIT BTF842 Max screen size: 47" - 65" Max load: 77lbs per screen Fits VESA® patterns: up to 600x400 Dimensions: H:96" W:35" D:23.8" BTF841 Max screen size: 32" - 65" Max load: 77lbs per screen Fits VESA® patterns: up to 600x400 Dimensions: H:72.5" W:35" D:23.8" BT8710 Max screen size: 46" - 65" Max load: 155lbs per screen Fits VESA® patterns: up to 600x400 Dimensions: H:77.5" W:78.7" D:6.5" BT8711 Max screen size: 46" - 65" Max load: 155lbs per screen Fits VESA® patterns: up to 600x400 Dimensions: H:75.2" W:78.7" D:8.3" BT8712 Max screen size: 46" - 65" Max load: 123lbs per screen Fits VESA® patterns: up to 600x400 Dimensions: H:76.5" W:78.7" D:29.6" VC SHELF VC SHELF VC SHELF XXL BT8590 Max screen size: 72" - 120" Max load: 286lbs Fits VESA® patterns: up to 1600x800mm Dimensions: H:75" W:69" D:30.2" VC SHELF BTF845 Max screen size: 47" - 55" Max load: 55lbs per screen Fits VESA® patterns: up to 600x400 Dimensions: H:72.5" W:69" D:23.8" COMPLETE MOUNT ING SOLUT IONS XXL
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 7 FLOOR STANDS FREESTANDING FREESTANDING FLOOR-TO-WALL BOLT-DOWN CARTS MOBILE XXL XXL XXL BT8705 Max screen size: 75" Max load: 154lbs Fits VESA® patterns: up to 600x400 Dimensions: H:52.8" W:26.5" D:29.6" BT8706 Max screen size: 75" Max load: 154lbs Fits VESA® patterns: up to 600x400 Dimensions: H:76.5" W:26.5" D:29.6" BT8709 Max screen size: 65" - 100" Max load: 220lbs Fits VESA® patterns: up to 900x800 Dimensions: H:76.5" W:44.4" D:29.6" BT8708 Max screen size: 65" - 100" Max load: 310lbs Fits VESA® patterns: up to 900x800 Dimensions: H:75.2" W:39.4" D:8.3" BT8504 Max screen size: 75" Max load: 154lbs Fits VESA® patterns: up to 600x400 Dimensions: H:73" W:43.2" D:29" BT8503 Max screen size: 60" Max load: 110lbs Fits VESA® patterns: up to 800x600 Dimensions: H:76.4" W:44" D:30.8" BT8506 Max screen size: 65" - 120" Max load: 285lbs Fits VESA® patterns: up to 1000x600 Dimensions: H:65" W:65.3" D:32" BT8707 Max screen size: 65" - 100" Max load: 440lbs Fits VESA® patterns: up to 900x800 Dimensions: H:77.5" W:39.4" D:6.5" BT8572 Max screen size: 55" Max load: 88lbs Fits VESA patterns: up to 600x400 Dimensions: H:72" W:31.5" D:23.6" BT8571 Max screen size: 47" Max load: 55lbs Fits VESA patterns: up to 200x200 Dimensions: H:72" W:27.5" D:20.3" TALL BT8582 Max screen size: 55" Max load: 88lbs Fits VESA patterns: up to 600x400 Dimensions: H:72.6" W:31.5" D:23.6" BT8583 Max screen size: 75" Max load: 154lbs Fits VESA patterns: up to 600x400 Dimensions: H:72.6" W:31.5" D:23.6" BT8581 Max screen size: 47" Max load: 77lbs Fits VESA patterns: up to 200x200 Dimensions: H:72.6" W:27.5" D:20.3" BT8573 Max screen size: 75" Max load: 154lbs Fits VESA patterns: up to 600x400 Dimensions: H:72" W:31.5" D:23.6" This reference guide gives a quick overview of the B-Tech range of Flat Screen Floor Stands. Products with a page number are featured in this mini catalog. For all other products, please visit our website at www.btechavmounts.com for full specifications. Note, max screen sizes are recommendations only and it may be possible to mount other sizes, please refer to the screen's weight and mounting pattern to find the best compatible mount. XXL MOBILE WALL VC SHELF VC SHELF VC SHELF VC SHELF VC SHELF BT8517 Max screen size: 65" - 75" Max load: 220lbs per screen Fits universal patterns: up to 1200x800mm Dimensions: H:78.75" W:96.5" D:37.4" BT8415 Max screen size: 39" - 46" Max load: 154lbs per screen F its universal patterns: up to 400x400mm Distance from wall: 2.4" BT8416 Max screen size: 46" - 65" Max load: 154lbs per screen F its universal patterns: up to 600x400mm Distance from wall: 2.4" BT8514 Max screen size: 39" - 46" Max load: 88lbs per screen Fits VESA® patterns: up to 400x400 Dimensions: H:75" W:59.2" D:34" BT8516 Max screen size: 46" - 65" Max load: 154lbs per screen Fits VESA® patterns: up to 600x400 Dimensions: H:75" W:78.9" D:39" COMPLETE MOUNT ING SOLUT IONS XXL
B-TECH AV MOUNTS 8 XX-LARGE FIXED TILT SMALL FIXED TILT TILT & SWIVEL SINGLE ARM X-LARGE FIXED LARGE FIXED MEDIUM FIXED TILT BT8421 Max screen size: 55" Max load: 77lbs Fits VESA® patterns: up to 400x400 Distance from wall: 1.2" BT8441 Max screen size: 55" Max load: 176lbs Fits VESA® patterns: up to 400x400 Distance from wall: 1.2" BTV510 Max screen size: 55" Max load: 110lbs Fits VESA® patterns: up to 400x400 Distance from wall: 0.8" BT7510 Max screen size: 28" Max load: 44lbs Fits VESA® patterns: 50x50, 75x75 & 100x100 Distance from wall: 0.59" BT7511 Max screen size: 28" Max load: 44lbs Fits VESA® patterns: 75x75 & 100x100 Tilt: +17/-10° BT7518 Max screen size: 28" Max load: 44lbs Fits VESA® patterns: 75x75 & 100x100 Tilt: +17/-10° Swivel: 50° Screen rotation: 360° BT8422 Max screen size: 80" Max load: 154lbs Fits VESA® patterns: up to 800x500 Distance from wall: 1.2" BT8442 Max screen size: 80" Max load: 176lbs Fits VESA® patterns: up to 600x400 Distance from wall: 1.2" BTV520 Max screen size: 65" Max load: 154lbs Fits VESA® patterns: up to 800x500 Distance