For More Information Visit B-TECH PROFESSIONAL 37
BT884 Short Throw
Short ThrowProjectorWall Mount
with Adjustable Arm
 Designed for Short Throw Projectors
up to 10kg (22lbs)
 Features +/-20° tilt and +/-20° roll
 Telescopic design for correct
projector positioning
 Cable management included
 Coverplate included for smart installation
 Maximum distance between
any two fixing points: 300mm (11.8”)
Available in 2 lengths
BT884-M
 Telescopic arm mounts projector
400mm (15.7”) - 575mm (22.6”) fromwall
BT884-L
 Telescopic arm mounts projector
880mm (34.6”) - 1510mm (59.4”) fromwall
20˚
20˚
10kg
 Designed for projectors
up to 10kg (22lbs)
 Features +/-90° tilt, +/-90° roll
and 360° swivel
 Suitable for angled / cathedral ceilings
 Maximum distance between any two
fixing points on projector: 340mm (13.5”)
 Hand lever for easy adjustment
of ceiling drop:
BT882 - Adjustable Drop
Min: 580mm (22.8”)
Max: 830mm (32.7”)
BT883 - Long Adjustable Drop
Min: 830mm (32.6”)
Max: 1330mm (52.3”)
Projector CeilingMount
with Adjustable Drop
BT882
BT883
Adjustable Drop
Mobile Projector Trolley/Stand
BT890 Projector Trolley
 Designed for use with projectors but
may also be used as a mobile lectern
 Maximum load 25kg (55lbs)
 Supplied with braked castors and
optional levelling feet for extra stability
 Supplied with safety rails and safety
strap for secure installation
 Adjustable height (with castors):
785mm (30.9”) - 1265mm (49.8”)
 Adjustable height (with feet):
730mm (28.7”) - 1230mm (48.4”)
 Platform dimensions:
290mm (11.4”) x 360mm (14.2”)
 Adjustable tilt: +/-20˚
 Inner pole diameter: 35mm (1.4”)
 Outer pole diameter: 42mm (1.7”)
 Easy to assemble
RegisteredDesignNumber:3016251
10kg
20˚
20˚
25kg
BT881
 Designed for projectors
up to 10kg (22lbs)
 Mounts projector only 115mm (4.5”)
from ceiling or 280mm (11”) with
supplied extension rod
 Features +/-90° tilt adjustment, +/-90°
roll adjustment and 360° swivel
 Maximum distance between any two
fixing points on projector: 340mm (13.5”)
Projector Ceiling Mount
Short Drop BT899 Heavy Duty
Projector Ceiling Mount
with Micro-Adjustment
 Designed for projectors
up to 25kg (55lbs)
 Compatible with the B-Tech System 2 ™
Professional Range and NPT pipe systems
(see page 43 for more info)
 Features +/-13° tilt, +/-6° roll and 360° swivel
 Maximum distance between any two fixing
points: 370mm (14.6”)
10kg
RegisteredDesignNumber:001713306-0004
13˚
13˚
360° 6˚
6˚
25kg
Adjustable Projector Mounts Projector
Mounts
BT899-XL Extra Large Projector Ceiling
Mount withMicro-Adjustment
 Maximum distance between any two fixing points: 493mm (19.4”)
 Compatible with System 2 (see page 43 for more info)
BT7030 Accessory
Shelf also available
(separately)
see page 27
20˚
20˚
