B-Tech AV Mounts 2025 dvLED Product Brochure

www.btechavmounts.com dvLED Mounting Systems Designed for All Brands of LED 2025 dvLED Product Range

B-Tech AV Mounts 2 dvLED Videowall Mounting Solutions Discover the Ultimate dvLED Mounting Solutions by B-Tech AV Mounts Over the past decade B-Tech AV Mounts has continuously expanded and refined one of the most comprehensive and versatile dvLED mounting systems on the market. Our award-winning solutions are trusted globally across a wide range of projects, from compact installations to large-scale, high-profile AV setups. Whatever the size or scope, we have the perfect solution for you. New for 2025, we’re excited to introduce three specialised ranges tailored to meet diverse requirements, offering unparalleled flexibility and convenience. London, Oxford Street 400sqm dvLED wall using System Xpert Future Stores

info@btechavmounts.com 3 Mounting solutions for DI SPLAYS System Xpert, the installers choice, is a premium range of dvLED mounting solutions trusted for its quality, ease of use, adjustability and fast installation. It meets every need, from simple small format wall mounts to extra-large, curved, odd shaped or even ceiling setups. Configurations can be generated using our online configuration tool. For more ambitious projects, our expert engineers can assist with bespoke specifications via email at technical@btechavmounts.com. The range includes detailed documentation, pre-assembled components and precision engineered Interface components for your specific application. System Xpress revolutionises dvLED mounting supply with its innovative, universal design for self-locking cabinets. Featuring Patent Pending Xpress Connectors instead of screen-specific interface arms, this system offers unmatched versatility. The connectors click into your cabinets and lock effortlessly into supplied rails, enabling wall, floor, or ceiling installations with precision. Pre-configured in the most popular 16:9 layouts and stocked for immediate availability, System Xpress eliminates the need for custom fabrication, making it the fastest and easiest way to receive your dvLED mounting solution. Our System AIO range provides dedicated mounting solutions for the most popular all-in-one dvLED displays on the market. Offering wall-mounted, floor-standing, and mobile options, System AIO supports leading brands such as Absen, LG, and Samsung, ensuring a perfect fit for your display requirements. New for 2025 3-ways to create your ideal dvLED solutions! Pg.16 Pg.12 Pg.6

B-Tech AV Mounts 4 Making dvLED installation simple Floor Base with Level Adjustment Suitable for uneven floors Depth and Height Adjustment Brackets Precision alignment on uneven surfaces Retractable Floor Base Allows easy access to the front of AV displays Ideal for shop window displays All dvLED Solutions include Cut to Size parts No on-site cuts required Service Pre-assembly of component parts B-Tech's Service+ offers customers a fully integrated service tailored specifically for our System Xpert dvLED solutions. Our team of in-house engineers delivers: • Bespoke, installation-specific technical drawings. • Pre-assembly of component parts for added convenience. • Precision-cut rail lengths customised to your exact specifications - a feature that sets us apart from competitor services. Best of all, this service is provided free of charge for System Xpert Solutions. dvLED Mounting Solutions available for all major brands, including... Installation specific techincal drawings with all required dimensions for a straight forward assembly To ensure the precise installation of dvLED cabinets, B-Tech provides a range of features in our dvLED solutions, including custom cut-to-size parts for every order. Our System X components are designed with level, depth, height, and angle adjustments, ensuring they meet diverse mounting requirements. These innovations make the installation of dvLED video walls straightforward, efficient, and highly adaptable to any set-up.

info@btechavmounts.com 5 Recommended Max configuration size Unlimited 10x10 All-in-One Production lead time (working days) 25 days UK / EU: 0-2 days Rest of the World: 4-8 days UK / EU: 0-2 days Rest of the World: 4-8 days Universal combitility Designed and manufactured in accordance with the customer's cabinets All 'latching' cabinets Absen / LG / Samsung All-In-One displays Function Wall, Floor, Mobile, Bolt-Down, Ceiling Hung, Ceiling Flat, Curved, Bespoke Wall, Floor, Mobile, Bolt-Down, Ceiling Hung Wall, Floor, Mobile, Bolt-Down Install time Fast Medium Fast Rear Mount    Front Mount    Micro-adjustment on wall plate  Height & depth up to +/-10mm*  Height & depth +/-5mm  Height & depth +/-10mm Height micro-adjustment on interface 20mm  20mm Depth adjustment    Rails cut to size    Pre-assembly with    Technical drawings provided by  Install specific drawings provided  General installation guide with clear instructions provided for configurations outside of stocked packages  Provided with stocked packages Provided with stocked packages Indoor / Outdoor use Indoor & Outdoor* Indoor Indoor Service Service *Depending on application Mounting solutions for DI SPLAYS