from wall: 0.8" BT8200 Max screen size: 47" Max load: 88lbs Fits VESA® patterns: up to 200x200 Distance from wall: 0.5" BTV500 Max screen size: 47" Max load: 88lbs Fits VESA® patterns: up to 200x200 Distance from wall: 0.8" BT7523 Max screen size: 47" Max load: 55lbs Fits VESA® patterns: up to 200x200 Tilt: +/-15° BT7512 Max screen size: 28" Max load: 33lbs Fits VESA® patterns: 75x75 & 100x100 Tilt: +17/-10° Swivel: 180° Screen rotation: 360° Distance from wall: 3" - 11" BT9901 Max screen size: 65" - 100" Max load: 220lbs Fits VESA® patterns: up to 900x600 Distance from wall: 1.2" BT9903 Max screen size: 65" - 120" Max load: 440lbs Fits VESA® patterns: up to 1000x600 Distance from wall: 1.4" BT9910 Max screen size: 65" - 100" Max load: 285lbs Fits VESA® patterns: up to1000x600 Tilt: +15° FLAT SCREEN WALL MOUNTS COMPLETE MOUNT ING SOLUT IONS BT7532 Max screen size: 47" Max load: 88lbs Fits VESA® patterns: up to 200x200 Distance from wall: 0.6"
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 9 TILT DOUBLE ARM SINGLE ARM DOUBLE ARM DOUBLE ARM BT7514 Max screen size: 47" Max load: 55lbs Fits VESA® patterns: up to 200x200 Tilt: +/-40° Swivel: 180° Distance from wall: 3.75" - 13.25" BT7515 Max screen size: 47" Max load: 55lbs Fits VESA® patterns: up to 200x200 Tilt: +/-40° Swivel: 180° Distance from wall: 3.75" - 20.5" BTV504 Max screen size: 47" Max load: 55lbs Fits VESA® patterns: up to 200x200 Tilt: +/-15° Swivel: 180° Screen rotation: 360° Distance from wall: 3" - 15" BT7513 Max screen size: 28" Max load: 33lbs Fits VESA® patterns: 75x75 & 100x100 Tilt: +17/-10° Swivel: 180° Screen rotation: 360° Distance from wall: 3.75" - 18.5" BT8431 Max screen size: 55" Max load: 110lbs Fits VESA® patterns: up to 400x400 Tilt: +/-15° BTV513 Max screen size: 55" Max load: 77lbs Fits VESA® patterns: up to 400x400 Tilt: +10/-2° Swivel: 180° Distance from wall: 1.6" - 17.7" This reference guide gives a quick overview of the B-Tech range of Flat Screen Wall Mounts. To view the complete range, full specifications, product photos and technical drawings, please visit our website at www.btechavmounts.com. Note, max screen sizes are recommendations only and it may be possible to mount other sizes, please refer to the screen's weight and mounting pattern to find the best compatible mount. TILT DOUBLE ARM BT8432 Max screen size: 80" Max load: 154lbs Fits VESA® patterns: up to 600x400 Tilt: +/-15° XX-LARGE DOUBLE ARM FIXED POP-OUT BT9920 Max screen size: 72" - 120" Max load: 440lbs Fits universal patterns: up to 1600x800mm Distance from wall: 2" BT9921 Max screen size: 72" - 120" Max load: 176lbs Fits universal patterns: up to 1600x800mm Distance from wall: 4.5" - 10.6" BT8228 Max screen size: 65" - 120" Max load: 275lbs Fits VESA® patterns: up to 800x600mm Tilt: +15/-3 ° Swivel: 130° Distance from wall: 3.5" - 24.75" POP-OUT BT8226 Max screen size: 65" Max load: 77lbs Fits VESA® patterns: up to 600x400mm Tilt: +14°/-3° Swivel: 180° Distance from wall: 2" - 22.6" BT8237 Max screen size: 75" Max load: 176lbs Fits VESA® patterns: up to 600x400mm Swivel: 120° Distance from wall: 3" - 27.5" COMPLETE MOUNT ING SOLUT IONS MEDICAL MOUNTS WALL BT7592 Max screen size: 28" Max load: 7-11lbs Fits VESA® patterns: 75x75 & 100x100 BT7593 Max screen size: 28" Max load: 11-18lbs Fits VESA® patterns: 75x75 & 100x100 VESA ADAPTERS FIXED BT7540 Fits VESA® patterns: 300x200 & 400x200 BT7542 Fits VESA® patterns: 200x100 & 200x200 BT7564 Fits VESA® pattern: 600x400 BT7565 Fits VESA® pattern: 800x400 BT7566 Fits VESA® pattern: 900x400 BT7502 Fits VESA® patterns: 200x100 & 200x200
B-TECH AV MOUNTS 10 PROJECTOR MOUNTS CEILING DESK MOUNTS DESKTOP CEILING MOUNTS CEILING BT7553 Max screen size: 32" Max load: 50lbs Fits VESA® patterns: 75x75 & 100x100 Tilt: +90°/-15° Swivel / Screen Rotation: 360° BT8424 Max screen size: 65" Max load: 110lbs Fits universal patterns: up to 600x400mm Tilt: +/-15° BT8426 Max screen size: 65" Max load: 110lbs Fits VESA® patterns: up to 600x400 Tilt: +/-15° BT8427 Max screen size: 75" Max load: 154lbs Fits VESA® patterns: up to 600x400 Tilt: up to +20° SWIVEL BT899XL Max load: 55lbs Max fixing pattern: up to 19.5" BT899XL-AD Max load: 55lbs Max fixing pattern: up to 19.5" BT899 Max load: 55lbs Max fixing pattern: up to 14.5" BT899-AD Max load: 55lbs Max fixing pattern: up to 14.5" BT899-FD Max load: 55lbs Max fixing pattern: up to 14.5" ADJUSTABLEDROP ADJUSTABLEDROP ADJUSTABLEDROP ADJUSTABLEDROP C OMP L E T E MOUN T I NG S O L U T I ON S ADDITIONAL MOUNTING SOLUTIONS AV STORAGE WALL MOUNTS WALL PULL-DOWN AV STORAGE SLIDE-OUT AV STORAGE BT7883 Max screen size: 46" - 75" Max screen weight: 154lbs Max equipment load: 22lbs Fits universal patterns: 200x200 up to 600x400 BT7889 Max load: 22lbs Max AV equipment size: 17.7" x 11" BT7888 Max load: 22lbs Max AV equipment size: 17.7" x 9.8" BT7885 Max screen size: 49" - 86" Max screen weight: 154lbs Max equipment load: 18lbs Fits universal patterns: 200x200 up to 600x400 AV STORAGE SLIDE-OUT AV STORAGE TWINSCREEN TRIPLE SCREEN FPMA-D550BLACK Max screen size: 32" Max load: 18lbs Fits VESA® patterns: 75x75 & 100x100 Tilt: +90° Swivel 180° Screen Rotation: 360° FPMA-D550D3BLACK Max screen size: 27" Max load: 13lbs per screen Fits VESA® patterns: 75x75 & 100x100 Tilt: +90° Swivel 180° Screen Rotation: 360° DS70-450BL1 Max screen size: 42" Max load: 33lbs Fits VESA® patterns: 75x75 & 100x100 Tilt: +/-90° Swivel 180° Screen Rotation: 360° FPMA-D550DBLACK Max screen size: 32" Max load: 18lbs per screen Fits VESA® patterns: 75x75 & 100x100 Tilt: +90° Swivel 180° Screen Rotation: 360° DS75-450BL2 Max screen size: 32" Max load: 18lbs per screen Fits VESA® patterns: 75x75 & 100x100 Tilt: +/-10° Swivel 180° Screen Rotation: 360° TWINSCREEN
