www.btechavmounts.com Mobile Mounting Solutions
B-Tech AV Mounts 2 Mobile Mounting Solutions B-TECH MOBILE MOUNTING SOLUTIONS Momentum mobile mounting solutions are a modern, durable and easy-to-use range of trolleys and floor-to-wall stands designed support displays from 32" to 120". The trolleys' braked castors provide smooth, safe mobility, while the sturdy design ensures stable use, preventing unintended movement, essential when using interactive screens. Capable of holding heavy loads and with multiple screen mounting heights available, this versatile range can also be accessorised with AV equipment such as component shelves and video bars. The Momentum range is ideal for both installers and end users, delivering flexibility and high performance across a range of applications.
info@btechavmounts.com 3 Mobile Mounting Solutions Flat Screen Display Trolleys pg.4-5 Interactive Touchscreen Trolleys pg.6-7 Motorised Height Adjustable Trolleys pg.8-9 Motorised Height Adjustable Floor-To-Wall Stands pg.10-11 CONTENTS
B-Tech AV Mounts 4 RECOMMENDED MAX SCREEN MAX LOAD MAX VESA COLLAR COMPATIBLE PLASTIC FREE PACKAGING 140cm 55" 25kg 400 FLAT SCREEN DISPLAY TROLLEYS FLAT SCREEN DISPLAY TROLLEY BT7504 B-Tech’s Momentum Range of mobile display solutions includes a versatile lineup of trolleys designed for a wide range of screen sizes and professional applications. The BT7504 Momentum One offers a compact, single-pole design ideal for small to medium displays, with easy hook-on installation, multiple height options, and both landscape and portrait orientation support. For larger displays, the BT8504 Momentum Two provides a robust freestanding trolley with non-marking braked castors, optional levelling feet, and support for VESA patterns up to 600 x 400mm using included adaptor arms. For extra-large, heavy-duty displays, the BT8506 Momentum Grand delivers a mobile or freestanding solution with a three-piece base that allows for portability, integrated cable management, and storage for accessories, all with the same quick hook-on screen fitting featured across the range. SPECIFICATIONS Recommended screen size up to 55" Max load 25kg VESA® compatibility up to 400 x 400mm Product Dimensions W: 779mm H: 1634mm D: 624mm Packaging Dimensions W: 845mm H: 805mm D: 90mm FEATURES Suitable for displaying screens in both landscape or portrait orientation Ships in a compact single box for user convenience Integrated cable management Non-marking, 3" locking/braked castors included for easy mobility Offers three height options to mount the screen Shelves and other accessories can be fitted to the pole using B-Tech Ø50mm accessory collars (available separately) All mounting hardware included
info@btechavmounts.com 5 Flat Screen Display Trolleys FLAT SCREEN DISPLAY TROLLEY / STAND BT8504 XL FLAT SCREEN DISPLAY TROLLEY / STAND BT8506 SPECIFICATIONS Recommended screen size up to 75″ Max load 70kg VESA® fixings up to 600 x 400 (with included adaptors) Universal fixings up to up to 455 x 400mm Dimensions (with castors) W: 1098mm H: 1854mm D: 740mm FEATURES Mount screens in a landscape or portrait orientation Accessories can be fitted to the poles using Ø50mm accessory collars Includes alternative levelling feet for a freestanding display Integrated cable management for a neat and tidy installation Features non-marking 3” locking/braked castors Simple ‘hook-on’ installation All mounting hardware included SPECIFICATIONS Recommended screen size 60″ - 120" Max load 130kg VESA® & non-VESA fixings up to 1000 x 600mm Dimensions (with-castors) W: 1340mm H: 1731mm D: 738mm Storage area dimensions W: 720mm H: 160mm D: 90mm FEATURES Includes 4" locking/braked castors & alternative levelling feet The interface features an optional storage area for accessories Adjustment screws allow the screen to be levelled once mounted 1.5m Ø50mm poles supplied with cable management holes Shelves and other accessories such as video bars can be fitted to the poles using collars RECOMMENDED MAX SCREEN MAX LOAD MAX VESA POST INSTALL ALIGNMENT COLLAR COMPATIBLE 600 x 400 190cm 75" 70kg RECOMMENDED MAX SCREEN MAX LOAD MAX VESA POST INSTALL ALIGNMENT COLLAR COMPATIBLE 1000 x 600 305cm 120" 130kg