B-Tech AV Mounts 6 BT9342 dvLED Ceiling Mount for any configuration BT9344 dvLED Floor-To-Ceiling Mount for any configuration Examples of configurations are shown below; all configurations are available. Configure to your requirements using our online configurator, or contact technical@btechavmounts.com for more advanced set-ups. BT9340 dvLED Wall Mount for any configuration Depth and Height Adjustment Brackets Precision alignment on uneven surfaces Depth and Height Adjustment Brackets Precision alignment for ceiling mounted solutions Depth and Height Adjustment Brackets Precision alignment for ceiling mounted solutions dvLED Mounts & Stands

7 info@btechavmounts.com www.btechavmounts.com/led-panel-configurator See online for more information about our online configurator. www.btechavmounts.com/led-panel-configurator BT9372 dvLED Bolt-Down Stand for any configuration BT9370 dvLED Videowall Stand for any configuration Optional Adjustable Floor Base with level adjustment for uneven floors BT9371 dvLED Mobile Stand for any configuration BT9377 dvLED Bolt-Down Stand with Retractable Base for any configuration Retractable Floor Bases Ideal for close to window installs dvLED Mounts & Stands

B-Tech AV Mounts 8 Configure to your requirements using our online configurator, or contact technical@btechavmounts.com for more advanced set-ups. dvLED Curved mounts designed for Latching Curved Cabinets BT9343 dvLED Curved Wall Mount for any configuration BT9373 dvLED Curved Stand for any configuration BT9375 dvLED Curved Bolt-Down Stand for any configuration Depth and Height Adjustment Brackets Precision alignment on uneven surfaces Optional Adjustable Floor Base with level adjustment for uneven floors dvLED Mounts & Stands Adjustable Levelling Feet to allow for uneven floor surfaces Examples of configurations are shown below; all configurations are available.

9 info@btechavmounts.com www.btechavmounts.com/led-panel-configurator See online for more information about our online configurator. www.btechavmounts.com/led-panel-configurator BT9350 Internal dvLED Corner Wall Mount BT9351 External dvLED Corner Wall Mount BT9352 Cube dvLED Videowall Mount BT9376 dvLED Curved Wave Bolt-Down Stand for any configuration Bolt Down Floor Bases with level adjustment for uneven floors Depth and Height Adjustment Brackets Precision alignment on uneven surfaces BT9378 dvLED Motorised Height Adjustable Mobile Stand dvLED Mounts & Stands

B-Tech AV Mounts 10 Step 1: Go to www.btechavmounts.com Step 2: Select Wall, Freestanding, Mobile or Bolt-Down Configurations can be specified in just a few simple clicks. Start by choosing between wall or floor stand mounted options. Then, enter details about your screen size and the quantity to be installed, the orientation, the type and brand of dvLED panel to be used. Once complete, fill out your contact details, and we'll get in touch and give you a quote for your requested configuration. Freestanding Mobile Bolt-Down Floor Stands: Select Mobile, Freestanding or Bolt-Down Direct View LED Videowall Online Configuration Tool www.btechavmounts.com/led-panel-configurator

11 info@btechavmounts.com Step 3: Select specifications from drop down boxes LED Cabinets Per Row please select Number of Rows of LED Cabinets please select Cabinet Dimensions please select Cabinet Brand / Model Number please select Cabinet Fixing Method please select Cabinet Weight please select Step 4: Configure your LED Mounting Solution B-Tech Model: BT9340-3x2 Step 5: Request a quote for this configuration Alternatively: Contact B-Tech for Curved, Ceiling or Bespoke Solutions To configure curved, ceiling or bespoke dvLED mounting solutions contact technical@ btechavmounts.com stating your specifications to receive a quote within days. For Wall, Freestanding, Mobile and Bolt-Down Mounting Solutions For an in depth tutorial and explanation of System Xpert scan the QR code to view our online overview video.