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 11 CEILING CEILING SPEAKER MOUNTS WALL SOUNDBAR BT8428 Max screen size: 65" Max load: 110lbs per screen Fits universal patterns: up to 600x400 Tilt: +/-15° BT8448 Max screen size: 65" - 120" Max load: 286lbs Fits VESA® patterns: up to 1000x600 BT8449 Max screen size: 65" - 120" Max load: 176lbs Fits VESA® patterns: up to 1000x600 Tilt: up to +15° BTV914 Max load: 22lbs Height adjustable: 9.85" Lateral adjustable: 4.40" BT893-AD Max load: 154lbs Max fixing pattern: up to 31" BT893-FD Max load: 154lbs Max fixing pattern: up to 31" BT893 Max load: 154lbs Max fixing pattern: up to 31" ADJUSTABLEDROP BT899XL-FD Max load: 55lbs Max fixing pattern: up to 19.5" BACK-TO-BACK XXL XXL TILT BT332 Max load: 11lbs Tilt: +/-20° Swivel: 180° BT77 Max load: 55lbs Tilt: +/-10° Swivel: 360° Adjustable clamp width: 5.3" - 11" BT15 Max load: 33lbs Adjustable arm length: 7" - 11" SIDE-CLAMPING CENTER SPEAKER This reference guide gives a quick overview of B-Tech's Additional Mounting Solutions. Please visit our website at www.btechavmounts.com for full specifications. Patent N°: 7523906 COMPLETE MOUNT ING SOLUT IONS DESKTOP STAND TWINSCREEN CURVEDWIDESCREEN CURVEDWIDESCREEN TWINSCREEN TRIPLE SCREEN NM-D775DX3BLACK Max screen size: 27" Max load: 13lbs per screen Fits VESA® patterns: 75x75 & 100x100 Tilt: +/-20° Swivel 360° Screen Rotation: 360° DS70PLUS-450BL1 Max screen size: 49" Max load: 40lbs Fits VESA® patterns: 75x75 & 100x100 Tilt: +/-45° Swivel 180° Screen Rotation: 360° DS70S-950BL1 (Black) DS70S-950WH1 (White) Max screen size: 49" Max load: 40lbs Fits VESA® patterns: 75x75 & 100x100 Tilt: +/-90° Swivel 180° Screen Rotation: 360° DS75S-950BL2 (Black) DS75S-950WH2 (White) Max screen size: 27" Max load: 18lbs per screen Fits VESA® patterns: 75x75 & 100x100 Tilt: +/-60° Swivel 180° Screen Rotation: 360° FPMA-D550DDBLACK Max screen size: 32" Max load: 18lbs per screen Fits VESA® patterns: 75x75 & 100x100 Tilt: +90° Swivel 180° Screen Rotation: 360°
12 B-TECH AV MOUNTS TM SYSTEM X MENU BOARD MOUNT I NG SYSTEM B-Tech is the go-to multi-screen mounting systems provider, favored by installers worldwide, thanks to a large selection of solutions that cover almost any requirement. Our modular mounting system for single rail menu board installations are suitable for screens of any size and can be configured for specific requirements using our System X component range. Mount multiple screens side-by-side with wall, ceiling, floor & curved solutions available. Screens can be mounted in landscape or portrait orientation with interface options that include fixed, tilt, or pop-out arms with micro-adjustment, allowing for a precise alignment and a 'hassle-free' installation; perfect for fast food restaurants, transport hubs, entertainment venues etc. For full product specifications including technical drawings, scan the QR codes to view the online product page. KEY FEATURES Configurablemounting solution available to order to you requirements from stock Choice of fixed, tilt, micro-adjustment or pop-out interface arms Multiple rail and pole lengths available - can be cut or joined to any length Micro-adjustment arms allow tool-less adjustments for seamless display alignment Full service options available - Pop-Out arms for easy service access or recess mounting Suitable for landscape or portrait mounting Lateral shift available for post installation screen alignment Curved options available Safety screws help prevent unauthorized removal of screens Simple installation with all mounting hardware included SYSTEM X MENU BOARD MOUNTS Original Designs by B-Tech AV Mounts - Registered Designs & Patents apply
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 13 SYSTEM X MENU BOARD MOUNT I NG SYSTEM SINGLE RAIL MULTI-SCREEN INSTALLATIONS AVAILABLE AS WALL OR CEILING MOUNTS FROM STOCK AND ARE READY TO CUSTOMIZE RAILS CAN BE EXTENDED TO ANY LENGTH CUSTOMIZE RAILS TO MATCH THE NUMBER OF SCREENS MOUNTED MENU BOARD MOUNT I NG SYSTEMS Example configurations shown below CONFIGURE TO YOUR EXACT REQUIREMENTS MENU BOARD MOUNTING SYSTEM POP-OUT MENU BOARD MOUNTING SYSTEM CEILING MOUNTED MENU BOARD MOUNTING SYSTEM CEILING MOUNTED CURVED MENU BOARD MOUNTING SYSTEM BT8330 BT8331 BT8332 BT8333 CHOICE OF FIXED, TILT OR MICRO-ADJUSTMENT INTERFACE ARMS AVAILABLE CHO I CE OF I NTERFACE ARMS RA I L EXTENS I ON EXAMPLE X4 SCREEN CONFIGURATION MULTIPLE POLE LENGTHS AVAILABLE FOR CEILING MOUNTING CHO I CE OF CE I L I NG DROPS max screen max LOAD max vesa 75" 900 110lbs PER SCREEN max screen max LOAD max vesa 75" 900 110lbs PER SCREEN max screen max LOAD max vesa 75" 900 110lbs PER SCREEN max screen max LOAD max vesa 75" 900 110lbs PER SCREEN
