B-Tech AV Mounts 2 Welcome to the 2026 B-Tech AV Mounts Highlights Catalog Contact: B-Tech AV Mounts LLC +1 888 792 8188 Americas@btechavmounts.com Established in London in 1972, B-Tech AV Mounts is an industry leader in the design and manufacture of professional AV mounting solutions, whose products are recognized globally for their innovation, robustness, reliability, ease of install and design aesthetics. With strategically located offices and distribution centers around the world, B-Tech provides a truly global localized service. B-Tech AV Mounts not only offers one of the most extensive but also the most versatile and adaptable mounting ranges available from any mounting solutions provider. B-Tech mounting solutions cover all AV requirements ranging from small, single screens to large format displays, projectors, speakers, interactive touchscreens and UC equipment, as well as large, multi-screen LCDs and dvLED video walls and digital signage. Designed to stringent TUV and UL safety standards by B-Tech's in-house team of engineers, our products are available as wall or ceiling mounts, desktop stands or as freestanding, mobile or bolt-down floor stands. Winners of multiple accolades including AV Awards' AV Manufacturer of the Year crown, B-Tech AV Mounts products are found in hotels, shopping malls, government facilities, education, corporate offices, sports stadiums, restaurants, airports and conference facilities worldwide. Subscribe to our mailing list for the latest news, event details and product launches: www.btechavmounts.com/mailing-list Welcome to the latest edition of the B-Tech AV Mounts Catalog For full company info, product specs, assembly manuals, configuration tools, PR and media files, please visit: www.btechavmounts.com QR Codes All products in the catalogue feature QR codes that you can scan to access the product's dedicated web page. There, you'll find the full product specifications, features, images, assembly manuals, and specification sheets. London, Oxford Street 400sqm dvLED wall using System Xpert Future Stores
3 info@btechavmounts.com 3 Contents Welcome to the B-Tech Highlights Catalog Pg.2 Contents 3 About B-Tech 4-5 Complete Mounting Solutions Quick Reference Guides Pg.6-13 dvLED Mounting Solutions 14-29 Menu Board Mounting Systems 30-31 Videowall Mounting Systems 32-37 Modular Videowall Mounts 38-39 Digital Signage Mounts 40-43 Flat Screen Wall Mounts 44-45 Flat Screen Ceiling Mounts 46-47 Floor Stands & Mobile Solutions 48-51 UC & VC Twin Screen Mounting Solutions 52-53 Media Storage Solutions & Accessory Mounts 54-56 Video Bar Mounts 57 Speakers Mounts 59 Projector Ceiling Mounts 60-61 Component Ranges Mounting Guides Pg.62-71 Flat Screen Ceiling Mounts Pg.46 Pg.44 Pg.14 Digital Signage Flat Screen Wall Mounts Pg.40 Pg.30 Menu Board & Videowall Mounting Systems Pg.48 Floor Stands & Mobile Solutions dvLED Mounting Solutions Pg.60 Projector Ceiling Mounts Pg.54 Media Storage Devices & Shelves Pg.57 Video Bar Mounts Speaker Mounts Pg.59 Bane NOR, Norway 21x1 curved ceiling mounted videowall 6 large videowall stands using System X Global Control Center (GCCD) Contents Pg.62 Components Ranges Pg.52 UC / VC Display Stands
B-Tech AV Mounts 4 Fully stocked distribution centers Enables a fast turn around on orders and shipping Why Choose B-Tech? Pre-assembly To save valuable on-site installation time Paris, France Curved dvLED video wall with a 25x7 suspended ceiling mount using System Xpert & System 2 XR Studio Comprehensive Product Range Our extensive catalogue features one of the industry’s largest selections of mounting solutions. a wide selection of mounting solutions, including wall, ceiling and floor mounts for display screens, dvLED, projectors, and audio equipment. Decades of Excellence Established in 1972, B-Tech brings over 50 years of industry experience and is a multiple award-winner, including Manufacturer of the Year at the AV Awards, and top honors for our System X and dvLED solutions. Rapid, Accurate Quotes & Fast Dispatch We offer quick, precise quotes for complex set-ups, including dvLED installations, often fulfilling bespoke needs directly from stock. Many of B-Tech's global locations offer same-day dispatch, ensuring swift delivery for urgent requirements. Dedicated Support Our technical and sales teams are always available to answer questions and provide expert guidance. Our engineers are available to design tailored installation plans and provide quotes based on your precise requirements. Limitless Configurations With thousands of configurations available through our stocked, modular component systems, we provide versatile options for any project. Our ranges enable custom configurations, making installations exceptionally flexible and adaptable. Installer Friendly B-Tech mounts are designed with installation simplicity in mind, many features are included to save the installer on-site time with a streamlined mounting processes, pre-assembly of key components, rails cut to size in-house. Why Choose B-Tech? About B-Tech AV Mounts Complete technical drawings & installation guides provided. Pre-assembled frames and rails cut to size for quick and easy on-site install. 540mm 21.26in 540mm 21.26in TYP 540mm 21.26in TYP 540mm 21.26in 266mm 10.47in Excluding End Cap 240mm 9.45in 840mm 33.07in 540mm 21.26in 540mm 21.26in 840mm 33.07in 240mm 9.45in 266mm 10.47in Excluding End Cap 392mm 15.43in 2020mm 79.53in 308mm 12.13in 1712mm 67.4in 1148mm 45.2in 872mm 34.33in 34mm 1.34in Excluding End Cap (x3) Aluminum 5 SCALE 1 : 25 540mm 21.26in 540mm 21.26in TYP 540mm 21.26in TYP 540mm 21.26in 540mm 21.26in 540mm 21.26in 266mm 10.47in Excluding End Cap 257mm 10.12in 283mm 11.14in 240mm 9.45in 840mm 33.07in 540mm 21.26in 540mm 21.26in 840mm 33.07in 240mm 9.45in 283mm 11.14in 257mm 10.12in 266mm 10.47in Excluding End Cap 358mm 14.09in Excluding End Cap 565mm 22.24in 2020mm 79.53in 392mm 15.43in 2020mm 79.53in 308mm 12.13in 1712mm 67.4in 1148mm 45.2in 872mm 34.33in 51mm 2.01in 890mm 35.04in 33mm 1.3in Excluding End Cap (x1) Aluminum 4 SCALE 1 : 25 540mm 21.26in TYP 540mm 21.26in TYP 540mm 21.26in TYP 540mm 21.26in TYP 540mm 21.26in TYP 540mm 21.26in TYP 935mm 36.81in 38mm 1.5in Excluding End Cap 1028mm 40.47in 232mm 9.13in 1628mm 64.09in 392mm 15.43in 2020mm 79.53in 308mm 12.13in 1712mm 67.4in 1148mm 45.2in 872mm 34.33in 734mm 28.9in 207mm 8.15in 38mm 1.5in Excluding End Cap 266mm 10.47in Excluding End Cap 654mm 25.75in 426mm 16.77in 240mm 9.45in 840mm 33.07in 540mm 21.26in 540mm 21.26in 840mm 33.07in 240mm 9.45in 680mm 26.77in 400mm 15.75in 266mm 10.47in Excluding End Cap Aluminum 2 SCALE 1 : 25 540mm 21.26in 540mm 21.26in TYP 540mm 21.26in TYP 540mm 21.26in TYP 540mm 21.26in TYP 266mm 10.47in Excluding End Cap 114mm 4.49in 426mm 16.77in 240mm 9.45in 840mm 33.07in 540mm 21.26in 540mm 21.26in 840mm 33.07in 240mm 9.45in 140mm 5.51in 400mm 15.75in 266mm 10.47in Excluding End Cap 898mm 35.35in Excluding End Cap 1628mm 64.09in 392mm 15.43in 2020mm 79.53in 308mm 12.13in 1712mm 67.4in 1148mm 45.2in 872mm 34.33in 941mm 37.05in 573mm 22.56in Excluding End Cap Aluminum 3 SCALE 1 : 25 540mm 21.26in TYP 540mm 21.26in TYP 540mm 21.26in TYP 540mm 21.26in TYP 540mm 21.26in TYP 540mm 21.26in TYP 935mm 36.81in 578mm 22.76in Excluding End Cap 266mm 10.47in Excluding End Cap 114mm 4.49in 426mm 16.77in 1260mm 49.61in 1628mm 64.09in 392mm 15.43in 240mm 9.45in 840mm 33.07in 2020mm 79.53in 540mm 21.26in 540mm 21.26in 308mm 12.13in 1712mm 67.4in 1148mm 45.2in 872mm 34.33in 840mm 33.07in 240mm 9.45in 140mm 5.51in 941mm 37.05in 400mm 15.75in 266mm 10.47in Excluding End Cap 578mm 22.76in Excluding End Cap Aluminum 1 SCALE 1 : 25 We recommend measuring from the top edge, to the top edge when installing the BT8390 horizontal rails. Total B-TECH Mount Weight (Without the Cabinets) Approx: 1382.69Kg (3048.30lbs). Total dvLED Cabinet Weight (Excluding Cables) Approx: 1872.34Kg (4127.80Ibs). Please view DXF file using eDrawings software for precise measurements (x1) (x1) (x1) B-Tech AV Mounts Coporation Limited BT9340-RM-25X7-SAM-IEA-03502 R00 B-Tech No: Title: Revision: The information contained in this drawing is the sole property of B-Tech AV Mounts Coporation Limited, any reproduction in part or whole without the written permission of B-Tech AV Mounts Coporation Limited is prohibited. Sheet: 3 of 3 File Name: BTD-BT9340-RM-25X7-SAM-IEA-03502 Date: 24/05/2024 Scale: A2 Size: UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN MILLIMETERS B-Tech AV Mounts Coporation Limited makes no representation or warranties, express or implied, with respect to the reuse of the data provided herewith, regardless of its format or the means of its transmission. B-Tech AV Mounts Coporation Limited makes every effort to provide accurate information, however there is no guarantee or representation to the user as to the accuracy, currency, suitability or reliability of this data. The user assumes all risks associated with its use. B-Tech International Design and Manufacturing Limited assumes no responsibility for actual or consequential damage incurred as a result of any user's reliance on this data. Universal DVLED Videowall Mount 1:40 Customer Sign Off: 540mm 21.26in Installation Spacer 2 504mm 19.84in TYP 36mm 1.42in TYP 870mm 34.25in TYP 90mm 3.54in TYP 660mm 25.98in 960mm 37.8in TYP 540mm 21.26in 840mm 33.07in Installation Spacer 3 960mm 37.8in TYP 13496mm 531.34in Max Extrusion Width (Including End Caps) 12416mm 488.82in Including End Caps 11336mm 446.3in Including End Caps 10256mm 403.78in Including End Caps 8096mm 318.74in Including End Caps 1140mm 44.88in Installation Spacer 4 1260mm 49.61in B C D E 528mm 20.79in Installation Spacer 1 266mm 10.47in Excluding End Cap 540mm 21.26in TYP 1080mm 42.52in 540mm 21.26in TYP 1080mm 42.52in 540mm 21.26in TYP 1080mm 42.52in 540mm 21.26in TYP 266mm 10.47in Excluding End Cap A 379mm 14.92in 409mm 16.1in 1920mm 75.59in IMP Height 3 (2-High IMP) 960mm 37.8in TYP IMP Height 2 (1-High IMP) 2880mm 113.39in IMP Height 1 (3-High IMP) 2880mm 113.39in IMP Height 1 (3-High IMP) ISOMETRIC VIEW SCALE: 1 : 100 2mm 0.08in End Cap 1.5mm 0.06in Excluding End Cap 3.5mm 0.14in Including End Cap DETAIL A SCALE 1 : 2 2mm 0.08in End Cap 1.5mm 0.06in Excluding End Cap 3.5mm 0.14in Including End Cap DETAIL B SCALE 1 : 2 2mm 0.08in End Cap 1.5mm 0.06in Excluding End Cap 3.5mm 0.14in Including End Cap DETAIL C SCALE 1 : 2 2mm 0.08in End Cap 1.5mm 0.06in Excluding End Cap 3.5mm 0.14in Including End Cap DETAIL D SCALE 1 : 2 2mm 0.08in End Cap 1.5mm 0.06in Excluding End Cap 3.5mm 0.14in Including End Cap DETAIL E SCALE 1 : 2 We recommend measuring from the top edge, to the top edge when installing the BT8390 horizontal rails. Total B-TECH Mount Weight (Without the Cabinets) Approx: 1382.69Kg (3048.30lbs). Total dvLED Cabinet Weight (Excluding Cables) Approx: 1872.34Kg (4127.80Ibs). Please view DXF file using eDrawings software for precise measurements B-Tech AV Mounts Coporation Limited BT9340-RM-25X7-SAM-IEA-03502 R00 B-Tech No: Title: Revision: The information contained in this drawing is the sole property of B-Tech AV Mounts Coporation Limited, any reproduction in part or whole without the written permission of B-Tech AV Mounts Coporation Limited is prohibited. Sheet: 1 of 3 File Name: BTD-BT9340-RM-25X7-SAM-IEA-03502 Date: 24/05/2024 Scale: A2 Size: UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN MILLIMETERS B-Tech AV Mounts Coporation Limited makes no representation or warranties, express or implied, with respect to the reuse of the data provided herewith, regardless of its format or the means of its transmission. B-Tech AV Mounts Coporation Limited makes every effort to provide accurate information, however there is no guarantee or representation to the user as to the accuracy, currency, suitability or reliability of this data. The user assumes all risks associated with its use. B-Tech International Design and Manufacturing Limited assumes no responsibility for actual or consequential damage incurred as a result of any user's reliance on this data. Universal DVLED Videowall Mount 1:40 Customer Sign Off:
5 info@btechavmounts.com 5 Sustainability Sustainability B-Tech recycles 100% of excess cardboard as filler and implements a no plastic tape policy Green sheets provide a clear and concise document detailing materials used and the environmental impact of each product. PLASTIC FREE PACKAGING As part of our ethical responsibility, B-Tech are committed to operating in an environmentally responsible way throughout our global organisation. www.btechavmounts.com B-Tech AV Mounts is dedicated to making sustainable product choices that prioritise recyclability. We are committed to investing in a circular economy, where sustainability is central to every aspect of our operations. Embracing a sustainable approach is crucial in our efforts to combat global climate change. Environmental footprint Greenhouse gasses emitted into the environment during production of a product contribute directly to our planet’s global warming. Using LCA software1 we are able to calculate2 the (potential) environmental footprint, measured in kilograms CO2-equivalent. This enables us to evaluate a product’s footprint and support the design of sustainable products. By recycling our products the impact on the environment can be reduced as the recycled material replace the need to produce virgin materials. GREENSHEET Sit-stand workstation This product is made from the following materials: Steel 79% Aluminium 15% ABS 3% PE 2% PA 1% POM 0,1% MA D E WI T H R E C Y C L E D MA T E R I A L S WL90-325BL1 Steel Aluminium ABS PE PA POM Total Material weight (g) 5756,3 1058,5 249,7 171,4 43,3 9,4 7.289 Kilograms CO2 equivalent When not recycled 21,6 15,9 1,5 0,66 0,41 0,04 40,09 When recycled 13,2 9,3 1,5 0,7 0,4 0,03 25,10 Total recycling reduction 37% To illustrate the impact of one kilogram of carbon dioxide, we’ve converted it into the equivalent distance a car would travel in kilometers. Emitted carbon dioxide with recycling without recycling 25,10 CO2 40,08 CO2 76,10 KM 121,50 KM *8 litres of petrol per 100 km² Sources: ¹ Mobius Ecochain - Ecoinvent v3.6, ² According to EN15804+A2, 3 Foundation myclimate; based on 8 litres of pertrol per 100 km WL90-325BL1 www.btechavmounts.com B-Tech AV Mounts is dedicated to making sustainable product choices that prioritise recyclability. We are committed to investing in a circular economy, where sustainability is central to every aspect of our operations. Embracing a sustainable approach is crucial in our efforts to combat global climate change. Environmental footprint Greenhouse gasses emitted into the environment during production of a product contribute directly to our planet’s global warming. Using LCA software1 we are able to calculate2 the (potential) environmental footprint, measured in kilograms CO2-equivalent. This enables us to evaluate a product’s footprint and support the design of sustainable products. By recycling our products the impact on the environment can be reduced as the recycled material replace the need to produce virgin materials. GREENSHEET Sit-stand workstation This product is made from the following materials: Steel 79% Aluminium 15% ABS 3% PE 2% PA 1% POM 0,1% MA D E WI T H R E C Y C L E D MA T E R I A L S WL90-325BL1 Steel Aluminium ABS PE PA POM Total Material weight (g) 5756,3 1058,5 249,7 171,4 43,3 9,4 7.289 Kilograms CO2 equivalent When not recycled 21,6 15,9 1,5 0,66 0,41 0,04 40,09 When recycled 13,2 9,3 1,5 0,7 0,4 0,03 25,10 Total recycling reduction 37% To illustrate the impact of one kilogram of carbon dioxide, we’ve converted it into the equivalent distance a car would travel in kilometers. Emitted carbon dioxide with recycling without recycling 25,10 CO2 40,08 CO2 76,10 KM 121,50 KM *8 litres of petrol per 100 km² Sources: ¹ Mobius Ecochain - Ecoinvent v3.6, ² According to EN15804+A2, 3 Foundation myclimate; based on 8 litres of pertrol per 100 km WL90-325BL1 www.btechavmounts.com B-Tech AV Mounts is dedicated to making sustainable product choices that prioritise recyclability. We are committed to investing in a circular economy, where sustainability is central to every aspect of our operations. Embracing a sustainable approach is crucial in our efforts to combat global climate change. Environmental footprint Greenhouse gasses emitted into the environment during production of a product contribute directly to our planet’s global warming. Using LCA software1 we are able to calculate2 the (potential) environmental footprint, measured in kilograms CO2-equivalent. This enables us to evaluate a product’s footprint and support the design of sustainable products. By recycling our products the impact on the environment can be reduced as the recycled material replace the need to produce virgin materials. GREENSHEET Sit-stand workstation This product is made from the following materials: Steel 79% Aluminium 15% ABS 3% PE 2% PA 1% POM 0,1% MA D E WI T H R E C Y C L E D MA T E R I A L S WL90-325BL1 Steel Aluminium ABS PE PA POM Total Material weight (g) 5756,3 1058,5 249,7 171,4 43,3 9,4 7.289 Kilograms CO2 equivalent When not recycled 21,6 15,9 1,5 0,66 0,41 0,04 40,09 When recycled 13,2 9,3 1,5 0,7 0,4 0,03 25,10 Total recycling reduction 37% To illustrate the impact of one kilogram of carbon dioxide, we’ve converted it into the equivalent distance a car would travel in kilometers. Emitted carbon dioxide with recycling without recycling 25,10 CO2 40,08 CO2 76,10 KM 121,50 KM *8 litres of petrol per 100 km² Sources: ¹ Mobius Ecochain - Ecoinvent v3.6, ² According to EN15804+A2, 3 Foundation myclimate; based on 8 litres of pertrol per 100 km WL90-325BL1 Governance As part of our commitment to environmental responsibility, B-Tech is eliminating plastic from our packaging across the entire product range and reducing waste by recycling 100% of excess cardboard. Our Green Sheets are one of the ways we provide clear, straightforward information about our sustainability efforts. B-Tech AV Mounts is a member of the Sedex platform for ethical trade and is committed to transparency and accountability throughout its global supply chain. This membership allows B-Tech to monitor, manage and report on ethical performance in key areas including labour rights, health & safety, environment and business ethics. Management System As part of Global Mounts Group, our management structure combines responsible leadership and independent oversight. Company directors work closely with department leaders to set environmental goals, including transitioning to recyclable materials and waste management practices. Development Goals To strengthen our environmental performance, we continuously evaluate our use of sustainable materials, re-think product life-cycles, and introduce new green initiatives that support long term sustainability. We remain committed to delivering high quality products, services and solutions while fully complying with all applicable laws and international standards. Environmental Risk Management Environment considerations are integrated into our manufacturing processes, supply chains, R&D and sales. We continuously monitor our global operations with a focus on environment protection, safety, climate change, energy use and regulatory compliance. Our risk management approach is designed to provide reasonable assurance that we will meet both our strategic and operational sustainability objectives. About B-Tech AV Mounts
B-Tech AV Mounts 6 System X Menu Board Mounts Wall Wall / Pop-Out Ceiling Curved BT8330 BT8331 BT8332 BT8333 Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm System Xpert dvLED Mounts Wall Freestanding Mobile Bolt-Down BT9340 BT9370 BT9371 BT9372 BT9377 Modular Full Service Wall Mounts Wall / Pop-Out BT8309 BT8312 BT8310XL Max screen size: 42" Max load: 55lbs Mounting patterns: 75x75 up to 200x200 Distance from wall: 3" - 7.5" Max screen size: 75" Max load: 110lbs Mounting patterns: 200x100 to 600x400 Distance from wall: 3" - 8.75" Max screen size: 120" Max load: 275lbs Mounting patterns: 200x100 to 600x400 Distance from wall: 4" - 11.5" XXL Digital Signage Wall Wall / Pop-Out BT9920 BT9921 BT9925 BT9926 Max screen size: 72" - 120" Max load: 440lbs Mounting patterns: up to 1600x800mm Distance from wall: 2" Max screen size: 72" - 120" Max load: 176lbs Mounting patterns: up to 1600x800mm Distance from wall: 5" - 11" Max screen size: 72" -120" Max load: 176lbs Mounting patterns: up to 800x1600 Distance from wall: 5" - 11" Max screen size: 72" -120" Max load: 440lbs Mounting patterns: up to 1600x800 Distance from wall: 6" - 13" XXL Micro-Adjustment Micro-Adjustment Micro-Adjustment Micro-Adjustment Micro-Adjustment Micro-Adjustment dvLED / Multi-Screen / Digital Signage Mounts Quick Reference Guide Slimline BT9371-RM rear mounted BT9371-FM front mounted BT9372-RM rear mounted BT9377-RM rear mounted BT9372-FM front mounted BT9377-FM front mounted BT9340-RM rear mounted BT9340-FM front mounted BT9370-RM rear mounted BT9370-FM front mounted Portrait Retractable Base Digital Signage Wall Rotation BT7550 Max screen size: 65" Max load: 154lbs Mounting patterns: up to 400x400 Screen rotation: 90° Portrait Portrait BT8322 Max screen size: 65" Max load: 176lbs Mounting patterns: up to 400x600mm Distance from wall: 1.4" BT9923 Max screen size: 105"-120" Max load: 440lbs Mounting patterns: up to 600x1500mm Distance from wall: 2" XXL Ultrawide System X Videowall Floor Stands Freestanding Mobile Bolt-Down BT8370 BT8371 BT8372 BT8377 Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Retractable Base
7 info@btechavmounts.com 7 System Xpress dvLED Mounts Wall Freestanding Mobile Bolt-Down Ceiling BTXPS27-W BTXPS27-S BTXPS27-M BTXPS27-B BT9242 Custom configuration available This quick reference guide provides a brief overview of the B-Tech range of Multi-Screen Videowall Mounts, dvLED displays and Digital Signage mounting solutions. For more information on each product, please visit www.btechavmounts.com for full specifications. Customize meet your requirements through our convenient online configuration tool at www.btechavmounts.com/led-panel-configurator or www.btechavmounts.com/systemx-configurator. Configure Online Kits: 4x4, 5x5, 6x6 & 8x8 Custom configuration Kits: 4x4, 5x5, 6x6 & 8x8 Custom configuration Kits: 4x4, 5x5, 6x6 & 8x8 Custom configuration Kits: 4x4, 5x5, 6x6 & 8x8 Custom configuration Freestanding Bolt-Down Ceiling BT7004 Max screen size: 65" Max load: 110lbs Mounting patterns: up to 600x400mm BT8577 Max screen size: 75" Max load: 110lbs Mounting patterns: up to 600x400mm BT8587 Max screen size: 86" Max load: 154lbs Mounting patterns: up to 600x800mm BT7003 Max screen size: 65" Max load: 110lbs Mounting patterns: up to 600x400mm BT8325 For use with: 55" Samsung OMN-D Series BT8326 For use with: 55" Samsung OMN-D Series OMN-D Series OMN-D Series Pole Column Screen Enclosure Retractable Base Retractable Base Screen Enclosure System X Videowall Mounts Wall Wall / Pop-Out Ceiling Curved BT8340 BT8341 BT8342 BT8343 Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm System X Curved Videowall Mounts Freestanding Mobile Bolt-Down BT8373 BT8376 BT8374 BT8375 Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm Max screen size: 75" Max load: 110lbs per screen Mounting patterns: up to 900mm E-Paper Mounts Wall Freestanding Ceiling BT7611-SAM32 Max screen size: 32" Max load: 10kg Mounting patterns: up to 200x200mm Tilt: +/-10° BT7613-SAM32 Max screen size: 32" Max load: 10kg per screen Mounting patterns: up to 200x200mm Tilt: +/-15° BT7671-SAM32 Max screen size: 32" Max load: 10kg Mounting patterns: up to 200x200mm Tilt: +/-10° BT7611 Max screen size: 43" Max load: 10kg Mounting patterns: up to 200x200mm Tilt: +/-10° BT7612 Max screen size: 43" Max load: 10kg Mounting patterns: up to 200x200mm Tilt: +/-35° BT7612-SAM32 Max screen size: 32" Max load: 10kg Mounting patterns: up to 200x200mm Tilt: +/-15° BT7613 Max screen size: 43" Max load: 10kg per screen Mounting patterns: up to 200x200mm Tilt: +/-20° EMDX Series EMDX Series EMDX Series EMDX Series