B-Tech AV Mounts 12 BTXPS27-W Universal 27" dvLED Wall Mount System Xpress offers a versatile range of universal dvLED mounting kits, ready for express shipment from stock. These kits can be ordered as pre-packaged solutions in configurations such as 4x4, 5x5, 6x6, and 8x8 or for other sizes and shapes, quoted and shipped using off-the-shelf components under a unique Bill of Materials for your specific project Designed to mount interlocking 27" dvLED cabinets (Min. width 600 - Max.610mm), System Xpress features universal mounting connectors that eliminate the need for custom parts. This allows mounting solutions to be quoted, stocked, and shipped with speed and efficiency. With same-day lead times for our ready-to-go kits and next day for everything else - that's what we call Xpress service! For custom configurations, cabinets other than 27" and bespoke solutions, see page 14. dvLED Mounts & Stands - Pre-Configured Kits BTXPS27-S Universal 27" dvLED Stand Available in 4 pre-configured kits BTXPS27-W4X4 4x4 Dimensions: H: 160 x W: 240 x D: 6cm BTXPS27-W5X5 5x5 Dimensions: H: 200 x W: 300 x D: 6cm BTXPS27-W6X6 6x6 Dimensions: H: 240 x W: 360 x D: 6cm BTXPS27-W8X8 8x8 Dimensions: H: 320 x W: 480 x D: 6cm Available in 4 pre-configured kits Dimensions*: W. 2400-2440 x H. 1370 x D. 60mm Dimensions*: W. 3000-3050 x H: 1710 x D. 60mm Dimensions*: W. 3600-3660 x H. 2050 x D. 60mm Dimensions*: W. 4800-4880 x H. 2740 x D. 60mm BTXPS27-S4X4 4x4 Dimensions*: W: 2400-2440 x H: 2500 x D: 950mm BTXPS27-S5X5 5x5 Dimensions*: W: 3000-3050 x H: 2500 x D: 950mm BTXPS27-S6X6 6x6 Dimensions*: W: 3600-3660 x H: 2500 x D: 950mm BTXPS27-S8X8 8x8 Dimensions*: W: 4800-4880 x H: 3100 x D: 950mm

13 info@btechavmounts.com BTXPS27-B Universal 27" dvLED Bolt-Down Stand dvLED Mounts & Stands - Pre-Configured Kits System Xpress Features BTXPS27-M Universal 27" dvLED Mobile Stand Available in 4 pre-configured kits Available in 4 pre-configured kits 'Click & Lock' (patent pending) Interface Mounting Connector for a simple and secure installation Depth Adjustable Rail Mounts Bottom Row Spacer for Level Installation Designed for use with dvLED Locking Cabinets BTXPS27-B4X4 4x4 Dimensions*: W: 2400-2440 x H: 2410 x D: 240mm BTXPS27-B5X5 5x5 Dimensions*: W: 3000-3050 x H: 2410 x D: 240mm BTXPS27-B6X6 6x6 Dimensions*: W: 3600-3660 x H: 2410 x D: 240mm BTXPS27-B8X8 8x8 Dimensions*: W: 4800-4880 x H: 3010 x D: 240mm BTXPS27-M4X4 4x4 Dimensions*: W: 2400-2440 x H: 2620 x D: 950mm BTXPS27-M5X5 5x5 Dimensions*: W: 3000-3050 x H: 2620 x D: 950mm BTXPS27-M6X6 6x6 Dimensions*: W: 3600-3660 x H: 2620 x D: 950mm BTXPS27-M8X8 8x8 Dimensions*: W: 4800-4880 x H: 3220 x D: 950mm *Product dimensions are based on mounting 600-610mm x 342mm cabinets.

B-Tech AV Mounts 14 BT9240 Universal dvLED Wall Mount for any configuration BT9270 Universal dvLED Stand for any configuration BT9271 Universal dvLED Mobile Stand for any configuration dvLED Mounts & Stands - Custom Kits For configurations beyond our off-the-shelf options, we offer custom System Xpress packages, recommended for up to 10x10 set-ups. For larger or more complex configurations, our System Xpert solutions have you covered. Designed to support a wide range of interlocking dvLED cabinets of any size, System Xpress features universal mounting connectors that eliminate the need for custom parts. This allows mounting solutions to be quoted, stocked, and shipped with speed and efficiency. For an in depth tutorial and explanation of System Xpress scan the QR code to view our online overview video. Examples of configurations are shown below; all configurations up to 10x10 are available under System Xpress. 4" non-marking Braked Castors for easy repositioning of the videowall Adjustable Levelling Feet to allow for uneven floor surfaces

15 info@btechavmounts.com BT9272 Universal dvLED Bolt-Down Stand for any configuration BT9242 Universal dvLED Ceiling Mount for any configuration BT9244 Universal dvLED Floor-to-Ceiling Mount for any configuration dvLED Mounts & Stands - Custom Kits System Xpress Features Optional Adjustable Floor Base with level adjustment for uneven floors 'Click & Lock' Interface Mounting Connector for a simple and secure installation Depth Adjustable Rail Mounts Bottom Row Spacer for Level Installation Designed for use with dvLED Locking Cabinets

