ABOUT B-TECH AV MOUNTS B-Tech AV Mounts is an industry-leading brand of professional AV mounting solutions recognised worldwide for our reliability, robustness, ease of installation and design aesthetics. Our full range of mounting solutions covers all AV mounting requirements ranging from small, single screens to large format displays, projectors, speakers, interactive touchscreens and UC equipment, multiscreen videowalls, digital signage and, of course, our ever-growing range of Award-winning dvLED mounting solutions available as off-the-shelf kits for the most popular configurations or configured to specific requirements using our online configuration tool. Working closely with Sony, B-Tech has developed a range of dvLED solutions designed for use with Sony’s Crystal LED Series. Utilising B-Tech’s renowned System X technology has allowed us to create a range using off-the-shelf components, enabling solutions to be packaged and shipped promptly, with our engineers pre-assembling all key components to save installers valuable on-site time. Solutions include wall-mounted, mobile, fixed base and freestanding options, and can be ordered in black or silver finish. The range has been developed for the most popular dvLED configurations from 4x4 up to 8x8, but we can also provide solutions for all other configurations. Most requirements can be specified using our online dvLED configuration tool. For more bespoke and more complex installations, contact us directly at technical@ btechavmounts.com and we’ll be happy to configure a solution that suits your needs. In addition to our standard wall mounts and floor stands, our system can be used for more complex projects such as mounting to ceilings, curved walls, in ceiling-to-floor or ceiling-to-wall applications. Another customisation option that we can provide are cosmetic cover panels to hide the mounting structure if required. B-TECH AV MOUNTS · EST.1972 Premium super-size images, even in bright environments BH-series From corporate entrances and lobbies to retail showrooms - the BH-series delivers impressively big, bright images bursting with rich vibrant colour, even in brightly-lit spaces. Harnessing latest advance in Sony’s high-efficiency LED driver technology, the BHseries fills the room with an extraordinary 1,700 cd/m² of brightness. It’s complimented by an anti-reflection coating on each display panel that prevents ambient light bounce-back under harsh illumination or sunlight. It all adds up to a phenomenal viewing experience that your audience wont forget. Immersive visual experiences with more depth and colour CH-series Two secrets of creating truly immersive images are bright, vibrant colours and deep black levels that bring more contrast, depth and texture to faces and other on-screen objects. In addition huge black area in display by using super fine LED, the CH-series uses Sony’s unique Deep Black Coating surface technology enabling our crystal LED displays to achieve outstanding black levels - superior to other high-end LED video walls. Coupled with the display’s extra wide colour gamut, audiences will love being pulled into richly immersive images. B-Tech AV Mounts 2 SONY CRYSTAL LED COMPATIBILE MOUNTING SYSTEMS
There are actually over 2000 different configurations of dvLED available! Visit our online configuration tool to specify setups with different options such as screen size, orientation and leg height. Try now at: www.btechavmounts.com/led-panel-configurator ALTERNATIVE CONFIGURATIONS BT9340-SON-CRY Wall Mounted dvLED Solution pg.4-5 BT9370-SON-CRY Freestanding dvLED Solution pg.6-7 BT9371-SON-CRY Mobile dvLED Solution pg.8-9 BT9372-SON-CRY Bolt-Down dvLED Solution pg.10-11 ABOUT B-TECH AV MOUNTS / SONY CRYSTAL LED pg.2 33 info@btechavmounts.com CONTENTS