TM 14 B-TECH AV MOUNTS SYSTEM X V I DEOWALL MOUNT I NG SYSTEM B-Tech is the go-to multi-screen mounting systems provider, favored by installers worldwide, thanks to a large selection of solutions that cover almost any requirement. Our modular mounting system for multi-rail video wall installations are suitable for screens of any size and can be configured for specific requirements using our System X component range. Mount multiple screens side-by-side with wall, ceiling, floor & curved solutions available. Screens canbemounted in landscapeorportrait orientationwith interface options that include fixed, tilt, or pop-out arms with micro-adjustment, allowing for a precise alignment and a 'hassle-free' installation; perfect for fast food restaurants, transport hubs, entertainment venues etc. For full product specifications including technical drawings scan the QR code for each product to view the online page. KEY FEATURES Configurablemounting solution available to order to you requirements from stock Choice of fixed, tilt, micro-adjustment or pop-out interface arms Multiple rail and pole lengths available - can be cut or joined to any length Micro-adjustment arms allow tool-less adjustments for seamless display alignment Full service options available - Pop-Out arms for easy service access or recess mounting Suitable for landscape or portrait mounting Lateral shift available for post installation screen alignment Curved options available Safety screws help prevent unauthorized removal of screens Simple installation with all mounting hardware included SYSTEM X VIDEOWALL MOUNTS
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 15 SYSTEM X V I DEOWALL MOUNT I NG SYSTEM MULTI SCREEN, MULTI-RAIL INSTALLATIONS AVAILABLE ASWALL, FLOOR OR CEILINGMOUNTS CUSTOMIZE OR CHOOSE OFF-THE-SHELF KITS VIDEOWALL MOUNTING SYSTEM BT8341 BT8340 POP-OUT VIDEOWALL MOUNTING SYSTEM BT8342 CEILING MOUNTED VIDEOWALL MOUNTING SYSTEM BT8343 CEILING MOUNTED CURVED VIDEOWALL MOUNTING SYSTEM max screen max LOAD max vesa web PAGE 75" 900 POP-OUT INTERFACE ARMS AVAILABLE FOR FULL SERVICE ACCESS INCLUDED AS STANDARD WITH BT8331 & BT8341 POP OUT ARMS FOR SERVICE ACCESS MULTIPLE POLE LENGTHS AVAILABLE FOR CEILING MOUNTING CHO I CE OF CE I L I NG DROPS EXAMPLE 3X3 VIDEOWALL CONFIGURATION V I DEOWALL MOUNT I NG SOLUT I ONS Example configurations shown below CONFIGURE TO YOUR EXACT REQUIREMENTS max screen max LOAD max vesa 75" 900 max screen max LOAD max vesa 75" 900 max screen max LOAD max vesa 75" 900 CHOICE OF FIXED (F), TILT (T) OR MICROADJUSTMENT (M) INTERFACE ARMS AVAILABLE CHO I CE OF I NTERFACE ARMS 110lbs PER SCREEN 110lbs PER SCREEN 110lbs PER SCREEN 110lbs PER SCREEN
16 B-TECH AV MOUNTS AV ACCESSORY COMPONENT SHELVES FIT AV ACCESSORIES SUCH AS SHELVES DIRECTLY TO COLUMNS VIDEOWALL STAND MOBILE VIDEOWALL STAND BOLT DOWN VIDEOWALL STAND CUSTOM SET-UPS USE THE ONLINE CONFIGURATOR TO CUSTOMIZE SCREEN SET-UP EXAMPLE 2X2 CONFIGURATION BT8370 BT8371 BT8372 V I DEOWALL STANDS Example configurations shown below CONFIGURE TO YOUR EXACT REQUIREMENTS max screen max LOAD max vesa 75" 900 MULTI-SCREEN, MULTI-RAIL INSTALLATIONS AVAILABLE AS FLOOR STANDS FROM STOCK AND READY TO CUSTOMISE SYSTEM X V I DEOWALL MOUNT I NG SYSTEM 110lbs PER SCREEN max screen max LOAD max vesa 75" 900 110lbs PER SCREEN max screen max LOAD max vesa 75" 900 110lbs PER SCREEN
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 17 ADJUSTABLE ANGLE FOR CURVED DISPLAYS CABLE MANAGEMENT BT8374 BT8375 BT8376 BT8373 CURVED VIDEOWALL STAND MOBILE CURVED VIDEOWALL STAND BOLT DOWN CURVED VIDEOWALL STAND FREESTANDING CURVED VIDEOWALL STAND INTEGRATED ANGLE CONNECTOR CREATES CURVED STANDS UP TO +/-45º INTEGRATED CABLE MANAGEMENT FEATURED FOR A TIDY INSTALLATION INCLUDED ON ALL SYSTEM X STANDS EXAMPLE 4X2 CONFIGURATION CURVED V I DEOWALL STANDS Example configurations shown below CONFIGURE TO YOUR EXACT REQUIREMENTS max screen max LOAD max vesa 75" 900 max screen max LOAD max vesa 75" 900 110lbs PER SCREEN MULTI SCREEN, MULTI-RAIL INSTALLATIONS AVAILABLE AS CURVED FLOOR STANDS CUSTOMIZE OR CHOOSE OFF-THE-SHELF KITS SYSTEM X V I DEOWALL MOUNT I NG SYSTEM 110lbs PER SCREEN max screen max LOAD max vesa 75" 900 110lbs PER SCREEN max screen max LOAD max vesa 75" 900 110lbs PER SCREEN