B-Tech AV Mounts 16 All-In-One dvLED Mounting Solutions Mounting solutions available for all major brands of All-in-One displays Freestanding Solutions BT83LAEC015-S Freestanding Floor Stand for LG LAEC015 136" Display BT83LG163-S Freestanding Floor Stand for LG LAEC018 163" Display BT83LG171-S Freestanding Floor Stand for LG LAEC015 171" 21:9 Display BT83LAEC015-M Mobile Floor Stand for LG LAEC015 136" Display BT83LG163-M Mobile Floor Stand for LG LAEC018 163" Display Mobile Solutions Designs specifically for LG's LAEC015 136", LAEC018 163" and LAED015 171" All-In-One LED Screens, the range consists of wall mounted, freestanding, mobile and bolt-down versions and all feature the same high-end aesthetic, anodised aluminium finish and integrated cable management, which ensures a smart and stylish installation. Mounting solutions for DI SPLAYS

17 info@btechavmounts.com All-In-One dvLED Mounting Solutions BT83LG171-M Mobile Floor Stand for LG LAEC015 171" 21:9 Display BT83LG163-B Bolt-Down Floor Stand for LG LAEC018 163" Display BT83LG171-B Bolt-Down Floor Stand for LG LAEC015 171" 21:9 Display BT83LAEC015-B Bolt-Down Floor Stand for LG LAEC015 136" Display Bolt-Down Solutions Scan to view our LG dvLED Mounting Brochure Mounting solutions for DI SPLAYS

B-Tech AV Mounts 18 All-In-One dvLED Mounting Solutions Mounting solutions available for all major brands of All-in-One displays Designs specifically for Samsung's The Wall IAB 110", IAC 130" and IAB 146" All-In-One LED Screens, the range consists features freestanding and bolt-down stands and all feature the same high-end aesthetic, anodised aluminium finish and integrated cable management, which ensures a smart and stylish installation. For a mobile stand add BT8380-CASTORS to a freestanding solution. Mounting solutions designed specifically for Absens iCon series All-In-One LED Screens, the range consists of wall mounted, freestanding, mobile and bolt-down versions and all feature the same high-end aesthetic, anodised aluminium finish and integrated cable management, which ensures a smart and stylish installation. Freestanding Solutions BT9370-SAM110 Freestanding Floor Stand for Samsung All-In-One 110" IAB Display BT9370-SAM130 Freestanding Floor Stand for Samsung All-In-One 130" IAC Display BT9370-SAM146 Freestanding Floor Stand for Samsung All-In-One 146" IAB Display Scan to view our Absen dvLED Mounting Brochure Mounting solutions for DI SPLAYS

19 info@btechavmounts.com All-In-One dvLED Mounting Solutions Scan to view our Samsung dvLED Mounting Brochure BT9372-SAM130 Bolt-Down Floor Stand for Samsung All-In-One 130" IAC Display BT9372-SAM146 Bolt-Down Floor Stand for Samsung All-In-One 146" IAB Display BT9372-SAM110 Bolt-Down Floor Stand for Samsung All-In-One 110" IAB Display Bolt-Down Solutions Mounting solutions for DI SPLAYS

www.btechavmounts.com info@btechavmounts.com © 2025 January B-Tech AV Mounts Corporation Ltd., All rights reserved. The information in this catalogue reflects the current technical specifications at the time of print. We reserve the right to change the technical or physical specifications without prior notice. System X, System Xpert, System Xpress, System 2 & System V are trademarks of B-Tech AV Mounts Corporation Ltd., B-Tech AV Mounts, the B-Tech logo, Ventry & Mode-AL are all registered trademarks. All B-Tech images & symbols are exclusive property of B-Tech AV Mounts Corporation Ltd. All other brands & products are trademarks of their respective owners. B-Tech accept no liability for loss or damage caused by improper installation or mounting on unstable structures. E&OE. Disclaimer B-Tech security fasteners are designed as a security deterrent only. B-Tech, B-Tech distributors & B-Tech resellers accept no liability for loss or resulting costs incurred from the theft, attempted theft or unauthorised removal of any item(s) mounted using B-Tech security fasteners. Security screw removal tools are widely available & all B-Tech security fasteners are intended as a deterrent to the opportunist thief only. Designed & Engineered in the UK www.globalmountsgroup.com DPB-2025-V1-200125-ENG B-Tech AV Mounts is part of the United Kingdom +44 (0)1327 300 787 uk@btechavmounts.com APAC +65 3159 1604 apac@btechavmounts.com Europe +32 (0)2 720 9271 europe@btechavmounts.com China (+86) 574 8810 3861 china@btechavmounts.com Germany +49 (0)2162-5483032 dach@btechavmounts.com South Korea +82 (0) 2 862 3165 korea@btechavmounts.com Spain +34 93 640 24 79 iberia@btechavmounts.com Vietnam +84 (0)24 3201 3418 vietnam@btechavmounts.com MEAI +971 4 3574855 meai@btechavmounts.com Americas +1 888 792 8188 americas@btechavmounts.com For full details of all B-Tech offices, please visit www.btechavmounts.com/contact-us or scan here:
