UC/VC Video Bar & Camera Mounting Solutions www.btechavmounts.com
B-Tech AV Mounts 2 UC / VC Video Bar & Camera Mounts B-Tech’s reputation as the go-to brand for professional AV mounting solutions is built off the back of our huge range of specialist solutions for each area of industry. Our suite of mounts for the VC/UC space is no exception and we have designed and manufactured a range of mounting plates and adaptors designed specifically to mount Video Bars, Soundbars, VC cameras and a range of other devices. These are all available from stock and can be fitted to a wide selection of B-Tech wall mounts, stands and trolleys. With options to fit the device above or below the display, end users will experience a robust, yet flexible mounting solution to suit their conferencing needs and the installation process will be smooth and hassle-free for the integrator. Solutions available for all major brands, including: For the most up-to-date brand listings visit B-Tech's website or contact us at technical@btechavmounts.com
33 info@btechavmounts.com UC / VC Video Bar & Camera Mounts Position Above Or Below A Wall Mounted Screen Using A BT7031 Mounting Arm Mount Onto A BT8390 System X Rail Using A BT8390-SA Mounting Arm Mount To A Ø50mm Pole Using A B-Tech Accessory Collar (BT7052 / BT7841) Mount Directly To B-Tech Columns (BT8380 / BT8381) Install the video bars on existing B-Tech flat screen mounts above or below the screen using adjustable accessory mounting arms, collars for pole mounting or fix directly onto columns.
B-Tech AV Mounts 4 Video Bar & Camera Mounts BT7871 Mounting Plate for Jabra Panacast 50, Poly Studio / X50 / X52 / X70 & Lenovo ThinkSmart Bar 180 BT7873 Mounting Plate for Logitech Rally Bars BT7874 Mounting Plate for Dual Logitech Rally Plus Speakers, Aver VB342PRO & Cisco Webex Room Kit Plus BT7875 Mounting Plate for Yealink UVC40 / A20 / MeetingEye 400, Logitech Meet Up & Poly Studio X30 Mounts to columns, rails, poles & screen mounts BT7876 Mounting Plate for Lenovo Google Series One Room Kits Mounts to the rear of the screen Max Load 3kg Max Load 8kg Max Load 5kg Max Load 4kg Max Load 10kg
55 info@btechavmounts.com Video Bar & Camera Mounts Video Bar Mounts Model Number Video Bar / Camera Max Load System X Compatible System 2 Compatible Dimensions BT7871 Jabra Panacast 50, Poly Studio / X50 / X70 Lenovo ThinkSmart 180 3kg 185mm x 75mm BT7873 Logitech Rally Bar / Rally Bar Mini 8kg 440mm x 30mm BT7874 Logitech Rally Plus / Aver VB342PRO / Cisco Webex Room Kit Plus 5kg 740mm x 30mm BT7875 Yealink UVC40 / A20 / MeetingEye 400 / Logitech MeetUp / Poly Studio X30 4kg 90mm x 63mm x 60mm BT7876 Lenovo Google Series One Medium Room, Google Series One Large Room Kits 10kg N/A N/A 1506mm - 449mm BT7877 Neat Bar / Neat Bar Pro / Bose Videobar VB1 & VB-S / Yealink MspeakerII / Logitech Rally Plus Speakers (x2 pcs) 3kg 250mm x 40mm BT7878 Yealink A30 / Yealink MeetingEye 600 4kg 100mm x 103mm x 70mm BT7879 Biamp Parlé VBC / ABC 2500 / SBC 2 Lenovo ThinkSmart One 5kg 565mm x 70mm BT7877 Mounting Plate for Bose Videobar VB1 / VB-S, Logitech Rally Plus Speakers, Neat.Bar, Neat.Bar Pro & Yealink MspeakerII BT7878 Mounting Plate for Yealink A30 / MeetingEye 600 BT7879 Mounting Plate for Biamp Parlé Video & Audio Conferencing Bars / Speakers & Levono ThinkSmart One Max Load 3kg Max Load 4kg Max Load 5kg
B-Tech AV Mounts 6 Typical Installations A video bar mounting plate can attach directly to a B-Tech column (BT8380 / BT8381*). Ideal for use on System X and Designer Trolleys and floor stands. *Use a BT8385-RTC when mounting to a Mode-AL BT8385 column. Column Mounting Rail Mounting A video bar mounting plate can be mounted onto a rail using an Adjustable Accessory Mounting Arm (BT8390-SA), and can be positioned above or below the screen(s). Ideal for any System X or Mode-AL products that feature a BT8390 mounting rail. Pole Mounting A video bar mounting plate can be fixed to a Ø50mm Pole using a B-Tech Accessory Collar (BT7052 / BT7841*). Ideal for ceiling mounts or on pole mounted floor stands and trolleys. *Use a BT7841 2-Piece Accessory Collar to retro fit video bar onto an existing installation No additional product required - fit direct to column Use BT8390-SA