B-Tech AV Mounts 6 BT8545 Momentum Edge and BT8546 Momentum Edge XL are modern, durable, and easy-to-use flat screen trolleys designed to support displays and interactive touchscreens from 55" to 110" (varies between products). The trolleys' braked castors provide smooth, safe mobility, while the sturdy design ensures stable use, preventing unintended movement when using the touchscreen. Capable of holding displays up to 100kg and 125kg with multiple screen mounting heights available, both products feature versatile display options including an AV equipment shelf, which can also serve as a sleek blanking panel. These solutions are ideal for both installers and end users, delivering flexibility and performance across a range of applications. KEY FEATURES INTERACTIVE TOUCHSCREEN TROLLEYS Sturdy design prevents unwanted movement when using a touchscreen display Includes accessory shelf with versatile mounting options Simple hook-on installation for interactive displays Features non-marking, braked castors for secure mobility
info@btechavmounts.com 7 Interactive Touchscreen Trolleys BT8546 XL INTERACTIVE TOUCHSCREEN TROLLEY BT8545 INTERACTIVE TOUCHSCREEN TROLLEY SPECIFICATIONS Recommended screen size 65" up to 110" VESA® fixings up to 1000 x 900mm Max load (Screen) 125kg Max load (Shelf) 5kg Trolley Dimensions W: 1778mm H: 1245mm D: 772mm Shelf Dimensions W: 450mm D: 260mm FEATURES Rigid steel contruction eliminates unwanted movement when pressing against XL touchscreens Includes accessory shelf that fits anywhere along the mounting bar Non-marking locking / braked castors included Integrated cable management Safety screws help to prevent unauthorised removal of the screen All necessary mounting hardware is included SPECIFICATIONS Recommended screen size 55" up to 86" VESA® fixings up to 900 x 600mm Max load (Screen) 100kg Max load (Shelf) 5kg Trolley Dimensions W: 1050mm H: 1428-1722mm D: 882mm Shelf Dimensions W: 950mm D: 210mm FEATURES Sturdy steel construction prevents unwanted movement when using a touch screen display Includes an accessory shelf that can be mounted at the front or rear of the trolley Features non-marking, braked castors for secure mobility Provides six height adjustments for screen mounting and three for the shelf Safety screws help to prevent unauthorised removal of the screen All necessary mounting hardware is included RECOMMENDED MAX SCREEN MAX LOAD MAX VESA PLASTIC FREE PACKAGING 1000 x 900 279cm 110" 125kg RECOMMENDED MAX SCREEN MAX LOAD MAX VESA PLASTIC FREE PACKAGING 900 x 600 218cm 86" 100kg
B-Tech AV Mounts 8 MOTORISED HEIGHT ADJUSTABLE TROLLEYS B-Tech’s Momentum Range also includes, BT8558, BT8554, and BT8556 Momentum E-Lift trolleys. These products are motorised, height-adjustable solutions designed for single displays up to 100" or dual displays up to 46" and 65", respectively. Each model features an electronic height adjustment system with a 650mm range, operated via a wired control panel at a speed of 35mm per second. Designed to support screens weighing up to 100kg (single) or 25kg per screen (twin), they combine sleek aesthetics with quick assembly and userfriendly functionality. A rear integrated storage unit ensures neat cable management and practical AV equipment storage, ideal for educational and corporate environments. SPECIFICATIONS Recommended screen size 55″ - 100″ Max load 100kg VESA® & non-VESA fixings up to 900 x 600mm Dimensions (Trolley) H: 1415 - 2060mm W: 1086mm D: 833mm Dimensions (Inner Storage Box) H: 377mm W: 257mm D: 95.2mm RECOMMENDED MAX SCREEN MAX LOAD MAX VESA POST INSTALL ALIGNMENT HEIGHT ADJUSTMENT 900 x 600 254cm 100" 100kg FEATURES Motorised height-adjustment for precise screen positioning Supplied with a wired control console for easy height adjustment Storage compartment on the rear stores cables and AV equipment Non-marking locking / braked castors included Auto-stop; prevents screen from moving when resistance is felt Levelling screws for simple post-install alignment Safety screws help prevent unauthorised removal of the screen BT8558 MOTORISED HEIGHT ADJUSTABLE FLAT SCREEN TROLLEY CE APPROVED UK CONFORMITY ASSESSED