Enter your configuration online to generate an order ref & we will email you your quotation The BT9340-SON-CRY is a wall-mounted solution suitable for Sony Crystal LED panels. As part of B-Tech's System X range of configurable dvLED mounting solutions, it is available to order as off-the-shelf solutions in a range of common configurations (from 4x4 up to 8x8) including those that match Sony's "softbundle" 138" and 220" display dvLED kits. B-Tech's online dvLED configuration tool allows alternative configurations to be specified online and promptly quoted, with orders fulfiled within a short lead time thanks to our extensive collection of stocked B-Tech components. FEATURES DIRECT VIEW LED VIDEOWALL WALL MOUNT BT9340-SON-CRY Pre-configured 4x4, 5x5, 6x6, 7x7 and 8x8 mounting kits available 5x5 and 8x8 kits are designed for Sony's 138" and 220" "soft bundles" Close to the wall install Simple 'hook-on' installation Bespoke configurations are also available to order to your requirements Assembled from off-the-shelf components for fast order fulfilment Online configuration tool for quick turnaround of quotes System can be extended to any required width for large installations Open frame allows panel access for easy servicing and maintenance Pre-assembly of major parts for quick and easy installation All mounting hardware included *Hybrid mounting options allow for rear mounted fixings if required CONFIGURE AS REQUIRED CONFIGURE ONLINE SPECIFICATIONS Compatible Panels ZRD-BH15D / ZRD-CH15D / ZRD-BH12D / ZRD-CH12D Panel fixing method Front mounted* Colour Black For indoor use only B-Tech AV Mounts 4 SONY CRYSTAL LED VIDEOWALL MOUNT
CONFIGURATIONS PRODUCT CODE 4x4 BT9340-FM-4X4-SON-CRY-ZRD 5x5 BT9340-FM-5X5-SON-CRY-ZRD BT9340-FM-5X5-SON-CRY-ZRK-138 6x6 BT9340-FM-6X6-SON-CRY-ZRD 7x7 BT9340-FM-7X7-SON-CRY-ZRD 8x8 BT9340-FM-8X8-SON-CRY-ZRD BT9340-FM-8X8-SON-CRY-ZRK-220 SUITABLE FOR SONY 138" BUNDLE SUITABLE FOR SONY 220" BUNDLE 55 info@btechavmounts.com SONY CRYSTAL LED VIDEOWALL MOUNT
B-Tech AV Mounts 6 The BT9370-SON-CRY is a freestanding solution suitable for Sony Crystal LED displays. As part of B-Tech's System X range of configurable dvLED mounting solutions, it is available to order as off-the-shelf solutions in a range of common configurations (from 4x4 up to 8x8) including those that match Sony's "softbundle" 138" and 220" display LED kits. B-Tech's online dvLED configuration tool allows alternative configurations to be specified online and promptly quoted, with orders fulfiled within a short lead time thanks to our extensive collection of stocked B-Tech components. FEATURES FREESTANDING DIRECT VIEW LED VIDEOWALL STAND BT9370-SON-CRY Pre-configured 4x4, 5x5, 6x6, 7x7 and 8x8 mounting kits available 5x5 and 8x8 kits are designed for Sony's 138" and 220" "soft bundles" Floor base utilises adustable levelling feet, ideal for uneven surfaces Simple 'hook-on' installation Bespoke configurations are also available to order to your requirements Assembled from off-the-shelf components for fast order fulfilment Online configuration tool for quick turnaround of quotes System can be extended to any required width for large installations Open frame allows panel access for easy servicing and maintenance Pre-assembly of major parts for quick and easy installation All mounting hardware included CONFIGURE AS REQUIRED Enter your configuration online to generate an order ref & we will email you your quotation *Hybrid mounting options allow for rear mounted fixings if required CONFIGURE ONLINE SPECIFICATIONS Compatible Panels ZRD-BH15D / ZRD-CH15D / ZRD-BH12D / ZRD-CH12D Panel fixing method Front mounted* Colour Black For indoor use only SONY CRYSTAL LED FREESTANDING VIDEOWALL STAND
CONFIGURATIONS PRODUCT CODE 4x4 BT9370-FM-4X4-SON-CRY-ZRD 5x5 BT9370-FM-5X5-SON-CRY-ZRD BT9370-FM-5X5-SON-CRY-ZRK-138 6x6 BT9370-FM-6X6-SON-CRY-ZRD 7x7 BT9370-FM-7X7-SON-CRY-ZRD 8x8 BT9370-FM-8X8-SON-CRY-ZRD BT9370-FM-8X8-SON-CRY-ZRK-220 SUITABLE FOR SONY 138" BUNDLE SUITABLE FOR SONY 220" BUNDLE 77 info@btechavmounts.com SONY CRYSTAL LED FREESTANDING VIDEOWALL STAND
