www.btechavmounts.com 2024 Highlights Product Catalog
B-Tech AV Mounts 2 Welcome to the 2024 B-Tech AV Mounts Highlights Catalog For company info, product specs, assembly manuals, configuration tools, PR and media files, please visit: www.btechavmounts.com For our latest news, event details & product launches, subscribe to our mailing list: www.btechavmounts.com/mailing-list Connect with B-Tech Our full line catalog contains over 150 pages of mounting solutions for any application View online at www.btechavmounts.com B-Tech AV Mounts LLC +1 888 792 8188 Americas@btechavmounts.com This edition might have been called The B-Tech Highlights Catalog 2.0 as you may have noticed, there is a visual change this year. The introduction of a brand new B-Tech logo and updated brand styling to match. Our heritage is something we are really proud of here at B-Tech. With 52 years of experience under our belt and multiple staff members approaching their 15 and 20-year work anniversaries, longevity is an attribute we rate highly, and we only change a winning formula when we feel that the time is right. From a branding perspective, that time is now. So out with the old, in with the new... B-Tech AV Mounts LLC launched in the US in 2018 with the opening of two facilities in California; staff offices and a showroom are located in Brea, whilst a fully stocked warehouse is a short drive away in Santa Fe Springs. From these locations B-Tech handles all sales, distribution and product development for the North American market, which has rapidly become one of B-Tech's fastest growing markets worldwide. B-Tech's award winning professional products can be found installed across the globe in all types of public and commercial environments, including retail, broadcast, control rooms, corporate, education, exhibitions & conferences, health care, hospitality & leisure, museums & information centers, rental & stage, sporting arenas & transport hubs. This catalog highlights a selection of B-Tech products, to view the full range available visit www.btechavmounts.com Contents Welcome to the B-Tech Highlights Catalog Pg.2 Contents 2 Why Choose B-Tech 3 Complete Mounting Solutions Quick Reference Guides Pg.4-11 Menu Board Mounting Systems 12-13 Videowall Mounting Systems 14-19 Modular Videowall Mounts 20-21 dvLED Mounting Solutions 22-23 All-In-One LED Mounting Solutions 24-25 Digital Signage Mounts 26-27 Flat Screen Wall Mounts 28-29 Flat Screen Ceiling Mounts 30-31 Flat Screen Carts & Stands 32-35 UC & VC Twin Screen Mounting Solutions 36-37 Media Storage, Video Bar Mounts & Shelves 38-41 Projector Ceiling Mounts 42-43 Speakers Mounts 44-45 Component Ranges Mounting Guides Pg.46-55
3 info@btechavmounts.com 3 Why Choose B-Tech? Instagram @btechavmounts Install and event photos YouTube @btechavmounts Vimeo @btechavmounts Product and event videos Linkedin @ B-Tech AV Mounts News and updates Sales Support Local Service On A Global Scale Product Range Local Service On A Global Scale Heritage Manufacturing One of the most extensive ranges of mounting solutions within the industry Multiple options to suit a range of price points 1,000s of possible solutions using products from our stocked, modular component systems Most wall mounts combine with our component systems, meaning we can often fulfil bespoke requirements from stock We're able to produce complex quotes, such as for dvLED installations with an ultra-fast turnaround Dedicated technical support team to answer technical questions Same-day dispatch from most B-Tech locations Products are technically well designed & incredibly robust Tested to TUV & UL standards to give users confidence in their reliability Products are designed by our in-house engineering team to ensure the highest quality & innovation Our dedicated inside sales team has extensive experience in AV mounting From our global network of offices, we offer sales & technical support in multiple languages We are the only true global mounting company, with B-Tech facilities consisting of sales offices and stocked warehouses in all key territories EST. 1972 Established in 1972, we have vast experience in the AV industry Winner of the Manufacturer of the Year Award at the 2017 AV Awards, plus multiple nominations and wins for key ranges such as System X and our dvLED solutions. Global partnerships with display technology manufacturers X @btechavmounts
B-Tech AV Mounts 4 Modular Full Service Mounts Wall / Pop-Out BT8309 BT8312 BT8310XL BT9922 BT9926 Max screen size: 42" Max load: 55lbs Mounting patterns: 75x75 up to 200x200 Max screen size: 75" M ax load: 110lbs Mounting patterns: 200x100 to 600x400 Max screen size: 120" M ax load: 275lbs Mounting patterns: 200x100 to 600x400 Max screen size: 136" Max load: 440lbs Mounting patterns: up to 2400x1200 Max screen size: 120" Max load: 176lbs Mounting patterns: up to 1600x800 Digital Signage Wall Rotation BT7550 Max screen size: 65" M ax load: 154lbs Mounting patterns: up to 400x400 Screen rotation: 90° Portrait Portrait Portrait BT8322 Max screen size: 65" M ax load: 176lbs Mounting patterns: up to 400x600mm Distance from wall: 1.4" Column/Pillar BT7832 M ax load: 110lbs Adjustable width: 5.5" - 29.5" Use with a compatible flat screen mount System X Menu Board Mounts Wall Ceiling Pop-Out Curved BT8330 BT8331 BT8332 BT8333 Max screen size: 75" M ax load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" M ax load: 110lbs per screen Mounting patterns: up to 900mm System X Videowall Mounts Wall Ceiling Pop-Out Curved BT8340 BT8341 BT8342 BT8343 Max screen size: 75" M ax load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" M ax load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" M ax load: 110lbs per screen Mounting patterns: up to 900mm BT9923 Max screen size: 120" Max load: 440lbs M ounting patterns: up to 600x1500mm BT9925 Max screen size: 120" Max load: 187lbs M ounting patterns: up to 800x1600 Pop-Out XXL XXL XXL XXL XXL Multi-Screen & Digital Signage Mounts Quick Reference Guide Slimline Ultrawide Ultrawide
5 info@btechavmounts.com 5 Screen Specific All-In-One LED Mounts System X Curved Videowall Mounts Freestanding Mobile Bolt-Down BT8373 BT8376 BT8374 BT8374 Max screen size: 75" M ax load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" M ax load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" M ax load: 110lbs per screen Mounting patterns: up to 900mm System X Videowall Floor Stands Freestanding Mobile Bolt-Down Retractable Base BT8370 BT8371 BT8372 BT8377 Max screen size: 75" M ax load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" M ax load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" M ax load: 110lbs per screen Mounting patterns: up to 900mm Direct View LED Mounts Wall Freestanding Mobile Bolt-Down Retractable Base BT9340 BT9370 BT9371 BT9372 BT9377 LAEB015 136" Display IAB 146" All-In-One Display BT83LG163-S BT83LG163-M BT83LG163-B BT83LG171-S BT83LG171-M BT83LG171-B BT83LAEB015-S BT83LAEBO15-M BT83LAEB015-B Floor Stand BT9370-SAM110 BT9370-SAM146 This quick reference guide provides a brief overview of the B-Tech range of Multi-Screen Videowall Mounts, dvLED displays and Digital Signage mounting solutions. For more information on each product, please visit www.btechavmounts.com for full specifications. The configuration icon signifies that this product can be customized to meet your requirements through our convenient online configuration tool at www.btechavmounts.com/systemx-configurator. BT9370-SAM130 IAC 130" All-In-One Display Floor Stand Floor Stand IAB 110" All-In-One Display LAEC018 163" Display LAEC015 171" 21:9 Display Configure Online Mobile Stand Bolt-Down Stand Floor Stand Mobile Stand Bolt-Down Stand Floor Stand Mobile Stand Bolt-Down Stand Floor Stand BT9371-RM rear mounted BT9371-FM front mounted BT9372-RM rear mounted BT9377-RM rear mounted BT9372-FM front mounted BT9377-FM front mounted BT9340-RM rear mounted BT9340-FM front mounted BT9370-RM rear mounted BT9370-FM front mounted
B-Tech AV Mounts 6 Twin Screen Video Conferencing Floor-To-Wall Bolt-Down Freestanding Mode-AL Floor Stands Floor-To-Wall Floor-To-Ceiling Bolt-Down Premium Carts Mobile Flip Rotation BT8562 Max screen size: 75" M ax load: 154lbs M ounting patterns: up to 600x400 Dimensions: H:74" W:40.5" D:30.2" BT8564 Max screen size: 65" - 120" M ax load: 285lbs Mounting patterns: up to 1000x600 Dimensions: H:75" W:48.5" D:30" BT8566 Max screen size: 75" Max load: 154lbs Screen rotation: 90° Mounting patterns: up to 600x400 Dimensions: H:76" W:42.3" D:34" BT8700 Max screen size: 75" Max load: 154lbs M ounting patterns: up to 600x400 Dimensions: H:54" W:27.7" D:6.5" BT8701 Max screen size: 75" Max load: 154lbs M ounting patterns: up to 600x400 Dimensions: H:77.5" W:27.7" D:6.5" BT8702 Max screen size: 75" M ax load: 154lbs M ounting patterns: up to 600x400 Dimensions: H:80.7-106.3" W:27.7" D:8.3" BT8703 Max screen size: 75" M ax load: 154lbs M ounting patterns: up to 600x400 Dimensions: H:51.5" W:27.7" D:8.3" BT8704 Max screen size: 75" M ax load: 154lbs Mounting patterns: up to 600x400 Dimensions: H:75.2" W:27.7" D:8.3" Tall Tall BT8710 Max screen size: 65" M ax load: 155lbs per screen Mounting patterns: up to 600x400 Dimensions: H:77.5" W:78.7" D:6.5" BT8711 Max screen size: 65" M ax load: 155lbs per screen Mounting patterns: up to 600x400 Dimensions: H:75.2" W:78.7" D:8.3" BT8712 Max screen size: 65" M ax load: 123lbs per screen Mounting patterns: up to 600x400 Dimensions: H:76.5" W:78.7" D:29.6" BT8528 For screen sizes: 75"- 86" M ax load: 220lbs per screen Mounting patterns: up to 600x400 Dimensions: H:76" W:118" D:37.4" VC Shelf VC Shelf VC Shelf VC Shelf VC Shelf VC Shelf BT8590 Max screen size: 72" - 120" Max load: 285lbs Mounting patterns: up to 1600x800mm Dimensions: H:75" W:69" D:30" BTF845 For screen sizes: 46"- 55" Max load: 55lbs per screen M ounting patterns: up to 600x400 Dimensions: H:72.5" W:69" D:23.8" XXL XXL Floor Stands / Carts Quick Reference Guide System X Floor Stands Freestanding Bolt-Down XL Portrait BTF840 Max screen size: 39"-75" Max load: 155lbs M ounting patterns: up to 600x400 Dimensions: H:72.5" W:35" D:23.8" BTF843 Max screen size: 65"- 85" Max load: 155lbs Mounting patterns: up to 800x600 Dimensions: H:72.5" W:35" D:23.8" Dual Stack Landscape Dual Stack Portrait BTF842 Max screen size: 47"- 65" M ax load: 77lbs per screen M ounting patterns: up to 600x400 Dimensions: H:96" W:35" D:23.8" BT8577 Max screen size: 75" M ax load: 110lbs M ounting patterns: up to 600x400 Base Dimensions: H:10.3" W:3.4" D:17"-33" BT8587 Max screen size: 86" Max load: 154lbs Mounting patterns: up to 800x600 Dimensions: H:75" W:27.5" D:17"-33" BTF841 Max screen size: 32"- 65" Max load: 77lbs per screen Mounting patterns: up to 600x400 Dimensions: H:72.5" W:35" D:23.8" BT8538 For screen sizes: 75"- 86" Max load: 220lbs per screen Mounting patterns: up to 600x400 Dimensions: H:72" W:118" D:9.5" Pole Column Retractable Base Retractable Base
7 info@btechavmounts.com 7 Freestanding Floor-To-Wall Bolt-Down Carts Mobile XXL XXL XXL BT8705 Max screen size: 75" M ax load: 154lbs Mounting patterns: up to 600x400 Dimensions: H:52.8" W:26.5" D:29.6" BT8706 Max screen size: 75" M ax load: 154lbs Mounting patterns: up to 600x400 Dimensions: H:76.5" W:26.5" D:29.6" BT8709 Max screen size: 65" - 100" M ax load: 220lbs M ounting patterns: up to 900x800 Dimensions: H:76.5" W:44.4" D:29.6" BT8708 Max screen size: 65" - 100" M ax load: 310lbs M ounting patterns: up to 900x800 Dimensions: H:75.2" W:39.4" D:8.3" BT8546 Max screen size: 110" Max load: 275lbs M ounting patterns: up to 1000x800 Dimensions: H.65.3" W.49" D.29.8" BT8503 Max screen size: 60" Max load: 110lbs Mounting patterns: up to 800x600 Dimensions: H:76.4" W:44" D:30.8" BT7504 Max screen size: 55" Max load: 55lbs Mounting patterns: up to 400x400 Dimensions: H:47.6" W:30" D:18" BT8506 Max screen size: 65" - 120" Max load: 285lbs Mounting patterns: up to 1000x600 Dimensions: H:68" W:53" D:29" BT8707 Max screen size: 65" - 100" Max load: 440lbs Mounting patterns: up to 900x800 Dimensions: H:77.5" W:39.4" D:6.5" Tall This reference guide gives a quick overview of the B-Tech range of Flat Screen Floor Stands and Carts. For full specifications and to view all other products and accessories, please visit our website at www.btechavmounts.com Note, max screen sizes are recommendations only and it may be possible to mount other sizes, please refer to the screen's weight and mounting pattern to find the best compatible mount. Mobile Wall BT8517 For screen sizes: 65"- 75" M ax load: 220lbs per screen M ounting patterns: up to 1200x800mm Dimensions: H:78.75" W:96.5" D:37.4" BT8518 For screen sizes: 75"- 86" M ax load: 220lbs per screen M ounting patterns: up to 1200x800mm Dimensions: H:78.75" W:118.1" D:37.4" BT8415 For screen sizes: 39"- 46" M ax load: 154lbs per screen M ounting patterns: up to 400x400mm Distance from wall: 2.4" BT8416 For screen sizes: 46"- 65" Max load: 154lbs per screen M ounting patterns: up to 600x400mm Distance from wall: 2.4" BT8514 For screen sizes: 39"- 46" M ax load: 88lbs per screen Mounting patterns: up to 400x400 Dimensions: H:75" W:59.2" D:34" BT8516 For screen sizes: 46"- 65" M ax load: 154lbs per screen M ounting patterns: up to 600x400 Dimensions: H:75" W:78.9" D:39" XXL Motorized Touchscreen Floor Stands Freestanding BT8572 Max screen size: 55" M ax load: 88lbs M ounting patterns: up to 600x400 Dimensions: H:72" W:31.5" D:23.6" BT8571 Max screen size: 47" M ax load: 55lbs M ounting patterns: up to 200x200 Dimensions: H:72" W:27.5" D:20.3" BT8583 Max screen size: 75" M ax load: 154lbs M ounting patterns: up to 600x400 Dimensions: H:72.6" W:31.5" D:23.6" BT8581 Max screen size: 47" M ax load: 77lbs M ounting patterns: up to 200x200 Dimensions: H:72.6" W:27.5" D:20.3" BT8573 Max screen size: 75" M ax load: 154lbs M ounting patterns: up to 600x400 Dimensions: H:72" W:31.5" D:23.6" BT8582 Max screen size: 55" Max load: 88lbs Fits VESA patterns: up to 600x400 Dimensions: H:72.6" W:31.5" D:23.6" VC Shelf VC Shelf VC Shelf VC Shelf VC Shelf VC Shelf BT8558 Max screen size: 86" Max load: 220lbs Mounting patterns: up to 1000x600 Dimensions: H:43.5 - 69" W.42.75" D:32"
B-Tech AV Mounts 8 XX-Large Fixed Tilt Small Fixed Tilt Tilt & Swivel Single Arm X-Large Fixed Large Fixed Medium Fixed Tilt BT8421 Max screen size: 55" M ax load: 77lbs F its VESA patterns: up to 400x400 Distance from wall: 1.2" BT8441 Max screen size: 55" Max load: 176lbs Fits VESA patterns: up to 400x400 Distance from wall: 1.2" BTV510 Max screen size: 55" M ax load: 110lbs F its VESA patterns: up to 400x400 Distance from wall: 0.8" BT7510 Max screen size: 28" Max load: 44lbs Mounting patterns: 50x50, 75x75 & 100x100 Distance from wall: 0.6" BT7511 Max screen size: 28" M ax load: 44lbs Mounting patterns: 75x75 & 100x100 Tilt: +17/-10° BT7518 Max screen size: 28" M ax load: 44lbs Mounting patterns: 75x75 & 100x100 Tilt: +17/-10° Swivel: 50° Screen rotation: 360° BT8422 Max screen size: 80" M ax load: 154lbs Mounting patterns: up to 800x500 Distance from wall: 1.2" BT8442 Max screen size: 80" Max load: 176lbs Mounting patterns: up to 600x400 Distance from wall: 1.2" BTV520 Max screen size: 65" M ax load: 154lbs Mounting patterns: up to 800x500 D istance from wall: 0.8" BT8200 Max screen size: 47" Max load: 88lbs Mounting patterns: up to 200x200 Distance from wall: 0.5" BTV500 Max screen size: 47" M ax load: 88lbs Mounting patterns: up to 200x200 D istance from wall: 0.8" BT7523 Max screen size: 47" M ax load: 55lbs Mounting patterns: up to 200x200 Tilt: +/-15° BT7512 Max screen size: 28" M ax load: 33lbs Mounting patterns: 75x75 & 100x100 Tilt: +17/-10° Swivel: 180° Rotation: 360° Distance from wall: 3" - 11" BT9901 Max screen size: 65" - 100" Max load: 220lbs Mounting patterns: up to 900x600 Distance from wall: 1.2" BT9903 Max screen size: 65" - 120" M ax load: 440lbs Mounting patterns: up to 1000x600 D istance from wall: 1.4" BT9910 Max screen size: 65" - 100" M ax load: 285lbs Mounting patterns: up to 1000x600 Tilt: +15° BT7532 Max screen size: 47" Max load: 88lbs Mounting patterns: up to 200x200 Distance from wall: 0.6" Flat Screen Wall Mounts Quick Reference Guide
9 info@btechavmounts.com 9 Tilt Double Arm Single Arm Double Arm Double Arm BT7514 Max screen size: 47" M ax load: 55lbs Mounting patterns: up to 200x200 Tilt: +/-40° Swivel: 180° Distance from wall: 3.75" - 13.25" BT7515 Max screen size: 47" M ax load: 55lbs Mounting patterns: up to 200x200 Tilt: +/-40° Swivel: 180° Distance from wall: 3.75" - 20.5" BTV504 Max screen size: 47" M ax load: 55lbs Mounting patterns: up to 200x200 Tilt: +/-15° Swivel: 180° Screen rotation: 360° Distance from wall: 3" - 15" BT7513 Max screen size: 28" M ax load: 33lbs Mounting patterns: 75x75 & 100x100 Tilt: +17/-10° Swivel: 180° Screen rotation: 360° Distance from wall: 3.75" - 18.5" BT8431 Max screen size: 55" M ax load: 110lbs Mounting patterns: up to 400x400 Tilt: +/-15° BTV513 Max screen size: 55" Max load: 77lbs Mounting patterns: up to 400x400 Tilt: +10/-2° Swivel: 180° Distance from wall: 1.6" - 17.7" This reference guide gives a quick overview of the B-Tech range of Flat Screen Wall Mounts. To view the complete range, full specifications, product photos and technical drawings, please visit our website at www.btechavmounts.com Note, max screen sizes are recommendations only and it may be possible to mount other sizes, please refer to the screen's weight and mounting pattern to find the best compatible mount. Tilt Double Arm BT8432 Max screen size: 80" M ax load: 154lbs Mounting patterns: up to 600x400 Tilt: +/-15° Double Arm Fixed Pop-Out BT9920 Max screen size: 72" - 120" M ax load: 440lbs M ounting patterns: up to 1600x800mm D istance from wall: 2" BT9921 Max screen size: 72" - 120" Max load: 176lbs Mounting patterns: up to 1600x800mm Distance from wall: 4.5" - 10.6" BT8228 Max screen size: 65" - 120" M ax load: 275lbs Mounting patterns: up to 800x600mm Tilt: +15/-3 ° Swivel: 130° D istance from wall: 3.5" - 24.75" Pop-Out BT8226 Max screen size: 65" M ax load: 77lbs Mounting patterns: up to 600x400mm Tilt: +14°/-3° Swivel: 180° D istance from wall: 2" - 22.6" BT8237 Max screen size: 75" M ax load: 176lbs Mounting patterns: up to 600x400mm Swivel: 120° D istance from wall: 3" - 27.5" Medical Mounts Wall BT7592 Max screen size: 28" Max load: 7-11lbs Mounting patterns: 75x75 & 100x100 Tilt: +/-100 Swivel: 180° Screen rotation: 360° Extension: 65" BT7593 Max screen size: 28" M ax load: 11-18lbs Mounting patterns: 75x75 & 100x100 Tilt: +/-100 Swivel: 180° Screen rotation: 360° Extension: 65" VESA Adapters Adapters BT7540 Fits VESA patterns: 300x200 & 400x200 BT754 Fits VESA patterns: 200x100 & 200x200 BT7564 Fits VESA pattern: 600x400 BT7565 Fits VESA patterns: 900x400 & 800x400 BT7502 Fits VESA patterns: 200x100 & 200x200
B-Tech AV Mounts 10 Projector Mounts Ceiling Ceiling Mounts Ceiling BT7553 Max screen size: 32" Max load: 50lbs Mounting patterns: 75x75 & 100x100 Tilt: +90°/-15° Swivel / Screen Rotation: 360° BT8424 Max screen size: 65" Max load: 110lbs Mounting patterns: up to 600x400mm Tilt: +/-15° BT8426 Max screen size: 65" M ax load: 110lbs Mounting patterns: up to 600x400 T ilt: +/-15° BT8427 Max screen size: 75" M ax load: 154lbs Mounting patterns: up to 600x400 T ilt: up to +20° Swivel BT899XL M ax load: 55lbs Max fixing pattern: up to 19.5" Ceiling drop: 3.9" BT899XL-AD M ax load: 55lbs Max fixing pattern: up to 19.5" Ceiling drop: 28.7" - 44.4" BT899 Max load: 55lbs Max fixing pattern: up to 14.5" Ceiling drop: 4.8" BT899-AD M ax load: 55lbs Max fixing pattern: up to 14.5" Ceiling drop: 29.25" - 45" BT899-FD Max load: 55lbs Max fixing pattern: up to 14.5" Ceiling drop: 20"/40"/60"/80"/120" Adjustable Drop Adjustable Drop Adjustable Drop Adjustable Drop Media Storage Wall Mounts Wall Pull-Down AV Storage Slide-Out AV Storage BT7883 Max screen size: 46" - 75" Max screen weight: 154lbs Max equipment load: 22lbs Mounting patterns: 200x200 up to 600x400 BT7889 Max load: 22lbs Max AV equipment size: 17.7" x 11" BT7888 Max load: 22lbs Max AV equipment size: 17.7" x 9.8" BT7885 Max screen size: 49" - 86" Max screen weight: 154lbs Max equipment load: 18lbs Mounting patterns: 200x200 up to 600x400 AV Storage Slide-Out AV Storage Additional Mounting Solutions Quick Reference Guide Video Bar Mounts Video Bar Mounting Plates BT7871 Mounting Plate for Jabra Panacast 50 Poly Studio / X50 / X52 / X70 Lenovo ThinkSmart Bar 180 BT7873 Mounting Plate for Logitech Rally Bars BT7874 Mounting Plate for Dual Logitech Rally Plus Speakers Aver VB342PRO Cisco Webex Room Kit Plus BT7875 Mounting Plate for Yealink UVC40 / A20 / MeetingEye 400, Logitech Meet Up Poly Studio X30
11 info@btechavmounts.com 11 Ceiling Ceiling Speaker Mounts Wall Soundbar BT8428 Max screen size: 65" M ax load: 110lbs per screen Mounting patterns: up to 600x400 T ilt: +/-15° BT8448 Max screen size: 65" - 120" M ax load: 286lbs Mounting patterns: up to 1000x600 BT8449 Max screen size: 65" - 120" Max load: 176lbs Mounting patterns:up to 1000x600 T ilt: up to +15° BTV914 M ax load: 22lbs Height adjustable: 9.85" Lateral adjustable: 4.40" BT893-AD Max load: 154lbs Max fixing pattern: up to 31" Ceiling drop: 30.1" - 46.7" BT893-FD Max load: 154lbs Max fixing pattern: up to 31" Ceiling drop: 20"/40"/60"/80"/120" BT893 M ax load: 154lbs Max fixing pattern: up to 31" Ceiling drop: 6" Adjustable Drop BT899XL-FD M ax load: 55lbs Max fixing pattern: up to 19.5" Ceiling drop: 20"/40"/60"/80"/120" Back-To-Back XXL XXL Tilt BT332 M ax load: 11lbs T ilt: +/-20° S wivel: 180° BT77 M ax load: 55lbs T ilt: +/-10° S wivel: 360° A djustable clamp width: 5.3" - 11" BT15 Max load: 33lbs Adjustable arm length: 7" - 11" Side-Clamping Center Speaker This reference guide gives a quick overview of B-Tech's Additional Mounting Solutions, visit www.btechavmounts.com for full specifications. For unique & more complex installations, please see our Component Products from page 46 and see how custom solutions can be configured & ordered Video Bar Mounting Plates BT7876 Mounting Plate for Lenovo Google Series One Room Kits BT7877 Mounting Plate for Bose Videobar VB1 / VB-S Logitech Rally Plus Speakers, Neat.Bar / Neat.Bar Pro Yealink MspeakerII BT7878 Mounting Plate for Yealink A30 / MeetingEye 600 BT7879 Mounting Plate for Biamp Parlé Video & Audio Conferencing Bars / Speakers Levono ThinkSmart One
B-Tech AV Mounts 12 Menu Board & Videowall Mounts B-Tech is the go-to multi-screen mounting systems provider, favored by installers worldwide, thanks to a large selection of solutions that cover almost any requirement. Our modular mounting system for single rail menu board installations is suitable for screens of any size and can be configured for specific requirements using our System X component range. Mount multiple screens side-by-side with wall, ceiling, floor & curved solutions available. Screens can be mounted in landscape or portrait orientation with interface options that include fixed, tilt, or pop-out arms with micro-adjustment. This allows for precise alignment and a 'hassle-free' installation, perfect for fast-food restaurants, transport hubs, entertainment venues, etc. Back-to-back, floor-to-ceiling and floorto-wall options are also available using components from our System 2 range. For full product specifications, including technical drawings, scan the QR codes to view the online product page. Use our online configuration to specify your requirements. See page 18 for further details. Configurable solution available to order to your requirements from stock products Choice of fixed, tilt, micro-adjustment or pop-out interface arms Multiple rail & pole lengths available - can be cut or joined to any length Micro-adjustment arms allow tool-less adjustments for seamless display alignment Full-service options available - Pop-Out arms for easy service access or recess mounting Suitable for landscape or portrait mounting Lateral shift available for post-installation screen alignment Curved options available Safety screws help prevent unauthorized removal of screens Simple installation with all mounting hardware included Key Features Configure Online