18 B-TECH AV MOUNTS SYSTEM X ONLINE CONFIGURATION TOOL STEP 1: GO TO WWW.BTECHAVMOUNTS.COM STEP 2: SELECT FREESTANDING, MOBILE OR BOLT DOWN OR WALL & POLE MOUNTED VIDEOWALLS & MENU BOARDS SCREEN SIZE PLEASE SELECT SCREENS PER ROW PLEASE SELECT COLUMN HEIGHT PLEASE SELECT INTERFACE FUNCTION PLEASE SELECT NUMBER OF ROWS PLEASE SELECT COLUMN COLOR PLEASE SELECT STEP 3: SELECT SPECIFICATIONS FROM DROP DOWN BOXES CREATE VIDEOWALLS & MENU BOARDS WALL / FREESTANDING / MOBILE / BOLT DOWN STANDS OR POLE MOUNTED Add option for a curved display STEP 4: SELECT ADDITIONAL OPTIONS: CURVED INSTALLATION Our online configuration tool is designed to specify System X mounting solutions, whether that be for a specific configuration of an off-the-shelf package or for something more bespoke. FIXED POP-OUT TILT SYSTEM X ONL INE CONF IGURAT ION TOOL MICRO ADJUSTMENT www.btechavmounts.com/systemx-configurator
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 19 STEP 7: EXAMPLE CONFIGURATIONS Configurations can be specified in just a few simple clicks - start by choosing between freestanding, mobile, bolt down, wall or ceiling mounted options. Then, enter details about your screen size and the quantity to be installed, the orientation, the type of interface arm function required (e.g. pop-out) as well as pole length/leg height (where applicable). Once complete, fill out your contact details and we’ll get in touch and give quote for your requested configuration. BESPOKE CONFIGURATIONSAVAILABLE See SystemX components or contact your local sales rep for more information REQUEST A QUOTE FOR THIS CONFIGURATION STEP 5: SELECT DESIRED ORIENTATION (LANDSCAPE, PORTRAIT) B-TECH MODEL: BT8372-L2X2-42-M-180/S STEP 6: CONFIGURE YOUR VIDEOWALL MOUNTING SOLUTION TRY NOW: WWW.BTECHAVMOUNTS.COM/SYSTEMX-CONFIGURATOR SYSTEM X ONL INE CONF IGURAT ION TOOL
20 B-TECH AV MOUNTS Designed to make videowall installations as quick and simple as possible, these modular mounting solutions (one mount per screen) can be used to create unlimited configurations in both landscape and portrait format. Push-in, pop-out opening enables access to the rear of the mounted screen for servicing and maintenance and the low profile designs are ideal for multi-screen installations and mounting into walls with a shallow recess. Micro-adjustments knobs make screen alignment quick and easy. For full product specifications including technical drawings scan the QR code for each product to view the online page. MODULAR VIDEOWALL MOUNTS KEY FEATURES Modular mounts allow videowall assembly in an unlimited number of configurations Suitable for landscape or portrait screen mounting Pop-out system provides a safe and easy service access Tool-less micro-adjustment for seamless display alignment Depth, height and lateral adjustments of screen Slim designs ideal for low profile installs on walls or mounting in shallow recesses Keyhole mounting for quick and easy installation Also suitable for pole mounting using System 2 collars Integrated locking mechanism prevents accidental pop out of mount Safety screws help prevent unauthorized removal of screens Screen specific wall plate spacers kits are available for the BT8312 to speed up installation times MODULAR V I DEOWALL MOUNTS
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 21 BT8310XL HEAVY DUTY POP-OUT FLAT SCREEN WALL MOUNT WITH MICRO-ADJUSTMENT RECESS MOUNTING UNLIMITED CONFIGURATIONS ONE MOUNT PER SCREEN POP-OUT DESIGN FOR FULL SERVICE ACCESS IDEAL FOR MOUNTING INTO A SHALLOW RECESS OUR MODULAR MOUNTING SYSTEM ALLOWS VIDEOWALL ASSEMBLY IN AN UNLIMITED NUMBER OF LANDSCAPE OR PORTRAIT CONFIGURATIONS, FROM SIMPLE 2X2 VIDEOWALLS TO COMPLEX MOSAIC PATTERNS BT8309 POP-OUT FLAT SCREEN WALL MOUNT WITH MICRO-ADJUSTMENT BT8312 SLIMLINE SOFT-OPEN FULL SERVICE VIDEOWALL MOUNT WITH 8-POINT MICRO-ADJUSTMENT 8 POINTS OF MICRO-ADJUSTMENT FOR DEPTH, HEIGHT AND LATERAL SCREEN ADJUSTMENT MICRO-ADJUSTMENT MODULAR V I DEOWALL MOUNTS MODULAR V I DEOWALL MOUNTS QUICK TO INSTALL AND EASY TO CONFIGURE, DESIGNED SPECIFICALLY FOR VIDEOWALL APPLICATIONS. WALL PLATE SPACER KITS TO AID QUICK INSTALLATION ALSO AVAILABLE... max screen max LOAD max vesa 75" 600 x 400 110lbs max screen max LOAD max vesa 120" 600 x 400 275lbs max screen max LOAD max vesa web PAGE 42" 200 55lbs Patent App N°: 17/588,521
22 B-TECH AV MOUNTS dvLED MOUNT I NG SOLUT I ONS dvLED MOUNTING SOLUTIONS Solutions available for all major brands, including: We have brought a range of solutions to market that are simple to specify, with fast turnaround times from off-the-shelf stock. Designed to work with all popular dvLED cabinets on the market, our dvLEDmounting solutions can be specified to requirements using our online dvLED configuration tool. For ceilingmounted or curved installations, contact us directly. Most of our dvLEDmounting solutions canbe specified to requirements usingour online dvLEDconfiguration tool. Formore bespoke and more complex installations, contact us directly at technical@btechavmounts.com and we'll be happy to configure a solution that suits your needs. In addition to our standard wall, floor, mobile and ceilingmounts, our system can be used for more complex projects such as mounting to curvedwalls, in ceiling-to-floor/wall applications or when cosmetic frames need to be added to hide themounting structure.