*Hybrid mounting options allow for rear mounted fixings if required B-Tech AV Mounts 8 SONY CRYSTAL LED MOBILE VIDEOWALL STAND The BT9371-SON-CRY is a mobile mounting solution suitable for Sony Crystal LED displays. As part of B-Tech's System X range of configurable dvLED mounting solutions, it is available to order as off-the-shelf solutions in a range of common configurations (from 4x4 up to 8x8) including those that match Sony's "softbundle" 138" and 220" display LED kits. B-Tech's online dvLED configuration tool allows alternative configurations to be specified online and promptly quoted, with orders fulfiled within a short lead time thanks to our extensive collection of stocked B-Tech components. FEATURES MOBILE DIRECT VIEW LED VIDEOWALL STAND BT9371-SON-CRY Pre-configured 4x4, 5x5, 6x6, 7x7 and 8x8 mounting kits available 5x5 and 8x8 kits are designed for Sony's 138" and 220" "soft bundles" Non-marking braked castors allow for convient maneuverability Simple 'hook-on' installation Bespoke configurations are also available to order to your requirements Assembled from off-the-shelf components for fast order fulfilment Online configuration tool for quick turnaround of quotes System can be extended to any required width for large installations Open frame allows panel access for easy servicing and maintenance Pre-assembly of major parts for quick and easy installation All mounting hardware included CONFIGURE AS REQUIRED Enter your configuration online to generate an order ref & we will email you your quotation CONFIGURE ONLINE SPECIFICATIONS Compatible Panels ZRD-BH15D / ZRD-CH15D / ZRD-BH12D / ZRD-CH12D Panel fixing method Front mounted* Colour Black For indoor use only
CONFIGURATIONS PRODUCT CODE 4x4 BT9371-FM-4X4-SON-CRY-ZRD 5x5 BT9371-FM-5X5-SON-CRY-ZRD BT9371-FM-5X5-SON-CRY-ZRK-138 6x6 BT9371-FM-6X6-SON-CRY-ZRD 7x7 BT9371-FM-7X7-SON-CRY-ZRD 8x8 BT9371-FM-8X8-SON-CRY-ZRD BT9371-FM-8X8-SON-CRY-ZRK-220 SUITABLE FOR SONY 138" BUNDLE SUITABLE FOR SONY 220" BUNDLE 99 info@btechavmounts.com SONY CRYSTAL LED MOBILE VIDEOWALL STAND
B-Tech AV Mounts 10 SONY CRYSTAL LED BOLT-DOWN VIDEOWALL STAND The BT9372-SON-CRY is a bolt-down mounting solution suitable for Sony Crystal LED displays. As part of B-Tech's System X range of configurable dvLED mounting solutions, it is available to order as off-the-shelf solutions in a range of common configurations (from 4x4 up to 8x8) including those that match Sony's "softbundle" 138" and 220" display LED kits. B-Tech's online dvLED configuration tool allows alternative configurations to be specified online and promptly quoted, with orders fulfiled within a short lead time thanks to our extensive collection of stocked B-Tech components. FEATURES BOLT-DOWN DIRECT VIEW LED VIDEOWALL STAND BT9372-SON-CRY Pre-configured 4x4, 5x5, 6x6, 7x7 and 8x8 mounting kits available 5x5 and 8x8 kits are designed for Sony's 138" and 220" "soft bundles" Small footprint ideal for retail applications where floor space is limited Simple 'hook-on' installation Bespoke configurations are also available to order to your requirements Assembled from off-the-shelf components for fast order fulfilment Online configuration tool for quick turnaround of quotes System can be extended to any required width for large installations Open frame allows panel access for easy servicing and maintenance Pre-assembly of major parts for quick and easy installation All mounting hardware included CONFIGURE AS REQUIRED Enter your configuration online to generate an order ref & we will email you your quotation *Hybrid mounting options allow for rear mounted fixings if required CONFIGURE ONLINE SPECIFICATIONS Compatible Panels ZRD-BH15D / ZRD-CH15D / ZRD-BH12D / ZRD-CH12D Panel fixing method Front mounted* Colour Black For indoor use only
CONFIGURATIONS PRODUCT CODE 4x4 BT9372-FM-4X4-SON-CRY-ZRD 5x5 BT9372-FM-5X5-SON-CRY-ZRD BT9372-FM-5X5-SON-CRY-ZRK-138 6x6 BT9372-FM-6X6-SON-CRY-ZRD 7x7 BT9372-FM-7X7-SON-CRY-ZRD 8x8 BT9372-FM-8X8-SON-CRY-ZRD BT9372-FM-8X8-SON-CRY-ZRK-220 SUITABLE FOR SONY 138" BUNDLE SUITABLE FOR SONY 220" BUNDLE 1 11 1 info@btechavmounts.com SONY CRYSTAL LED BOLT-DOWN VIDEOWALL STAND