13 info@btechavmounts.com 13 System X Menu Board Mounting Systems Max VESA Refers to maximum vertical fixing dimension. Correctly sized interface arms and adapters will be supplied as necessary to suit the mounting pattern you require. Single rail multi-screen installations. Available as wall or ceiling mounts. From stock and are ready to customize. Choice of Fixed, Tilt or Micro-Adjustment Interface Arms available. Choice Of Interface Arms Rails can be extended to any length. Customize rails to match the number of screens mounted. Rail Extension BT8332 Ceiling Mounted Menu Board Mounting System BT8333 Ceiling Mounted Curved Menu Board Mounting System Example X4 Screen Configuration BT8330 Menu Board Mounting System Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 BT8331 Pop-Out Menu Board Mounting System Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 Multiple pole lengths available for ceiling mounting. Choice of Ceiling Drops
B-Tech AV Mounts 14 Videowall Mounts B-Tech is the go-to multi-screen mounting systems provider, favored by installers worldwide, thanks to a large selection of solutions that cover almost any requirement. Our modular mounting system for multi-rail video wall installations are suitable for screens of any size and can be configured for specific requirements using our System X component range. Mount multiple screens side-by-side with wall, ceiling, floor and curved solutions available. There are various installation options for videowall stands include freestanding, mobile or bolt-down bases. Screens can be mounted in landscape or portrait orientation with interface arm options featuring micro-adjustment and wall mounted pop-out solutions, allowing for a precise alignment and a 'hassle-free' installation; perfect for retail environments, transport hubs, entertainment venues etc. Back-to-back, floor-to-ceiling and floor-to-wall options are also available using components from our System 2 range. For full product specifications including technical drawings scan the QR code for each product to view the online page. Configurable solution available to order to your requirements from stock products Choice of fixed, tilt, micro-adjustment or pop-out interface arms Multiple rail & pole lengths available - can be cut or joined to any length Micro-adjustment arms allow tool-less adjustments for seamless display alignment Full-service options available - Pop-Out arms for easy full service access or recess mounting Suitable for landscape or portrait mounting Lateral shift available for post-installation screen alignment Curved options available Safety screws help prevent unauthorized removal of screens Simple installation with all mounting hardware included Key Features Use our online configuration to specify your requirements. See page 18 for further details. Configure Online
15 info@btechavmounts.com 15 System X Videowall Mounting Systems Choice of Fixed, Tilt, or Micro-Adjustment interface arms, dependent on the type of installation required. Rails & poles can be cut & joined to create any length required. Multi screen, multi-rail installations. Available as wall or ceiling mounts. Customize or choose off-the-shelf kits. Pop-out interface arms available for full service access included as standard with BT8331 & BT8341 Pop-Out Arms for Service Access Multiple pole lengths available for ceiling mounting. Choice of Ceiling Drops Example 3X3 Screen Configuration BT8340 Videowall Mounting System BT8341 Pop-Out Videowall Mounting System BT8342 Ceiling Mounted Videowall Mounting System BT8343 Ceiling Mounted Curved Videowall Mounting System Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 Adjustable Angle for Curved Displays Integrated angle connector creates curved stands up to +/-45º
B-Tech AV Mounts 16 System X Videowall Mounting Systems Micro-Adjustment Tool-less micro-adjustments on interface arms for seamless screen alignment. BT8370 Videowall Stand Multi-screen installations available as wall, floor or ceiling mounts from stock & ready to customize. Example 2X2 Screen Configuration BT8371 Mobile Videowall Stand BT8372 Bolt-Down Videowall Stand BT8377 Bolt-Down Retractable Base Videowall Stand Custom Set-Ups Use our online configuration to specify your requirements. Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 Ideal for shop fronts, close-to-the-window installations. Retractable Base
17 info@btechavmounts.com 17 System X Videowall Mounting Systems Cable Management Integrated cable management featured for a tidy installation. Included on all System X stands. Multi-screen curved installations available as floor or ceiling mounts. Customize or choose off-the-shelf kits. Adjustable Angle for Curved Displays Integrated angle connector creates curved stands up to +/-45º BT8373 Curved Videowall Stand BT8374 Mobile Curved Videowall Stand BT8375 Bolt-Down Curved Videowall Stand BT8376 Freestanding Curved Videowall Stand Example 2X4 Screen Configuration Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 Recommended Max Screen Max Load Max VESA 75" 110lbs per screen 900 AV Accessory Component Shelves Fit AV accessories such as shelves directly to columns.
