2016 B-Tech Catalogue

76 / 100

50mmPole
Mounting System
For More Information Visit B-TECH PROFESSIONAL 76
50mmPoles & PoleMounts
50mm Diameter Poles
Lengths Available:
BT7850-025 - (0.25m), BT7850-
050 - (0.5m), BT7850-100 - (1m),
BT7850-150 - (1.5m), BT7850-
200 - (2m), *BT7850-300 - (3m)
50mm Diameter Poles
BT7850
BT7808 Tilt
Heavy Duty Ceiling Mount
with Tilt for ø50mm Poles
 Ideal solution to pole mount screens and
projectors to flat or angled ceilings
 Allows poles to be mounted on to walls in
landscape or portrait configurations
 Supplied with safety bolt for a secure install
 +/-90˚ Tilt of pole for angled ceilings
 Max Load: 140kg
 Pole sold separately
90˚
90˚
140kg
BT7807 Fixed Twin
BT7851 Adjustable Drop
 Ceiling drop: 600mm - 1000mm
in 25mm increments
 Ceiling plate diameter: 150mm
 Cover plate included for smart installation
 Cable management
 Longer drop available using
BT7823 Pole Joiner and any BT7850-Pole
Telescopic Ceiling Mount
For ø50mm Poles
RegisteredDesignNumber: 403650
90kg
BT7803 Wall Armwith Swivel
Wall Arm
for ø50mm Poles
 Single arm for 180˚ swivel
 Cover plate included for
smart installation
 Supplied with safety bolt for
secure installation
 Arm length: 535mm
 Pole sold separately
70kg
180˚
BT7822 Fixed
150kg
 Available in black, silver or chrome
*Please note 3mmodel is not
available in silver
 Can be cut to length if required
 Poles are internally unobstructed
to allow cables to pass through easily
 Features safety bolt holes at top
and bottom for secure installation
 Poles can be linked together using
BT7823 or BT7824 Joiners
 Includes BT7057 pole ring
90˚
200kg
Heavy Duty Ceiling / Floor
Mount for ø50mm Poles
 Can be used to mount poles to the ceiling
or to the floor
 Heavy Duty steel capable of supporting
substantial loads
 Cover plate included for smart installation
 Includes grub screws which allow
micro-adjustment of pole angle
 Supplied with safety bolt for a secure install
 Ceiling plate diameter: 150mm
 Ceiling drop: 141mm
 Pole sold separately
HeavyDutyTwinFloor/CeilingMountforø50mmPoles
BT7831 Wall Mounting
Wall Mounting Bracket
for ø50mm Poles
 Allows poles to be mounted vertically on to walls
 Ideal for use with B-Tech ceiling / floor mounts to create ceiling-to-wall
or floor-to-wall installations
 Heavy duty steel capable of supporting substantial loads
 Supplied with safety bolt for secure installation
150kg
*max loadcan be increasedwhenbeingusedaspartofafloor toceiling installation
*max loadcan be increasedwhenbeingusedaspartofafloor toceiling installation
 Can be used to mount poles to the
ceiling or to the floor
 Heavy Duty steel capable of
supporting substantial loads
 Includes grub screws which allow
micro-adjustment of pole angle
 Speeds up twin pole installations by eliminating
need to measure distance between pole centres
 Supplied with safety bolt for a secure install
 Plate dimensions: 426mm x 150mm
 Elavation / ceiling drop: 141mm
 Pole sold separately
RegisteredDesignNumber:002741256-0008 RegisteredDesignNumber:002741256-0009
RegisteredDesignNumber:002741256-0010
RegisteredDesignNumber:002741256-0012
NEW
Product NEW
Product
NEW
Product
Updated
Product