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 23 dvLED MOUNT & STANDS Example configurations shown below CONFIGURE TO YOUR EXACT REQUIREMENTS MOBILE dvLED VIDEOWALL STAND BT9371 BOLT DOWN dvLED VIDEOWALL STAND BT9372 CEILING MOUNTED dvLED VIDEOWALL MOUNT BT9342 BT9344 FLOOR-T0-CEILING dvLED VIDEOWALL MOUNT dvLED VIDEOWALL STAND WALL MOUNTED dvLED VIDEOWALL MOUNT BT9340 BT9370 dvLED MOUNT I NG SOLUT I ONS
24 B-TECH AV MOUNTS SPECIALIST MOUNTS FOR DIGITAL SIGNAGE SPECIALIST MOUNTS FOR DIGITAL SIGNAGE With more screens featuring in retail environments than ever before, the need for a comprehensive range of specialist mounting solutions is apparent. In addition to videowalls, single screens (ranging from small to XXL) and specialist signage such as LG's XXL 110" displays are being installed into retail outlets. Our range of specialist mounting solutions includes various options catering to the applications often required: portrait mounts, pop-out options for recess mounting rotational mounts for eye catching displays. For the full list of products available and specifications including technical drawings, scan the QR code to view the online page.
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 25 BT7550 ROTATIONAL FLIP MOUNT FOR LARGE SCREENS BT8322 PORTRAIT DIGITAL SIGNAGE WALL MOUNT BT9920 XXL DISPLAY WALL MOUNT BT9921 SOFT-OPEN FULL SERVICE WALL MOUNT FOR XXL DISPLAYS PORTRA I T WALL MOUNT ROTATION CAN BE STOPPED AND FIXED AT ANY ANGLE BETWEEN 0° AND 90° POP-OUT, FULL SERVICE MOUNT IDEAL FOR RECESSEDWALLS EXTRA LARGE WALL MOUNTS SUITABLE FOR DISPLAYS SUCH AS LG'S 110UM5J max screen max LOAD max vesa 65" 600 x 400 SPECIALIST MOUNTS FOR DIGITAL SIGNAGE XXL WALL MOUNTS ROTAT I ONAL WALL MOUNT max screen max LOAD max vesa tilt rotation 65" 400 4.5° 90° 154lbs 176lbs max screen max LOAD max vesa 120" 1600 x 800 440lbs max screen max LOAD max vesa 120" 1600 x 800 176lbs
26 B-TECH AV MOUNTS FLAT SCREENMOUNTS Many features can be found on products throughout the range, including designs for making installation as straight forward as possible. Additionally, many of the wall mounts are compatible with the B-Tech's System2 and SystemXmodular ranges using accessory collars, which allow them to be used for pole/columnmounted applications. B-Tech has a wide range of screen ceiling mounts available for small to XXL screens, suitable for landscape and portrait mounting. Ceiling drop options with a fixed or tool-less adjustment are available. Note, max screen sizes are recommendations only and it may be possible to mount other sizes, please refer to the screen's weight and mounting pattern to find the best compatible mount. For the full range of flat screen mounts with full product specifications including technical drawings, scan the QR codes to view the online pages. B-Tech's comprehensive collection of professional wall and ceiling screen mounts cover various fixed, tilt and full motion solutions for screens ranging from 10" to 120". FLAT SCREEN MOUNTS The VESA® Standard VESA mounting patterns are the distance (in millimeters) between the four mounting holes on the back of a screen and are used by most TV brands. vesa KEY FEATURES Simple 'hook-on' screen mounting Designed for an easy 1-2-3 step installation, mounts supplied pre-assembled All mounting hardware included Suitable for landscape or portrait mounting Universal mounts feature lateral shift of the screen once mounted Leveling screws allow adjustment of screen height Brackets include various security features to prevent easy removal of the screen with either safety screws or a locking bar included Cover plates and cable management are included with swing armmounts for a neat and tidy installation Most wall brackets feature 'On Wall Leveling System' (OWLS) or have keyhole fixings for a hassle-free installation A selection of mounts are compatible with System 2 and System X ranges suitable for both pole and column mounting
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 27 FLAT SCREEN MOUNTS WALL MOUNTS CE I L I NG MOUNTS BT7510 ULTRA-SLIM WALL MOUNT WALL MOUNT WITH TILT BT8431 DOUBLE ARM WALL MOUNT WITH TILT & SWIVEL BT8226 BT8428 BACK-T0-BACK CEILING MOUNT WITH TILT BT8448 EXTRA-LARGE DISPLAY CEILING MOUNT BT8427 ADJUSTABLE DROP CEILING MOUNT WITH TILT FIXED DROP & ADJUSTABLE DROP CEILING MOUNTING KITS AVAILABLE WITHOPTIONS FORDIFFERENT POLES LENGTHS Below is a small selection of flat screenmounts available fromB-Tech. Visit online to see the full range max screen max LOAD max vesa tilt 75" 20° 600 x 400 154lbs max screen max LOAD max vesa tilt swivel 65" 3° 14° 180° 600 x 400 77lbs max screen max LOAD max vesa 28" 100 44lbs BT8228 XL TWIN CANITLEVER ARM WALL MOUNT WITH TILT & SWIVEL max screen max LOAD max vesa tilt swivel 120" 3° 15° 130° 800 x 600 276lbs USE ACCESSORY COLLARS (BT7052/BT7841) TO POLE MOUNT COMPATIBLE SCREEN MOUNTS 15° PER SCREEN max screen max LOAD max vesa tilt 65" 15° 600 x 400 110lbs max screen max LOAD max vesa 120" 1000 x 600 286lbs max screen max LOAD max vesa tilt 55" 15° 15° 400 110lbs