B-Tech AV Mounts 8 Twin Screen Video Conferencing Bolt-Down Freestanding Mobile Mode-AL Floor Stands Floor-To-Wall Floor-To-Ceiling Bolt-Down Freestanding Carts Mobile Flip Rotation Flip Rotation BT8562 Max screen size: 75" Max load: 154lbs Mounting patterns: up to 600x400 Dimensions: H:74" W:40.5" D:30.2" BT8547 Max screen size: 65" Max load: 110lbs Screen rotation: 90° Mounting patterns: up to 400x400 Dimensions: H:63" W:29.5" D:26" BT8564 Max screen size: 65" - 120" Max load: 285lbs Mounting patterns: up to 1000x600 Dimensions: H:75" W:48.5" D:30" BT8566 Max screen size: 75" Max load: 154lbs Screen rotation: 90° Mounting patterns: up to 600x400 Dimensions: H:76" W:42.3" D:34" BT8701 Max screen size: 75" Max load: 154lbs Mounting patterns: up to 600x400 Dimensions: H:77.5" W:27.7" D:6.5" BT8702 Max screen size: 75" Max load: 154lbs Mounting patterns: up to 600x400 Dimensions: H:80.7-106.3" W:27.7" D:8.3" BT8704 Max screen size: 75" Max load: 154lbs Mounting patterns: up to 600x400 Dimensions: H:75.2" W:27.7" D:8.3" BT8527 For screen sizes: 65"- 75" Max load: 220lbs per screen Mounting patterns: up to 1000x800 Dimensions: H:76" W:96.5" D:37.4" BT8528 For screen sizes: 75"- 86" Max load: 220lbs per screen Mounting patterns: up to 1000x800 Dimensions: H:76" W:118" D:37.4" VC Shelf VC Shelf VC Shelf VC Shelf VC Shelf VC Shelf BTF845 For screen sizes: 46"- 55" Max load: 55lbs per screen Mounting patterns: up to 600x400 Dimensions: H:72.5" W:69" D:23.8" XXL Floor Stands / Carts Quick Reference Guide System X Floor Stands Freestanding XL Portrait BTF840 Max screen size: 39"-75" Max load: 155lbs Mounting patterns: up to 600x400 Dimensions: H:72.5" W:35" D:23.8" BTF843 Max screen size: 65"- 85" Max load: 155lbs Mounting patterns: up to 800x600 Dimensions: H:72.5" W:35" D:23.8" Dual Stack Landscape Dual Stack Portrait BTF842 Max screen size: 47"- 65" Max load: 77lbs per screen Mounting patterns: up to 600x400 Dimensions: H:96" W:35" D:23.8" BTF841 Max screen size: 32"- 65" Max load: 77lbs per screen Mounting patterns: up to 600x400 Dimensions: H:72.5" W:35" D:23.8" BT8537 For screen sizes: 65"- 75" Max load: 220lbs per screen Mounting patterns: up to 1000x800 Dimensions: H:72" W:96.5" D:9.5" BT8538 For screen sizes: 75"- 86" Max load: 220lbs per screen Mounting patterns: up to 1000x800 Dimensions: H:72" W:118" D:9.5" XXL BT8706 Max screen size: 75" Max load: 154lbs Mounting patterns: up to 600x400 Dimensions: H:76.5" W:26.5" D:29.6" BT8709 Max screen size: 65" - 100" Max load: 220lbs Mounting patterns: up to 900x800 Dimensions: H:76.5" W:44.4" D:29.6" BT7504 Max screen size: 55" Max load: 55lbs Mounting patterns: up to 400x400 Dimensions: H:47.6" W:30" D:18" BT8514 For screen sizes: 39"- 46" Max load: 88lbs per screen Mounting patterns: up to 400x400 Dimensions: H:75" W:59.2" D:34"
9 info@btechavmounts.com 9 Mode-AL Twin Screen Video Conferencing Floor-To-Wall Bolt-Down Freestanding BT8710 Max screen size: 65" Max load: 155lbs per screen Mounting patterns: up to 600x400 Dimensions: H:77.5" W:78.7" D:6.5" BT8711 Max screen size: 65" Max load: 155lbs per screen Mounting patterns: up to 600x400 Dimensions: H:75.2" W:78.7" D:8.3" BT8712 Max screen size: 65" Max load: 123lbs per screen Mounting patterns: up to 600x400 Dimensions: H:76.5" W:78.7" D:29.6" VC Shelf VC Shelf VC Shelf Floor-To-Wall Bolt-Down XL Carts Mobile Floor-To-Wall XXL XXL BT8708 Max screen size: 65" - 100" Max load: 310lbs Mounting patterns: up to 900x800 Dimensions: H:75.2" W:39.4" D:8.3" BT8546 Max screen size: 110" Max load: 275lbs Mounting patterns: up to 1000x800 Dimensions: H.70" W.49" D.30" BT8559 Max screen size: 100" Max load: 220lbs Mounting patterns: up to 900x600 Dimensions: H:52"-77" W:39" D:10"-10.7" BT8545 Max screen size: 86" Max load: 220lbs Mounting patterns: up to 800x600 Dimensions: H:68" W:41" D:35" BT8707 Max screen size: 65" - 100" Max load: 440lbs Mounting patterns: up to 900x800 Dimensions: H:77.5" W:39.4" D:6.5" This reference guide gives a quick overview of the B-Tech range of Flat Screen Floor Stands and Carts. For full specifications and to view all other products and accessories, please visit our website at www.btechavmounts.com Note, max screen sizes are recommendations only and it may be possible to mount other sizes, please refer to the screen's weight and mounting pattern to find the best compatible mount. Mobile Floor-To-Wall Wall BT8517 For screen sizes: 65"- 75" Max load: 220lbs per screen Mounting patterns: up to 1200x800 Dimensions: H:78.75" W:96.5" D:37.4" BT8415 For screen sizes: 39"- 46" Max load: 154lbs per screen Mounting patterns: up to 400x400mm Distance from wall: 2.4" BT8416 For screen sizes: 46"- 65" Max load: 154lbs per screen Mounting patterns: up to 600x400mm Distance from wall: 2.4" BT8516 For screen sizes: 46"- 65" Max load: 154lbs per screen Mounting patterns: up to 600x400 Dimensions: H:75" W:78.9" D:39" XXL XXL Motorized Motorized Motorized Motorized Touchscreen Floor Stands Freestanding BT8572 Max screen size: 55" Max load: 88lbs Mounting patterns: up to 600x400 Dimensions: H:72" W:31.5" D:23.6" BT8571 Max screen size: 47" Max load: 55lbs Mounting patterns: up to 200x200 Dimensions: H:72" W:27.5" D:20.3" BT8583 Max screen size: 75" Max load: 154lbs Mounting patterns: up to 600x400 Dimensions: H:72.6" W:31.5" D:23.6" BT8581 Max screen size: 47" Max load: 77lbs Mounting patterns: up to 200x200 Dimensions: H:72.6" W:27.5" D:20.3" BT8573 Max screen size: 75" Max load: 154lbs Mounting patterns: up to 600x400 Dimensions: H:72" W:31.5" D:23.6" BT8582 Max screen size: 55" Max load: 88lbs Fits VESA patterns: up to 600x400 Dimensions: H:72.6" W:31.5" D:23.6" VC Shelf VC Shelf VC Shelf VC Shelf VC Shelf VC Shelf BT8558 Max screen size: 86" Max load: 220lbs Mounting patterns: up to 1000x600 Dimensions: H:43.5 - 69" W.42.75" D:32" Touchscreen BT8557 Max screen size: 65" Max load: 55lbs per screen Mounting patterns: up to 600x400 BT8556 Max screen size: 65" Max load: 55lbs per screen Mounting patterns: up to 600x400 BT8590 Max screen size: 72" - 120" Max load: 285lbs Mounting patterns: up to 1600x800mm Dimensions: H:75" W:69" D:30"
B-Tech AV Mounts 10 XX-Large Pull-Out Double Arm Small Fixed Tilt Tilt & Swivel Single Arm X-Large Fixed Tilt Large Fixed Tilt Medium Fixed Tilt BT8441 Max screen size: 65" Max load: 176lbs Mounting patterns: up to 400x400 Distance from wall: 1.2" BTV510 Max screen size: 55" Max load: 110lbs Mounting patterns: up to 400x400 Distance from wall: 0.8" BT7510 Max screen size: 28" Max load: 44lbs Mounting patterns: 50x50, 75x75 & 100x100 Distance from wall: 0.6" BT7511 Max screen size: 28" Max load: 44lbs Mounting patterns: 75x75 & 100x100 Tilt: +17/-10° BT7518 Max screen size: 28" Max load: 22lbs Mounting patterns: 50x50, 75x75 & 100x100 Tilt: +17/-10° Swivel: 50° Screen rotation: 360° BT8442 Max screen size: 80" Max load: 176lbs Mounting patterns: up to 600x400 Distance from wall: 1.2" BTV520 Max screen size: 65" Max loa d: 154lbs Mounting patterns: up to 800x500 Distance from wall: 0.8" BT8200 Max screen size: 47" Max load: 88lbs Mounting patterns: up to 200x200 Distance from wall: 0.5" BTV500 Max screen size: 47" Max load: 88lbs Mounting patterns: up to 200x200 Distance from wall: 0.8" BT7523 Max screen size: 47" Max load: 55lbs Mounting patterns: up to 200x200 Tilt: +/-15° BT7512 Max screen size: 28" Max load: 22lbs Mounting patterns: up to 100x100 Tilt: +17/-10° Swivel: 180° Screen Rotation: 360° Distance from wall: 1.6" - 11" BT8237 Max screen size: 75" Max load: 176lbs Mounting patterns: up to 600x400mm Swivel: 120° Distance from wall: 3" - 27.5" BT7532 Max screen size: 47" Max load: 88lbs Mounting patterns: up to 200x200 Distance from wall: 0.6" Flat Screen Wall Mounts Quick Reference Guide BT8227 Max screen size: 75" Max load: 110lbs Mounting patterns: up to 600x400mm Tilt: +14/-3° Swivel: 180° Distance from wall: 2.5" - 22.9" BT8443 Max screen size: 75" Max load: 77lbs Mounting patterns: up to 650x400mm Tilt: +10/-2 ° Swivel: 28° Distance from wall: 2.4" - 8.7" BT5227 Max screen size: 75" Max load: 99lbs Mounting patterns: up to 600x400mm Tilt: +12/-2 ° Swivel: 180° Distance from wall: 2.4" - 28.4" BT5432 Max screen size: 80" Max load: 154lbs Mounting patterns: up to 600x400mm Tilt: +15° BT5442 Max screen size: 80" Max load: 154lbs Mounting patterns: up to 600x400mm Distance from wall: 1.2" BT5441 Max screen size: 65" Max load: 110lbs Mounting patterns: up to 400x400mm Distance from wall: 1.2" BT5431 Max screen size: 65" Max load: 110lbs Mounting patterns: up to 400x400mm Tilt: +15°
11 info@btechavmounts.com 11 Fixed Tilt Double Arm Tilt Double Arm Tilt & Swivel Single Arm Double Arm Double Arm BT7514 Max screen size: 47" Max load: 55lbs Mounting patterns: up to 200x200 Tilt: +/-40° Swivel: 180° Distance from wall: 1.8" - 13.2" BT7519 Max screen size: 47" Max load: 66lbs Mounting patterns: up to 200x200 Tilt: + 17°/-10° Swivel: 80° BT7515 Max screen size: 47" Max load: 55lbs Mounting patterns: up to 200x200 Tilt: +/-40° Swivel: 180° Distance from wall: 1.8" - 18.7" BTV504 Max screen size: 47" Max load: 55lbs Mounting patterns: up to 200x200 Tilt: +/-15° Swivel: 180° Screen rotation: 360° Distance from wall: 3" - 15" BT7513 Max screen size: 28" Max load: 22lbs Mounting patterns: 50x50, 75x75 & 100x100 Tilt: +17/-10° Swivel: 180° Screen rotation: 360° Distance from wall: 1.6" - 18.4" BT8431 Max screen size: 65" Max load: 110lbs Mounting patterns: up to 400x400 Tilt: +/-15° BTV513 Max screen size: 55" Max load: 77lbs Mounting patterns: up to 400x400 Tilt: +10/-2° Swivel: 180° Distance from wall: 1.6" - 17.7" BT9901 Max screen size: 65" - 100" Max load: 220lbs Mounting patterns: up to 900x600 Distance from wall: 1.2" This reference guide gives a quick overview of the B-Tech range of Flat Screen Wall Mounts. To view the complete range, full specifications, product photos and technical drawings, please visit our website at www.btechavmounts.com Note, max screen sizes are recommendations only and it may be possible to mount other sizes, please refer to the screen's weight and mounting pattern to find the best compatible mount. Tilt Double Arm BT8432 Max screen size: 80" Max load: 154lbs Mounting patterns: up to 600x400 Tilt: +/-15° BT8228 Max screen size: 65" - 120" Max load: 275lbs Mounting patterns: up to 800x600mm Tilt: +15/-3 ° Swivel: 130° Distance from wall: 3.5" - 24.75" BT8229 Max screen size: 65" Max load: 77lbs Mounting patterns: up to 600x400mm Tilt: +14°/-3° Swivel: 180° Distance from wall: 2" - 22.6" Medical Mounts Wall BT7592 Max screen size: 28" Max load: 7-11lbs Mounting patterns: 75x75 & 100x100 Tilt: +/-100 Swivel: 180° Screen rotation: 360° Extension: 65" BT7593 Max screen size: 28" Max load: 11-18lbs Mounting patterns: 75x75 & 100x100 Tilt: +/-100 Swivel: 180° Screen rotation: 360° Extension: 65" VESA Adapters Adapters BT7540 Fits VESA patterns: 300x200 & 400x200 BT7542 Fits VESA patterns: 200x100 & 200x200 BT7565 Fits VESA patterns: 900x400 & 800x400 BT7502 Fits VESA patterns: 200x100 & 200x200 BT9910 Max screen size: 65" - 100" Max load: 285lbs Mounting patterns: up to 1000x600 Tilt: +15° BT9903 Max screen size: 65" - 120" Max load: 440lbs Mounting patterns: up to 1000x600 Distance from wall: 1.4" BT5229 Max screen size: 65" Max load: 77lbs Mounting patterns: up to 600x400mm Tilt: +12°/-2° Swivel: 180° Distance from wall: 2.1" - 19.5"
B-Tech AV Mounts 12 Projector Mounts Ceiling Ceiling Mounts Ceiling Desktop Mounts Clamp & Grommet BT7553 Max screen size: 32" Max load: 50lbs Mounting patterns: 75x75 & 100x100 Tilt: +90°/-15° Swivel / Screen Rotation: 360° BT8424 Max screen size: 65" Max load: 110lbs Mounting patterns: up to 600x400mm Tilt: +/-15° BT8426 Max screen size: 65" Max load: 110lbs Mounting patterns: up to 600x400 Tilt: +/-15° BT8427 Max screen size: 75" Max load: 154lbs Mounting patterns: up to 600x400 Tilt: up to +20° Swivel BT899XL Max load: 55lbs Max fixing pattern: up to 19.5" Ceiling drop: 3.9" BT899XL-AD Max load: 55lbs Max fixing pattern: up to 19.5" Ceiling drop: 28.7" - 44.4" BT899 Max load: 55lbs Max fixing pattern: up to 14.5" Ceiling drop: 4.8" BT899-AD Max load: 55lbs Max fixing pattern: up to 14.5" Ceiling drop: 29.25" - 45" BT899-FD Max load: 55lbs Max fixing pattern: up to 14.5" Ceiling drop: 20"/40"/60"/80"/120" Adjustable Drop Adjustable Drop Adjustable Drop Adjustable Drop Heavy Duty Triple Screen Twin Screen Widescreen Additional Mounting Solutions Quick Reference Guide BT7870 Universal Mounting Plate for Bose, Cisco, Jabra, Logitech, Maxhub, Neat, Predia, Poly & Yealink videobars *Mounts to back of screen BT7351 Max screen size: 32" Max load: 20lbs per scree Mounting patterns: 75x75 & 100x100 Tilt: +60°/-60° Swivel: 360° Screen Rotation: 360° BT7352 Max screen size: 32" Max load: 20lbs per screen Mounting patterns: 75x75 & 100x100 Tilt: +60°/-60° Swivel: 360° Screen Rotation: 360° BT7353 Max screen size: 32" Max load: 20lbs per screen Mounting patterns: 75x75 & 100x100 Tilt: +/-60° Swivel: 360° Screen Rotation: 360° BT7355 Max screen size: 49" Max load: 44lbs Mounting patterns: 75x75 and 100x100 Tilt: +5°/-55° Swivel: 360° Screen Rotation: 360° Video Bar Mounts Video Bar Mounting Plates BT7871 Mounting Plate for Jabra Panacast 50 Poly Studio / X50 / X52 / X70 Lenovo ThinkSmart Bar 180 BT7873 Mounting Plate for Logitech Rally Bars BT7874 Mounting Plate for Dual Logitech Rally Plus Speakers Aver VB342PRO Cisco Webex Room Kit Plus BT7875 Mounting Plate for Yealink UVC40 / A20 / MeetingEye 400, Logitech Meet Up Poly Studio X30 Max screen size: 100" Max load: 22lbs Mounting patterns: up to 800x400 Universal Screen Mount
13 info@btechavmounts.com 13 Ceiling Ceiling BT8428 Max screen size: 65" Max load: 110lbs per screen Mounting patterns: up to 600x400 Tilt: +/-15° BT8448 Max screen size: 120" Max load: 286lbs Mounting patterns: up to 1000x600 BT8449 Max screen size: 100" Max load: 176lbs Mounting patterns:up to 1000x600 Tilt: up to +15° BT893-AD Max load: 154lbs Max fixing pattern: up to 31" Ceiling drop: 30.1" - 46.7" BT893-FD Max load: 154lbs Max fixing pattern: up to 31" Ceiling drop: 20"/40"/60"/80"/120" BT893 Max load: 154lbs Max fixing pattern: up to 31" Ceiling drop: 6" Adjustable Drop BT899XL-FD Max load: 55lbs Max fixing pattern: up to 19.5" Ceiling drop: 20"/40"/60"/80"/120" Back-To-Back XXL XXL Tilt This reference guide gives a quick overview of B-Tech's Additional Mounting Solutions, visit www.btechavmounts.com for full specifications. For unique & more complex installations, please see our Component Products from page 62 and see how custom solutions can be configured & ordered Media Storage Mounts Wall Pull-Down Slide-Out AV Storage AV Storage Pull-Out AV Storage BT7883 Max screen size: 46" - 75" Max screen weight: 154lbs Max equipment load: 22lbs Mounting patterns: 200x200 up to 600x400 BT7885 Max screen size: 49" - 86" Max screen weight: 154lbs Max equipment load: 18lbs Mounting patterns: 200x200 up to 600x400 Video Bar Mounting Plates BT7877 Mounting Plate for Bose Videobar VB1 / VB-S Logitech Rally Plus Speakers, Neat.Bar / Neat.Bar Pro Yealink MspeakerII BT7878 Mounting Plate for Yealink A30 / MeetingEye 600 BT7879 Mounting Plate for Biamp Parlé Video & Audio Conferencing Bars / Speakers Levono ThinkSmart One Speaker Mounts Soundbar Wall BTV914 Max load: 22lbs Height adjustable: 9.85" Lateral adjustable: 4.40" *Mounts to back of screen BT77 Max load: 55lbs Tilt: +/-10° Swivel: 360° Adjustable clamp width: 5.3" - 11" Side Clamping BT7896 Max screen size: 75" Max screen weight: 154lbs Mounting patterns: 200x200 up to 600x400 Tilt: + 10°/-2° BT7889 Max load: 22lbs Max AV equipment size: 17.7" x 11" BT7888 Max load: 22lbs Max AV equipment size: 17.7" x 9.8" AV Storage Slide-Out AV Storage
B-Tech AV Mounts 14 Discover the Ultimate dvLED Mounting Solutions by B-Tech AV Mounts Over the past decade B-Tech AV Mounts has continuously expanded and refined one of the most comprehensive and versatile dvLED mounting systems on the market. Our award-winning solutions are trusted globally across a wide range of projects, from compact installations to large-scale, high-profile AV set-ups. Whatever the size or scope, we have the perfect solution for you. These three specialized ranges are tailored to meet diverse requirements, offering unparalleled flexibility and convenience. dvLED Videowall Mounting Solutions London, Oxford Street 400sqm dvLED wall using System Xpert Future Stores