77 info@btechavmounts.com AV Storage Mounting A video bar mounting plate can mounted onto a B-Tech flat screen wall mount with slideout / pull-down AV storage tray (BT7883 / BT7885) using an BT7034 adjustable accessory mounting arm. AV storage trays are a convenient way of storing AV equipment behind the display and out of sight. Mode-Al Mounting A video bar mounting plate can be attached to a Mode-AL stand using a BT8390-SA mounting arm to hook onto the rail or by using a BT8385-RTC plate to fix on to the column (BT8385). All mounting arms can be installed to mount the video bar above or below the screen. Use a BT8385-RTC for column mounting... ...or a BT8390-SA for rail mounting Flat Screen Mounting A video bar mounting plate can be mounted onto compatible flat screen mount* using a BT7031 adjustable accessory mounting arm. Use mounting arms on trolleys / stands when mounting onto a column / pole is not an option. * ** Compatible Flat Screen Wall Mounts: BT8431 / BT8432 / BT8441 / BT8442 / BT9901 / BT9903 The BT7031 mounting arm can also be used on trolleys, stands and ceiling mounts that feature any of the above flat screen mounting plates in place of a rail. Use BT7034 Use BT7031 Typical Installations
B-Tech AV Mounts 8 Brand Video Bar Model Video Bar Mounting Plate Aver VB342PRO BT7874 Biamp Parlé VBC 2500 / 2500A Parlé ABC 2500 / 2500A / SBC 2 BT7879 Bose Videobar VB1 Bose Videobar VB-S BT7877 Cisco Webex Room Kit Plus Cisco Quad Camera BT7874 Jabra Panacast 50 BT7871 Lenovo Google Series One Medium Room, Lenovo Google Series One Large Room Kits BT7876* *Mounts directly tothe back of the screen Lenovo ThinkSmart Bar 180 BT7871 Logitech Rally Bar Logitech Rally Bar Mini BT7873 Logitech Rally Plus BT7874 Logitech MeetUp BT7875 Logitech Rally Plus Speakers BT7877 (x2 pcs) Neat Bar Neat Bar Pro BT7877 Poly Studio Poly Studio X50 Poly Studio X52 Poly Studio X70 BT7871 Poly Studio X30 BT7875 Yealink A10 / UVC34 Yealink UVC40 Yealink A20 Yealink MeetingEye 400 BT7875 Yealink MspeakerII BT7877 Yealink A30 Yealink MeetingEye 600 BT7878 Video Bars Compatibility Chart
99 info@btechavmounts.com Mount To Available Products Adaptor Needed To Use Video Bar Mounting Plate Wall Mount BT8431 - Single screen BT7031 BT8432 - Single screen BT8441 - Single screen BT8442 - Single screen BT9901 - Single screen BT9903 - Single screen BT7883 - Single screen & storage BT7034 BT7885 - Single screen & storage BT8415 - VC twin screen BT8390-SA BT8416 - VC twin screen BT8562 - Single screen NOT REQUIRED** Trolley BT8504 - Single screen BT7031 BT8506 - Single screen BT8564* - Single screen BT8568 - Single screen, motorised BT8511 - VC twin screen BT8390-SA BT8514 - VC twin screen BT8516 - VC twin screen BT8517 - VC twin screen BT8518 - VC twin screen BT8590 - Single screen Stand BT8570 - Single screen BT7052 OR BT7841 BT8571 - Single screen BT8572 - Single screen BT8573 - Single screen BT7031 BT8569 - Single screen, motorised BT8521 - VC twin screen BT8390-SA BT8528 - VC twin screen BT8538 - VC twin screen BT8581 - Single screen NOT REQUIRED** **Mounting plate can be fixed directly to the column. BT7031 adaptor arm maybe required if mounting the video bar above the screen. BT8582 - Single screen BTF840 - Single screen BTF841 - Dual stacked screen BTF842 - Dual stacked screen BTF843 - Single screen BTF845 - VC twin screen BT8700 - Single screen BT8390-SA BT8701 - Single screen BT8702 - Single screen BT8703 - Single screen BT8704 - Single screen BT8705 - Single screen BT8706 - Single screen BT8583* - Single screen BT7031 BT8707 - Single screen BT8390-SA BT8708 - Single screen BT8709 - Single screen BT8710 - VC twin screen BT8711 - VC twin screen BT8712 - VC twin screen Video Bars Mounting Options BT7031 Mounting Arm BT8390-SA Mounting Arm BT7034 Mounting Arm BT7052 or BT7841 Accessory Collar Not Required Fit Straight To Column *BT8564 & BT8583 have twin columns that allow BT7873 & BT7874 to be mounted without an adaptor Adaptor Usage Examples All can mount video bar above or below screen (example shows BT7877)
