47 / 72
For More Information Visit
www.btechavmounts.comB-TECH
PROFESSIONAL
47
Projector, CCTV & AV Player Mounts
50mmPole
MountingSystem
BT7819888
Universal Projector Mount
Pole Mounted
Universal mount to fit
LCD / DLP projectors
Unique carousel mount for
simple installation with all
mounting hardware included
Maximum distance between any
2 fixing points: 340mm (13.4”)
Distance from top of collar
to projector: 195mm (7.6”)
Maximum tilt and swivel at ball
joint bracket: 37° in any direction
37˚
37˚
360˚
15kg
BT899
Heavy Duty Projector Mount
Pole Mounted with
Micro-Adjustment
Designed for projectors
up to 25kg (55lbs)
Compatible with the B-Tech
System 2
™
Professional Range
and NPT pipe systems
Features +/-13° tilt, +/-6° roll
and 360° swivel
Maximum distance between any
two fixing points: 370mm (14.6”)
Pole sold separately
RegisteredDesignNumber:001713306-0004
6˚
6˚
13˚
13˚
360°
25kg
BT899-XL
Extra Large Pole Mounted Projector
Ceiling Mount with Micro Adjustment
Same as BT899 but features
increased maximum fixing
dimensions
Maximum distance between any
two fixing points: 493mm (19.4”)
Pole sold separately
RegisteredDesignNumber:001713306-0004
6˚
6˚
13˚
13˚
360°
25kg
Extra-Large Projector Mount
Apple TV
*
Mount
Designed to mount an
Apple TV player to your
wall or to a pole
Features +/-90° tilt
and 75° swivel
Open design for greater airflow
to keep the device cool
Features security locking bar
and screws to help
prevent unauthorised
removal of the device
Compatible with single
collars
(sold separately)
Apple TV
*
Mount
Digital Signage Box Cradle
Cradle designed to mount
a digital signage player to a
BT7522, BT8431 and BT8432
Max load 1kg
Open design for greater
airflow to keep the player cool
Security screws help
prevent unauthorised
removal of the player
Made to order based on the
dimensions of your device,
please ask for details
1kg
Digital Signage Cradle
BT6010
Security Camera Mount
Security Dome
Camera mount
Designed for use with CCTV cameras
Distance between any 2 fixing
points on CCTV camera:
Min:
63.5mm (2.4”)
Max:
103.5mm (4.1”)
including VESA® 75 x 75mm
Unique carousel mount for simple
installation with all
mounting hardware included
Maximum weight 25kg (55.1lbs)
Available in Zinc finish
25kg
BT7860
BT7867
*TM and ©2013 Apple Inc. All rights reserved.
90˚
90˚
75˚