28 B-TECH AV MOUNTS DESK MOUNTS & STANDS Simple to install, easy to adjust and great to use... The Neomounts range of premium, full motion desk mounts have been ergonomically designed to allow the user to achieve maximum comfort whilst helping to reduce eye and neck strain injuries. The range includes freestanding and desk-clamping mounts, single screen, twin screen and triple screen solutions, featuring a smooth and effortless height, depth and tilt adjustment, screen rotation and cable management. All mounts in this range are suitable for VESA 75 x 75 and 100 x 100 mounting patterns. A selection of the desk mounts are equipped with an quick-release VESA system and are supplied with both a top-fix clamp and grommet for a quick and easy installation. SOLUTIONS AVAILABLE FOR MOUNTING SINGLE, TWIN OR TRIPLE SCREEN DISPLAYS. BLACK OR WHITE COLOR OPTIONS AVAILABLE ON A SELECTION OF DESK MOUNTS. DESK MOUNTS Based in the Netherlands, Neomounts is a specialist supplier of IT mounts and is a sister company to B-Tech AV Mounts, with the two companies together forming the Global Mounts Group. As such, a selection of Neomounts products is held in stock and sold by B-Tech to the US market. For more information about these products please scan the QR codes to view the individual product pages on the B-Tech website, or you can also visit www.neomounts.com
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 29 ALSO AVAILABLE... FULL MOTION DESK MOUNT PREMIUM FULL MOTION DESK MOUNT FULL MOTION DESK MOUNT DS70-450BL1 FULL MOTION DUAL DESK MOUNT WITH CROSSBAR & HANDLE PREMIUM FULL MOTION DUAL DESK MOUNT WITH CROSSBAR & HANDLE DS75-450BL2 DS70PLUS-450BL1 DS70S-950BL1* DS75S-950BL2* NM-D775DX3BLACK FULL MOTION TRIPLE DESK MOUNT WITH CROSSBAR & HANDLE FULL MOTION DUAL DESK STAND FPMA-D550DDBLACK WALL ADAPTER FOR DS70-450BL1 & DS75-450BL2 AWL75-450BL DESK MOUNTS SUPPLIED BOTH A DESK CLAMP & A GROMMET INTEGRATED CABLE MANAGEMENT OR CABLE MANAGEMENT CLIPS INCLUDED ENSURING A CLEAN AND TIDY ROUTING OF THE CABLES. IDEAL FOR CURVED WIDESCREEN DISPLAYS *WHITE VERSIONS ALSO AVAILABLE DESK MOUNTS PER SCREEN max screen max LOAD max vesa tilt swivel ROTATION 32" 90° 180° 100 18lbs 360° max screen max LOAD max vesa tilt swivel ROTATION 42" 90° 180° 100 33lbs 360° 90° max screen max LOAD max vesa tilt swivel ROTATION 49" 45° 180° 100 40lbs 360° 45° max screen max LOAD max vesa tilt swivel ROTATION 49" 90° 180° 100 40lbs 360° 90° max screen max LOAD max vesa tilt swivel ROTATION 27" 60° 180° 100 18lbs 360° 60° PER SCREEN max screen max LOAD max vesa tilt swivel ROTATION 32" 10° 180° 100 18lbs 360° 10° PER SCREEN max screen max LOAD max vesa tilt swivel ROTATION 27" 20° 360° 100 13lbs 360° 20° DESK MOUNTS PER SCREEN
30 B-TECH AV MOUNTS FLOOR STANDS & MOB I LE SOLUT I ONS FLOOR STANDS & MOBILE SOLUTIONS This robust yet stylish range of carts and floor stands offers the perfect blend of long-lasting build quality and striking good looks, making them perfectly suited to corporate, education, government, hospitality, leisure, rental and any other markets where flexible positioning of displays is needed. Solutions for screens of all sizes, up to the largest heavy-duty interactive touchscreens, are available throughout the range and compatibility for both landscape and portrait orientations is a common feature. Accompanying shelving solutions from our AV accessory collection complement this range perfectly with other accessories and media storage devices that can be fitted to most options. In addition to the mobile solutions, a comprehensive range of freestanding floor stands are available. Starting with the low profile bases, there are the standard kits which use 02" poles and a more stylish option which feature aluminum columns. These complete mounting kits are also available as individual components, allowing you to customize a floor stand exactly to your installation requirements. Finally, there are the heavier duty floor stands which utilize the System X range of components and are suitable for displaying more than one screen. To view the complete range with full product specifications including technical drawings, scan the QR codes to view the product pages online. KEY FEATURES Universal designs suitable for displaying screens in a landscape or portrait orientation Non-marking locking / braked casters included with mobile display carts Collar compatible accessories such as shelves (available separately) can be fitted to the column or pole Integrated cable management for a smart installation Interface arms include adjustment screws to help level the height of the screen Safety screws help prevent unauthorized removal of screen Simple 'hook-on' screen installation with all mounting hardware included
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 31 FLOOR STANDS & MOB I LE SOLUT I ONS MOB I LE D I SPLAYS STANDS FREESTAND I NG D I SPLAY STANDS ALSO AVAILABLE... BT856-FEET ADJUSTABLE LEVELING FEET LARGE FLAT SCREEN TWIN COLUMN FLOOR STAND BT8583 FLAT SCREEN FLOOR STAND BTF840 max screen max LOAD VESA 75" 600 x 400 FLAT SCREEN SINGLE POLE FLOOR STAND BT8572 max screen max LOAD VESA 55" 600 x 400 FLAT SCREEN CART/ STAND BT8504 max screen max LOAD max vesa 75" 600 x 400 USE BT7841 ACCESSORY COLLARS (NOT INCLUDED) TO RETRO-FIT SHELVES ONTO EXISTING INSTALLATIONS DESIGNER FLAT SCREEN CART BT8562 XL DESIGNER FLAT SCREEN CART BT8564 max screen max LOAD max vesa 75" 600 x 400 USE WITH B-TECH DESIGNER CARTS TO CREATE FREESTANDING DISPLAYS 154lbs 154lbs 154lbs max screen max LOAD VESA 75" 600 x 400 154lbs 88lbs max screen max LOAD max vesa 120" 1000 x 600 286lbs