B-Tech AV Mounts 10 Brand Video Bar Model Number Mounting Plate Ref Aver VB342PRO BT7874 Biamp Parlé VBC 2500 / 2500A / ABC 2500 / 2500A / SBC 2 BT7879 Bose Videobar VB1 Bose Videobar VB-S BT7877 Cisco Webex Room Kit Plus Cisco Quad Camera BT7874 Jabra Panacast 50 BT7871 Lenovo Google Series One Medium Room Lenovo Google Series One Large Room Kits BT7876 Lenovo ThinkSmart Bar BT7871 Logitech Rally Bar Logitech Rally Bar Mini BT7873 Logitech Rally Plus BT7874 Logitech MeetUp BT7875 Logitech Rally Plus Speakers BT7877 (x2 pcs) Neat Bar Neat Bar Pro BT7877 Poly Studio Poly Studio X50 Poly Studio X52 Poly Studio X70 BT7871 Poly Studio X30 BT7875 Yealink A10 / UVC34 Yealink UVC40 Yealink A20 Yealink MeetingEye 400 BT7875 Yealink MspeakerII BT7877 Yealink A30 Yealink MeetingEye 600 BT7878 Video Bar Component Mounting Guide Step 1 Choose Video Bar Mount Video Bar Mounting Compatibility Table Step 2 Choose Mounting Accessory Collars BT7841 BT7052 BT7034 BT7031 BT8390-SA BT7878 BT7879 BT7876 BT7875 BT7874 BT7873 BT7871 BT7877 Video Bar Mounting Plates Mounts directly to the back of the screen Mounting Arms
1 11 1 info@btechavmounts.com 11 Install the video bars onto existing B-Tech mounting kits or create a mounting solution from scratch using B-Tech's component ranges. Mount the video bar/camera above or below the screen using adjustable mounting arms, collars for pole mounting or fix directly onto columns. Solutions for floor, wall and ceiling mounting available for most manufacturers. Step 3 Choose Pole / Rail Or Screen Mount Poles Flat Screen Mounts AV Storage Mounts Example Installations Mounting Rails BT7883 BT8431 I BT8432 I BT8441 I BT8442 I BT9901 I BT9903 BT7885 BT8380-180 BT8381 BT8390 BT8385 BT8385-RTC BT4107 I BT4116 I BT4118 Columns BT7850 Column Mounting Pole Mounted Rail Mounting Flat Screen Mounting Flat Screen AV Storage Wall Mounting Screen Mounting
© 2024 January B-Tech AV Mounts Corporation Ltd., All rights reserved. The information in this catalogue reflects the current technical specifications at the time of print. We reserve the right to change the technical or physical specifications without prior notice. System X, System 2 & System V are trademarks of B-Tech AV Mounts Corporation Ltd., B-Tech AV Mounts, the B-Tech logo, Ventry & Mode-AL are all registered trademarks. All B-Tech images & symbols are exclusive property of B-Tech AV Mounts Corporation Ltd. All other brands & products are trademarks of their respective owners. B-Tech accept no liability for loss or damage caused by improper installation or mounting on unstable structures. E&OE. Designed & Engineered in the UK www.globalmountsgroup.com VBCA-2024-V1-201223-ENG B-Tech AV Mounts is part of the www.btechavmounts.com info@btechavmounts.com United Kingdom +44 (01327 300 787 uk@btechavmounts.com Singapore +65 3159 1604 apac@btechavmounts.com Belgium +32 (0)2 720 9271 europe@btechavmounts.com China (+86) 574 8810 3861 china@btechavmounts.com Germany +49 (0)3322 50 792 50 dach@btechavmounts.com South Korea +82 (0) 2 862 3165 korea@btechavmounts.com Spain +34 93 640 24 79 iberia@btechavmounts.com Vietnam +84 (0)24 3201 3418 vietnam@btechavmounts.com MEAI +65 3159 1604 meai@btechavmounts.com Americas +1 888 792 8188 americas@btechavmounts.com For full details of all B-Tech offices, please visit www.btechavmounts.com/contact-us or scan here: UC/VC Video Bar & Camera Mounting Solutions
