For More Information Visit B-TECH PROFESSIONAL 45
Specialist PoleMounts & Accessories 50mmPole
MountingSystem
BT7012 Purlin Mount
Purlin Mount
for ø50mm Poles
 Adjustable purlin mount for use with
50mm poles
 Cable management
 Supplied with safety bolt for secure installation
 Locking bolt included to securely set the pole
vertical at any angle up to 45°
 Fits “Cee” and “Zee” section purlin
with a minimum height of 95mm (3.7”)
 Can also be mounted to beams and girders
 Pole sold separately 140kg
BT7014 Joist Mount
 Designed to be mounted to the
side / underside of a beam / joist
 Supplied with safety bolt for
secure installation
 Can be bolted through a joist
using supplied back plates
 Screws / bolts not included
 Pole sold separately
BT7014
BT7850
Joist Mount
for ø50mm Poles
100kg
BT7825 Truss Clamp
 Adjustable adaptor for attaching
50mm poles to truss systems,
scaffolding and other horizontal poles
 Cable management
 Supplied with safety bolt for
secure installation
 Fits truss size from 42mm (1.7”) - 50mm (2”)
 Zinc plated clamp
 Pole sold separately
Truss Mount
for ø50mm Poles
140kg
BT7017 I-Beam (Girder) Mount
 Adjustable I-Beam (girder) mount
for use with 50mm poles
 Cable management
 Supplied with safety bolt for secure
installation
 Locking bolt included to securely set
the pole vertical at any angle up to 40°
 Fits I-Beams and thick steel from
80mm (3.1”) - 250mm (9.8”) in width
 Pole sold separately
I-Beam Girder Mount
for ø50mm Poles
40˚
40˚ 140kg
Swivel Adaptor BT7852
 Allows a screen or AV
equipment mounted
at the bottom of a pole
to be swivelled 360˚
 Pole sold separately
Swivel Adaptor
for ø50mm Poles
360˚
70kg
BT7055 Pole Finishing Ring
 Escutcheon ring designed to
improve the look of a ceiling
mounted pole
 Ideal for use with
suspended ceilings
 Pole sold separately
Ceiling Finishing Ring
for ø50mm Poles
BT7056 Floor Fixing Kit
 Allows poles to be fixed to the
floor to prevent lateral movement
in a floor to ceiling installation
 Suitable for most floor types
including concrete and
wooden floors
 Chrome cover for a smart installation
 For alternative colours add BT7055
Floor Fixing Kit for
50mm Poles
Pole Joiners
 Joins 2 x 50mm
poles together
 Still allows cables
to pass through cables
 Hidden from view
once installed
 Pole sold separately
 Joins 2 x 50mm
poles together
 Still allows cables to
pass through poles
 Allows cable
access mid-pole
 Pole sold separately
Internal
Pole Joiner
External
Pole Joiner
BT7823 BT7824
