2016 B-Tech Catalogue

34 / 100

Medical
Mounts
For More Information Visit B-TECH PROFESSIONAL 34
Medical Mounts
 Designed for flat screens up to 23”(58cm)
 BT7592 is suitable for screens weighing 3 to 5kg
 BT7593 is suitable for screens weighing 5 to 8kg
 Fits screens with VESA®mounting patterns:
75 x 75 and 100 x 100mm
 Allows 360° rotation of screen in any direction
to display screen in landscape or portrait style
 Tilts +/-100°
 Mounts screen up to 1650mm from wall
 Supplied with optional handle for easy screen positioning
Full Motion
ArticulatingWall Arm
Medical Mount
23"58cm
VESA
100
BT7592
3-5kg
BT7593
5-8kg
100˚
100˚ 360˚
BT7592
BT7593
ArticulatingWall Arm
Portrait Mounting BT8320
Flat ScreenWall Mount
for Portrait Digital Signage Displays
 Designed for screens
up to 55”(140cm) / 70kg
 Maximum distance between fixings:
H: 410mm x V: 755mm
 Fits VESA® fixings up to 600 x 400mm
 Can also be fitted in landscape style
 Mounts screens just
41mm from the wall
 Simple ‘hook-on’ installation with
all mounting hardware included
BT8010
Flat ScreenWall Mounting Unit
for Large Screens
 Designed for screens
up to 50”(127cm) / 70kg
 Fits screens with mounting patterns
up toH: 755 xV: 410mm
including screens using
VESA® fixings up to 600 x 400mm
 Features integrated
cable management
 Contemporary Graphite Black finish
 AV Component glass shelf available
separately(BT7165 - see below)
 Glass shelf designed for AV equipment
up to 7.5kg
 Shelf dimensions:
450mm x 320mm
*Picture shows 2 shelves mounted
to a BT8010 (available separately)
BT7165 AV Component Shelf
For use with BT8010
RegisteredDesignNumber:001713280-0049
VESA
600
x
400
50"
127cm
Wall Mounting Unit
70kg
7.5kg
VESA
600
x
400
70kg 55"
140cm x2
Digital SignageWall Mounts
SinglePole
x4
DoublePoles