B-Tech AV Mounts 18 Screen Size please select Screens Per Row please select Column Height please select Number Of Rows please select Column Color please select Step 1: Go to www.btechavmounts.com Step 2: Select Wall, Ceiling or Floor Mounted Step 3: Select specifications from drop down boxes Fixed Pop-Out Tilt Micro Adjustment Configurations can be specified in just a few simple clicks. Start by choosing between wall or pole mounted options. Then, enter details about your screen size & the quantity to be installed, the orientation, the type of interface arm function such as tilt, fixed or micro-adjustment & pole length if required. Once complete, fill out your contact details, & we'll get in touch & give you a quote for your requested configuration. Freestanding Mobile Bolt-Down Floor Stands: Select Mobile, Freestanding or Bolt-Down www.btechavmounts.com/systemx-configurator Interface Function please select Menu Board & Videowall Online Configuration Tool
19 info@btechavmounts.com 19 For Wall, Ceiling & Floor Mounting Solutions Step 4: Select Additional Options: Curved installation Add option for a curved display Step 7: Request a quote for this configuration B-Tech Model: BT8340-Wl4x2-42-F Step 6: Configure your mounting solution System X Videowall mounting solutions Available in 1,000s of configurations including Fixed, Tilt or Pop-Out Step 5: Select desired orientation (Landscape, Portrait)
B-Tech AV Mounts 20 Modular Videowall Mounts Designed to make videowall installations as quick and straightforward as possible, these modular mounting solutions (one mount per screen) can create unlimited configurations in landscape and portrait formats. The push-in, pop-out opening enables access to the rear of the mounted screen for servicing and maintenance and the BT8312 features a patented soft opening mechanism for ultimate screen care. The low-profile designs are ideal for multi-screen installations and mounting into walls with a shallow recess. Micro-adjustment knobs make screen alignment quick and simple with keyholes added for easy wall mounting. For full product specifications, including technical drawings, scan the QR code for each product to view the online page. Modular mounts allow videowall assembly in an unlimited number of configurations Suitable for landscape or portrait screen mounting Pop-out systems provide easy service access Tool-less micro-adjustment for seamless display alignment Depth, height & lateral adjustments of the screen Slim designs ideal for low-profile installs on walls or mounting in shallow recesses Keyhole mounting for quick & easy installation Suitable for pole mounting using System 2 collars Integrated locking mechanism prevents accidental pop-out of mount Safety screws help prevent unauthorized removal of screens Screen-specific spacer kits are available for the BT8312 to speed up installation times Key Features
21 info@btechavmounts.com 21 Modular Videowall Mounts BT8312 Slimline Soft-Open Full Service Videowall Mount with 8-Point Micro-Adjustment Recommended Max Screen Max Load Max VESA 75" 110lbs 600 x 400 Recommended Max Screen Max Load Max VESA 120" 275lbs 600 x 400 BT8310XL Heavy-Duty Pop-Out Wall Mount with Micro-Adjustment BT8309 Pop-Out Wall Mount with Micro-Adjustment Recommended Max Screen Max Load Max VESA 42" 55lbs 200 Unlimited Configurations Our modular mounting system allows videowall assembly in an unlimited number of landscape or portrait configurations, from simple 2x2 videowalls to complex mosaic patterns. 8 points of micro-adjustment for depth, height and lateral screen adjustment. Pop-out systems provides safe and easy service access. Suitable for recess mounting. Micro-Adjustment Full Service Access Quick to install and easy to configure, designed specifically for videowall applications. One Mount Per Screen Patent N°: US 11,841,111B2 Wall Plate Spacer Kits aid speedy installations Also Available... MICRO ADJUSTMENT
B-Tech AV Mounts 22 dvLED Mounting Solutions Solutions available for all major brands, including: B-Tech are proud to have brought a range of solutions to market that are simple to specify and have fast turnaround times from off-the-shelf stock. Designed to work with all popular dvLED cabinets on the market, our dvLED mounting solutions can be specified to requirements using our online dvLED configuration tool. For ceilingmounted or curved installations, contact us directly. Most of our dvLED mounting solutions can be specified to requirements using our online dvLED configuration tool. For more bespoke and complex installations, contact us directly at technical@btechavmounts.com, and we'll be happy to configure a solution that suits your needs. In addition to our standard wall, floor, mobile, and ceiling mounts, our system can be used for more complex projects such as mounting to curved walls, in ceiling-to-floor/wall applications, or when cosmetic frames need to be added to hide the mounting structure. (If a brand is not shown, please check the B-Tech website for our latest listings)
23 info@btechavmounts.com 23 BT9340 Wall Mounted dvLED Videowall Mount BT9370 dvLED Videowall Stand BT9371 Mobile dvLED Videowall Stand BT9372 Bolt-Down dvLED Videowall Stand BT9377 Bolt-Down dvLED Videowall Stand with Retractable Base dvLED Mounting Solutions Floor Base with Level Adjustment Suitable for uneven floors. Depth & Height Adjustment Brackets Precision alignment on uneven surfaces. Retractable Floor Base 15.75" retraction allows easy access to the front of the panels. Ideal for shop window displays. Configure Online Use our online configuration to specify your requirements. Configure Online To assist with the precise installation of dvLED cabinets, a range of optional System X components featuring level, depth, height & angle adjustments have been designed to provide an exact & accurate mounting experience. Ideal for installations on uneven surfaces. Precise Adjustments BT9342 Ceiling Mounted dvLED Videowall Mount BT9344 Floor-To-Ceiling dvLED Videowall Mount