32 B-TECH AV MOUNTS UC/VC D I SPLAY MOUNTS & ACCESSOR I ES UC/VC DISPLAY MOUNTS & ACCESSORY MOUNTS Ideal for video conferencing installations, a full range of twin screen mounting solutions including wall mounts, floor stands and mobile carts are available from B-Tech. A wide range of AV accessories to hold media equipment, video bars, VC cameras etc. can easily be added to the displays. V I DEO BAR MOUNTS Install video bars onto existing B-Tech mounts above or below the screen using accessory mounting arms, collars for pole mounting or fix directly to columns. Solutions are available for most manufacturers. For the most up-to-date brand listings visit B-Tech's website or contact us at technical@btechavmounts.com
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 33 3kg max LOAD MOUNTING PLATE FOR JABRA PANACAST 50 POLY STUDIO / X50 / X70 BT7871 MOUNTING PLATE FOR YEALINK A30 / MEETINGEYE 600 BT7878 max LOAD web PAGE 4kg UC/VC D I SPLAY MOUNTS & ACCESSOR I ES TWI N SCREEN MOUNTS V I DEO BAR MOUNTS AV SHELVES & MOUNT I NG ARMS TWIN SCREEN VC WALL MOUNT FOR SCREENS UP TO 65" BT8416 TWIN SCREEN VC CART BT8517 TWIN SCREEN VC STAND BTF845 ADJUSTABLE ACCESSORY MOUNTING ARM Use with compatible B-Tech flat screen mounts ADJUSTABLE ACCESSORY MOUNTING ARM Use with compatible B-Tech AV storage screen mounts - See page 34 BT7031 max LOAD X1 max LOAD X2 9lbs 33lbs BT7863 SMALL AV ACCESSORY SHELF 9.25" x 4.75" USE BT8390-SA ACCESSORY MOUNTING ARM FOR USE WITH BT8390 MOUNTING RAILS (SEE PAGE 41) BT7032 LARGE AV ACCESSORY SHELF 19.7" x 15" max LOAD 9lbs 1 POLE 2 POLES 17lbs 33lbs max screen max LOAD max vesa 55" 600 x 400 25kg PER SCREEN 5 lbs max screen max LOAD max vesa 75" 800 PER SCREEN 220lbs BT7034 max LOAD X1 max LOAD X2 13lbs 26lbs max screen max LOAD max vesa 65" 600 x 400 154lbs PER SCREEN Below is a small selection of twin screenmounts available fromB-Tech. Visit online to see the full range Below is a small selection of video bar mounts available fromB-Tech. Visit online to see the full range
34 B-TECH AV MOUNTS AV STORAGE MOUNTS AV STORAGE MOUNTS WALL MOUNTED FIXED AV STORAGE TRAY BT7889 max screen max vesa max LOAD max LOAD 75" 600 x 400 FLAT SCREEN WALL MOUNT WITH SLIDE-OUT AV STORAGE TRAY BT7883 max screen max vesa max LOAD max LOAD 86" 600 x 400 SCREEN TRAY FLAT SCREEN WALL MOUNT WITH PULL-DOWN AV STORAGE TRAY BT7885 154lbs 18lbs 22lbs 154lbs max LOAD 22lbs WALL MOUNTED SLIDE-OUT AV STORAGE TRAY BT7888 max LOAD 22lbs Storage trays are an ideal solution for discreet mounting of AV equipment, such as power supplies, media players and video conferencing equipment behind a screen. SCREEN TRAY
WWW.BTECHAVMOUNTS.COM INFO@BTECHAVMOUNTS.COM 35 SPEAKER MOUNTS SPEAKER MOUNTS BT332 SPEAKER WALL MOUNTS WITH TILT & SWIVEL (PAIR) BT15 CENTER SPEAKER WALL MOUNT WITH ADJUSTABLE ARMS BT77 SIDE-CLAMPING SPEAKER WALL MOUNTS WITH TILT & SWIVEL (PAIR) Patent N°: 7523906 max LOAD tilt swivel 25° 25° 360° max LOAD tilt swivel 20° 20° 180° max LOAD 11lbs 55lbs 33lbs B-Tech's range of speaker mounts are suitable for a wide range of speakers. Supplied in color retail packaging they are ideal for both the consumer and professional market.
36 B-TECH AV MOUNTS PROJ ECTOR MOUNTS PROJECTOR MOUNTS Offering a wide selection of mounts to suit a variety of projector sizes and types, from home projection right up to large scale models used for entertainment venues and projection mapping. Available in Black or White finishes, B-Tech projector mounts are designed to fit quickly, be easily installed and can be ordered for either direct to the ceiling mounting or with fixed or tool-less height adjustable ceiling drops. Projector ceiling mounts suitable for installation onto angled ceilings are available and a selection of models are compatible with the System 2 range for customizing solutions such as when extra high ceilings mean a much larger ceiling drop is required. The unique ‘carousel’mounting plate design featured on a number of products is for universal compatibility and micro-adjustment features allow easy positioning of mounted projectors for a perfectly aligned projected image. To view the products full specifications including technical drawings, scan the QR codes to visit the online pages. KEY FEATURES � Options to mount directly to the ceiling for a flush installation or onto a pole for an extended drop � Compatible with the B-Tech System 2 Professional Range and 1.5" NPT pipe systems � Pre-assembled for simple three step installation � Micro-adjustment for short throw projectors � Integrated cable management for a smart installation � Unique 'carousel' mounting plate for universal compatibility � Supplied with universal fixings suitable for most projectors using M2.5, M3, M4, M5 and M6 fixings � All mounting hardware included BLACK OR WHITE COLOR OPTIONS AVAILABLE FOR PROJECTOR CEILING MOUNTS