15 info@btechavmounts.com 15 Mounting solutions for DI SPLAYS System Xpert, the installers choice, is a premium range of dvLED mounting solutions trusted for its quality, ease of use, adjustability and fast installation. It meets every need, from simple small format wall mounts to extra-large, curved, odd shaped or even ceiling setups. Configurations can be generated using our online configuration tool. For more ambitious projects, our expert engineers can assist with bespoke specifications via email at technical@btechavmounts.com. The range includes detailed documentation, pre-assembled components and precision engineered Interface components for your specific application. System Xpress revolutionises dvLED mounting supply with its innovative, universal design for latching cabinets. Featuring Patent Pending Xpress Connectors instead of screen-specific interface arms, this system offers unmatched versatility. The connectors click into your cabinets and lock effortlessly into supplied rails, enabling wall, floor, or ceiling installations with precision. Pre-configured in the most popular 16:9 layouts and stocked for immediate availability, System Xpress eliminates the need for custom fabrication, making it the fastest and easiest way to receive your dvLED mounting solution. Our System AIO range provides dedicated mounting solutions for the most popular all-in-one dvLED displays on the market. Offering wall-mounted, floor-standing, and mobile options, System AIO supports leading brands such as Absen, LG, Philips, Samsung and Sharp, ensuring a perfect fit for your display requirements. dvLED Videowall Mounting Solutions
B-Tech AV Mounts 16 Making dvLED installation simple Floor Base with Level Adjustment Suitable for uneven floors Depth and Height Adjustment Brackets Precision alignment on uneven surfaces Retractable Floor Base Allows easy access to the front of AV displays Ideal for shop window displays All dvLED Solutions include Cut to Size parts No on-site cuts required Service Pre-assembly of component parts B-Tech's Service+ offers customers a fully integrated service tailored specifically for our System Xpert dvLED solutions. Our team of in-house engineers delivers: • Bespoke, installation-specific technical drawings. • Pre-assembly of component parts for added convenience. • Precision-cut rail lengths customised to your exact specifications - a feature that sets us apart from competitor services. Best of all, this service is provided free of charge for System Xpert Solutions. dvLED Mounting Solutions available for all major brands... Installation specific technIcal drawings with all required dimensions for a straight forward assembly To ensure the precise installation of dvLED cabinets, B-Tech provides a range of features in our dvLED solutions, including custom cut-to-size parts for every order. Our System X components are designed with level, depth, height, and angle adjustments, ensuring they meet diverse mounting requirements. These innovations make the installation of dvLED video walls straightforward, efficient, and highly adaptable to any set-up.
17 info@btechavmounts.com 17 Recommended Max configuration size Unlimited 10x10 All-in-One Production lead time (working days) 25 days 4-8 days 4-8 days Universal compatibility Designed and manufactured in accordance with the customer's cabinets All 'latching' cabinets Absen / LG / Samsung All-In-One displays Function Wall, Floor, Mobile, Bolt-Down, Ceiling Hung, Ceiling Flat, Curved, Bespoke Wall, Floor, Mobile, Bolt-Down, Ceiling Hung Wall, Floor, Mobile, Bolt-Down Install time Fast Medium Fast Rear Mount Front Mount Micro-adjustment on wall plate Height & depth up to +/-0.4"* Height & depth +/-0.2" Height & depth +/-0.4" Height micro-adjustment on interface 0.8" 0.8" Depth adjustment Rails cut to size Pre-assembly with Technical drawings provided by Install specific drawings provided General installation guide with clear instructions provided for configurations outside of stocked packages Provided with stocked packages Provided with stocked packages Indoor / Outdoor use Indoor & Outdoor* Indoor Indoor Service Service *Depending on application Mounting solutions for DI SPLAYS dvLED Videowall Mounting Solutions
B-Tech AV Mounts 18 BT9342 dvLED Ceiling Mount for any configuration BT9344 dvLED Floor-To-Ceiling Mount for any configuration Examples of configurations are shown below; all configurations are available. Configure to your requirements using our online configurator, or contact technical@btechavmounts.com for more advanced set-ups. BT9340 dvLED Wall Mount for any configuration Depth and Height Adjustment Brackets Precision alignment on uneven surfaces Depth and Height Adjustment Brackets Precision alignment for ceiling mounted solutions Depth and Height Adjustment Brackets Precision alignment for ceiling mounted solutions dvLED Mounts & Stands
19 info@btechavmounts.com 19 www.btechavmounts.com/led-panel-configurator See online for more information about our online configurator. www.btechavmounts.com/led-panel-configurator BT9372 dvLED Bolt-Down Stand for any configuration BT9370 dvLED Videowall Stand for any configuration Optional Adjustable Floor Base with level adjustment for uneven floors BT9371 dvLED Mobile Stand for any configuration BT9377 dvLED Bolt-Down Stand with Retractable Base for any configuration Retractable Floor Bases Ideal for close to window installs dvLED Mounts & Stands
B-Tech AV Mounts 20 Examples of configurations are shown below; all configurations are available. Configure to your requirements using our online configurator, or contact technical@btechavmounts.com for more advanced set-ups. dvLED Mounts & Stands dvLED Curved mounts designed for Latching Curved Cabinets BT9343 dvLED Curved Wall Mount for any configuration BT9373 dvLED Curved Stand for any configuration BT9375 dvLED Curved Bolt-Down Stand for any configuration Depth and Height Adjustment Brackets Precision alignment on uneven surfaces Optional Adjustable Floor Base with level adjustment for uneven floors Adjustable Levelling Feet to allow for uneven floor surfaces
21 info@btechavmounts.com 21 www.btechavmounts.com/led-panel-configurator See online for more information about our configurator. www.btechavmounts.com/led-panel-configurator dvLED Mounts & Stands BT9350 Internal dvLED Corner Wall Mount BT9351 External dvLED Corner Wall Mount BT9352 Cube dvLED Videowall Mount BT9376 dvLED Curved Wave Bolt-Down Stand for any configuration Bolt-Down Floor Bases with level adjustment for uneven floors Depth and Height Adjustment Brackets Precision alignment on uneven surfaces BT9378 dvLED Motorized Height Adjustable Mobile Stand