B-Tech AV Mounts 24 Solutions designed exclusively for Samsung's All-In-One Displays BT9370-SAM110 Freestanding Floor Stand for Samsung All-In-One 110" IAB Display BT9370-SAM130 Freestanding Floor Stand for Samsung All-In-One 130" IAC Display BT9370-SAM146 Freestanding Floor Stand for Samsung All-In-One 146" IAB Display All-In-One LED Mounting Solutions Absen All-In-One LED Mounts Samsung All-In-One LED Stands Screen Specific Mounting Solutions For All-In-One LED Displays To be used with Samsung provided brackets. Mounting solutions designed specifically for Absens iCon series All-In-One LED Screens, the range consists of wall mounted, freestanding, mobile & bolt down versions & all feature the same high-end aesthetic, anodized aluminum finish & integrated cable management, which ensures a smart & stylish installation. Mounting solutions available for all major brands of All-in-One displays Scan the QR code to view our exclusive to Absen Brochure. Absen Mounting solutions for: Mobile Wall Mounted Freestanding Bolt-Down
25 info@btechavmounts.com 25 Designs specifically for LG's LAEC015 136", LAEC018 163" & LAED015 171" All-In-One LED Screens, the range consists of freestanding, mobile & bolt down versions* and all feature the same high-end aesthetic, anodized aluminum finish and integrated cable management, which ensures a smart & stylish installation. *Wall mounted options also available on some models - see brochure for further details Freestanding Solutions BT83LAEC015-S Freestanding Floor Stand for LG LAEC015 136" Display BT83LG163-S Freestanding Floor Stand for LG LAEC018 163" Display BT83LG171-S Freestanding Floor Stand for LG LAEC015 171" 21:9 Display BT83LAEC015-M Mobile Floor Stand for LG LAEC015 136" Display BT83LG163-M Mobile Floor Stand for LG LAEC018 163" Display BT83LG171-M Mobile Floor Stand for LG LAEC015 171" 21:9 Display Mobile Solutions BT83LAEC015-B Bolt-Down Floor Stand for LG LAEC015 136" Display BT83LG163-B Bolt-Down Floor Stand for LG LAEC018 163" Display BT83LG171-B Bolt-Down Floor Stand for LG LAEC015 171" 21:9 Display Bolt-Down Solutions Scan the QR code to view our exclusive to LG Brochure. All-In-One LED Mounting Solutions Freestanding, Mobile and Bolt Down solutions for LG's 136", 163" and 171" All-In-One displays. LG All-In-One LED Stands
B-Tech AV Mounts 26 Specialist Mounts & Digital Signage Solutions With more screens featuring in retail environments than ever before, the need for a comprehensive range of specialist mounting solutions is apparent. In addition to videowalls, single screens (ranging from small to XXL) & specialist signage such as LG's XXL 110" displays, are being installed into retail outlets, conference rooms etc.. Our range of specialist mounting solutions includes various options catering to the applications often required: portrait mounts, pop-out options for recess mounting, rotational mounts for eye-catching displays and screen enclosures can also be customized to meet the installation requirements. For complete product specifications, including technical drawings scan the QR code for each product to view the online page. BT9920 Display Wall Mount for XXL Displays Ideal for LG's 110" 110UM5J-B Ideal for LG's 110" 110UM5J-B Recommended Max Screen Max Load Max VESA 120" 440lbs 1600 x 800 Wall mounts designed for XXL displays such as LG's 110UM5J. BT9921 Soft-Open Full Service Wall Mount for XXL Displays Recommended Max Screen Max Load Max VESA 120" 176lbs 1600 x 800
27 info@btechavmounts.com 27 Digital Signage Mounts Rotates and fixes to any angle between 0° & 90° BT7550 Rotational Flip Mount for Large Screens Recommended Max Screen Max Load Max VESA Tilt Rotation 400 65" 154lbs 4.5° 360° Allows mounted screens to rotate from landscape to portrait orientation or vice-versa Angle guides help set the rotation of the screen. BT8322 Portrait Digital Signage Wall Mount Portrait Wall Mounts Digital Signage Stands Recommended Max Screen Max Load Max VESA 65" 176lbs 400 x 600 BT9925 Soft-Open Full Service Portrait Wall Mount for XXL Displays Ideal for LG's 110" 110UM5J-B Recommended Max Screen Max Load Max VESA 120" 176lbs 800 x 1600 Pop-out, full service mounts are ideal for recessed walls. Retractable base provides easy access for shop fronts displays. BT8587 Bolt-Down Column Mounted Digital Signage Stand with Retractable Base Recommended Max Screen Max Load Max VESA 86" 154lbs 600 x 800
B-Tech AV Mounts 28 Flat Screen Wall Mounts B-Tech's comprehensive collection of professional wall and ceiling screen mounts cover fixed, tilt and full motion solutions for screens ranging from 10" to 120". Many features can be found on products throughout the range, including designs for making installation as straight forward as possible with keyhole fixings and On Wall Leveling available on selected mounts. Additionally, many of the wall mounts are compatible with the B-Tech's System 2 and System X modular ranges using accessory collars, which allow them to be used for pole/ column mounted applications. Note, max screen sizes are recommendations only and it may be possible to mount other sizes, please refer to the screen's weight and mounting pattern to find the best compatible mount. For the full range of flat screen mounts with full product specifications including technical drawings, scan the QR codes to view the online pages. Designed for an easy 1-2-3 step installation Mounts supplied pre-assembled Simple 'hook-on' screen mounting All mounting hardware included Suitable for landscape or portrait mounting Universal mounts feature lateral adjustment of the screen once mounted Brackets utilise various security features to prevents easy removal of the screen with safety screws or locking bar included Cover plates & cable management are included with swing arm mounts Key Features The VESA® Standard mounting patterns are the distance (in millimeters) between the four mounting holes on the back of a screen & are used by most TV brands.