info@btechavmounts.com 9 Motorised Height Adjustable Trolleys BT8554 MOTORISED HEIGHT ADJUSTABLE TWIN SCREEN VC TROLLEY SPECIFICATIONS Recommended screen size 39″ up to 46″ per screen Max load 25kg per screen VESA® & non-VESA fixings up to 400 x 400mm Dimensions (Trolley) H: 1303 - 1953mm W: 1504mm D: 833mm Dimensions (Inner Storage Box) H: 377mm W: 257mm D: 95.2mm Dimensions (VC Shelf) H: 3mm W: 120mm D: 235mm FEATURES Motorised height-adjustment for precise screen positioning Storage compartment on the rear stores cables and AV equipment Non-marking locking / braked castors included Supplied with a wired control console for easy height adjustment Universal design suitable for mounting two screens side by side VC shelf for cameras with 1/4" thread and 100 x 100mm fixing points Auto-stop; prevents screen from movement when resistance is felt BT8556 MOTORISED HEIGHT ADJUSTABLE TWIN SCREEN VC TROLLEY FEATURES Universal design suitable for mounting two screens side by side Non-marking locking / braked castors included Motorised height-adjustment for precise screen positioning Storage compartment on the rear stores cables and AV equipment Supplied with a wired control console for easy height adjustment VC shelf for cameras with 1/4" thread and 100 x 100mm fixing points Auto-stop; prevents screen from movement when resistance is felt RECOMMENDED MAX SCREEN MAX LOAD MAX VESA POST INSTALL ALIGNMENT HEIGHT ADJUSTMENT 600 x 400 165cm 65" 25kg per screen SPECIFICATIONS Recommended screen size 49″ up to 65″ Max load 25kg per screen VESA® & non-VESA fixings up to 600 x 400mm Dimensions (Trolley) H: 1303 - 1953mm W: 2004mm D: 833mm Dimensions (Inner Storage Box) H: 377mm W: 257mm D: 95.2mm Dimensions (VC Shelf) H: 3mm W: 120mm D: 235mm RECOMMENDED MAX SCREEN MAX LOAD MAX VESA POST INSTALL ALIGNMENT HEIGHT ADJUSTMENT 400 x 400 117cm 46" 25kg per screen
B-Tech AV Mounts 10 MOTORISED HEIGHT ADJUSTABLE FLOOR-TO-WALL STANDS B-Tech’s Momentum Range also offers a selection of motorised, height-adjustable floor-to-wall stands designed to support multiple screen configurations. The BT8559 is ideal for single displays up to 100", while the BT8555 and BT8557 accommodate twin displays up to 46" and 65" respectively. Each model features an electronic height adjustment system with a 650mm range, operated via a wired control panel at a speed of 35mm per second. With support for screens up to 100kg (single) or 30kg per screen (twin) and wall depth adjustment of +/-25mm, these products are quick to assemble and easy to use, with each stand including an integrated rear storage unit for clean cable management and practical AV equipment housing making them a perfect fit for professional, educational, and corporate environments. FEATURES Supplied with a wired control console for easy height adjustment Adjustable depth to the wall Motorised height-adjustment for precise screen positioning Storage compartment on the rear stores cables and AV equipment Auto-stop; prevents screen from moving when resistance is felt Levelling screws for simple post-install alignment Safety screws help prevent unauthorised removal of the screen BT8559 MOTORISED HEIGHT ADJUSTABLE FLAT SCREEN FLOOR-TO-WALL STAND RECOMMENDED MAX SCREEN MAX LOAD MAX VESA POST INSTALL ALIGNMENT HEIGHT ADJUSTMENT 900 x 600 254cm 100" 100kg SPECIFICATIONS Recommended screen size 55″ - 100″ Max load 100kg VESA® & non-VESA fixings up to 900 x 600mm Dimensions (Stand) H: 1310 - 1960mm W: 1000mm D: 202 - 252mm Dimensions (Inner Storage Box) H: 353mm W: 257mm D: 103mm CE APPROVED UK CONFORMITY ASSESSED