29 info@btechavmounts.com 29 Recommended Max Screen Max Load Max VESA Tilt Swivel 65" 77lbs 600 x 400 Flat Screen Wall Mounts Utilize Accessory Collars for pole-mounting compatible screen mounts. BT8431 Wall Mount with Tilt Recommended Max Screen Max Load Max VESA Tilt 400 55" 110lbs 15° 15° BT8226 Double Arm Wall Mount with Tilt & Swivel 3° 14° 180° BT8228 Twin Cantilever Arm Wall Mount with Tilt & Swivel Recommended Max Screen Max Load Max VESA Tilt Swivel 120" 275lbs 3° 15° 130° 800 x 600 BT9903 Heavy-Duty Fixed Wall Mount for XL Screens Recommended Max Screen Max Load Wall Max Load Pole Max VESA 120" 440lbs 286lbs 1000 x 600 BT7518 Wall Mount with Tilt & Swivel Recommended Max Screen Max Load Max VESA Tilt Swivel Rotation 100 28" 44lbs 10° 17° 50° 360° BTV500 Fixed Wall Mount Recommended Max Screen Max Load Max VESA 200 47" 88lbs Compatibility with B-Tech Component Ranges Many of the wall mounts featured in this catalog are compatible with System 2 accessory collars for pole mounting or can be fitted directly onto System X columns. Collar Compatible The recommended screen size encompasses the maximum dimensions suitable for each mounting bracket. View the online specification sheets for recommended minimum screen sizes.
B-Tech AV Mounts 30 Flat Screen Ceiling Mounts With options for fixed or tool-less adjustable drops, installations onto flat or angled ceilings, and landscape & portrait mounting, B-Tech offer a vast array of ceiling mounting solutions; additional options are also available by using System 2 parts to create custom solutions. These include joiners to extend pole lengths & specialist mounts for fixing joists, purlins, I-beams, etc. See page 52 for information about creating custom mounting solutions. for full specifications, scan the QR code to visit the online product page. B-Tech has a wide range of screen ceiling mounting kits available for small to XXL screens. Key Features � Mounts are available with either a fixed drop or with a tool-less adjustment of the drop � Unique 'Torsion-tilt' mechanism for tilt adjustment on a selection of mounts � Suitable for landscape or portrait mounting � Lateral adjustment of the screen once mounted � Arms feature adjustment screws to help level the screen height � Security screws help prevent unauthorized removal of screens � Integrated cable management � Cover plate included for a smart installation � Simple 'hook-on' installation with all mounting hardware included � For more custom installations, see our System 2 range of components
31 info@btechavmounts.com 31 Flat Screen Ceiling Mounts BT8427 Adjustable Drop Ceiling Mount with Tilt Recommended Max Screen Max Load Max VESA Tilt 75" 154lbs 20° 600 x 400 60" Pole BT8428-150 80" Pole BT8428-200 40" Pole BT8428-100 BT8428-300 120" Pole Available in 4 pole lengths BT8428 Back-To-Back Ceiling Mount with Tilt Recommended Max Screen Max Load Max VESA Tilt 65" 15° 600 x 400 15° 110lbs per screen 60" Pole BT8448-150 80" Pole BT8448-200 40" Pole BT8448-100 BT8448-300 120" Pole Available in 4 pole lengths BT8448 XL Display Ceiling Mount Recommended Max Screen Max Load Max VESA 120" 1000 x 600 286lbs Available with a choice of ceiling drops: 20", 40", 60", 80" & 120" Fixed Ceiling Drops Adjustable Ceiling Drop Tool-Less height adjustment in 1" increments. BT7553 Ceiling Mount with Tilt & Swivel 20" Pole BT7553-050 40" Pole BT7553-100 BT7553-150 60" Pole BT7553-200 80" Pole Available in 4 pole lengths Recommended Max Screen Max Load Max VESA Tilt Swivel Rotation 100 28" 50lbs 15° 90° 360° 360°
B-Tech AV Mounts 32 Floor Stands & Mobile Solutions Our durable and stylish carts and floor stands cater to diverse markets needing flexible display options. The range features options for mounting all display sizes, including heavy-duty interactive touchscreens, in landscape and portrait orientations. Additionally, we offer a comprehensive range of freestanding floor stands, starting from low-profile bases to standard kits with 02" poles and more stylish options with aluminum columns. These kits can be customized to fit your installation requirements. For heavier-duty needs, our System X range of components supports multiple screens. Scan the QR codes to explore the complete range with detailed product specifications and technical drawings online. Universal designs suitable for displaying screens in a landscape or portrait orientation Non-marking locking / braked casters included with mobile display carts Collar compatible accessories such as shelves (available separately) can be fitted to the column or pole Integrated cable management for a smart installation Interface arms include adjustment screws to help level the height of the screen Safety screws help prevent unauthorized removal of screen Simple 'hook-on' screen installation with all mounting hardware included Key Features
33 info@btechavmounts.com 33 Flat Screen Floor Stands BT8572 Large Flat Screen Single Pole Floor Stand Recommended Max Screen Max Load 55" 88lbs Max VESA 600 x 400 BT8583 Large Flat Screen Twin Column Floor Stand Recommended Max Screen Max Load 75" 154lbs Max VESA 600 x 400 BTF840 Flat Screen Floor Stand Recommended Max Screen Max Load 75" 154lbs Max VESA 600 x 400 Single and twin pole options available. Single and twin column options available. Accessorize with component shelves - See page 41 Dual stack stands available for landscape or portrait mounting.
B-Tech AV Mounts 34 Flat Screen Carts BT7504 Flat Screen Cart Recommended Max Screen Max Load Max VESA 47" 55lbs 200 BT8503 Flat Screen Cart / Stand Recommended Max Screen Max Load Max VESA 60" 110lbs 800 x 600 BT8506 Flat Screen Cart / Stand for XL Screens Recommended Max Screen Max Load Max VESA 120" 286lbs 1000 x 600 Suitable for landscape & portrait mounting. Accessorize with AV shelves. Non-marking Braked Castors included with all carts. Use BT7841 Accessory Collars (not included) to retrofit shelves onto existing installations. Adjustable leveling feet included with standard carts BT8503 & BT8506.