info@btechavmounts.com 11 BT8555 FEATURES Universal design suitable for mounting two screens side by side Storage compartment on the rear stores cables and AV equipment Supplied with a wired control console for easy height adjustment Adjustable depth to the wall Motorised height-adjustment for precise screen positioning VC shelf for cameras with 1/4" thread and 100 x 100mm fixing points Auto-stop; prevents screen from movement when resistance is felt BT8557 FEATURES Supplied with a wired control console for easy height adjustment VC shelf for cameras with 1/4" thread and 100 x 100mm fixing points Adjustable depth to the wall Storage compartment on the rear stores cables and AV equipment Motorised height-adjustment for precise screen positioning Universal design suitable for mounting two screens side by side Auto-stop; prevents screen from movement when resistance is felt MOTORISED HEIGHT ADJUSTABLE TWIN SCREEN VC FLOOR-TO-WALL STAND RECOMMENDED MAX SCREEN MAX LOAD MAX VESA POST INSTALL ALIGNMENT HEIGHT ADJUSTMENT 400 x 400 117cm 46" 30kg per screen SPECIFICATIONS Recommended screen size 39″ up to 46″ per screen Max load 30kg per screen VESA® & non-VESA fixings up to 400 x 400mm Dimensions H: 1311 - 1961mm W: 1504mm D: 225-275mm Dimensions (Inner Storage Box) H: 353mm W: 257mm D: 103mm Dimensions (VC Shelf) H: 3mm W: 120mm D: 235mm XL MOTORISED HEIGHT ADJUSTABLE TWIN SCREEN VC FLOOR-TO-WALL STAND RECOMMENDED MAX SCREEN MAX LOAD MAX VESA POST INSTALL ALIGNMENT HEIGHT ADJUSTMENT 600 x 400 165cm 65" 30kg per screen SPECIFICATIONS Recommended screen size 49″ up to 65″ Max load 30kg per screen VESA® & non-VESA fixings up to 600 x 400mm Dimensions H: 1311 - 1961mm W: 2004mm D: 225-275mm Dimensions (Inner Storage Box) H: 353mm W: 257mm D: 103mm Dimensions (VC Shelf) H: 3mm W: 120mm D: 235mm Motorised Height Adjustable Floor-To-Wall Stands
www.btechavmounts.com info@btechavmounts.com © 2025 June B-Tech AV Mounts Corporation Ltd., All rights reserved. The information in this catalogue reflects the current technical specifications at the time of print. We reserve the right to change the technical or physical specifications without prior notice. B-Tech AV Mounts, the B-Tech logo & Momentum are all registered trademarks. All B-Tech images & symbols are exclusive property of B-Tech AV Mounts Corporation Ltd. All other brands & products are trademarks of their respective owners. B-Tech accept no liability for loss or damage caused by improper installation or mounting on unstable structures. E&OE. Disclaimer B-Tech security fasteners are designed as a security deterrent only. B-Tech, B-Tech distributors & B-Tech resellers accept no liability for loss or resulting costs incurred from the theft, attempted theft or unauthorised removal of any item(s) mounted using B-Tech security fasteners. Security screw removal tools are widely available & all B-Tech security fasteners are intended as a deterrent to the opportunist thief only. Designed & Engineered in the UK www.globalmountsgroup.com MPB-2025-V1-270625-ENG B-Tech AV Mounts is part of the United Kingdom +44 (0)1327 300 787 uk@btechavmounts.com APAC +65 3159 1604 apac@btechavmounts.com Europe +32 (0)2 720 9271 europe@btechavmounts.com China (+86) 574 8810 3861 china@btechavmounts.com Germany +49 (0)21625483032 dach@btechavmounts.com South Korea +82 (0) 2 862 3165 korea@btechavmounts.com Spain +34 93 640 24 79 iberia@btechavmounts.com Vietnam +84 (0)24 3201 3418 vietnam@btechavmounts.com MEAI +971 4 3574855 meai@btechavmounts.com Americas +1 888 792 8188 americas@btechavmounts.com For full details of all B-Tech offices, please visit www.btechavmounts.com/contact-us or scan here:
