50mmPole

Mounting System

For More Information Visit

www.btechavmounts.com

B-TECH

PROFESSIONAL

79

Projector, CCTV & AV Player Mounts

BT7819-888

Pole Mounted

Universal mount to fit

projectors up to 15kg

Unique carousel mount for

simple installation with all

mounting hardware included

Maximum distance between any

2 fixing points: 340mm

Distance from top of collar

to projector: 195mm

Maximum tilt and swivel at ball

joint bracket: 37° in any direction

37˚

37˚

360˚

15kg

BT899

Heavy Duty Projector Mount

Pole Mounted with

Micro-Adjustment

Designed for projectors

up to 25kg

Compatible with the B-Tech

System 2

Professional Range

and NPT pipe systems

Features +/-13° tilt, +/-6° roll

and 360° swivel

Maximum distance between any

two fixing points: 370mm

Pole sold separately

RegisteredDesignNumber:001713306-0004

13˚

13˚

360°

25kg

BT899-XL

Extra Large Pole Mounted Projector

Ceiling Mount with Micro Adjustment

Same as BT899 but features

increased maximum fixing

dimensions

Maximum distance between any

two fixing points: 493mm

Pole sold separately

RegisteredDesignNumber:001713306-0004

13˚

13˚

360°

25kg

Extra-Large Projector Mount

Apple TV

*

Mount

Designed to mount an

Apple TV player to your

wall or to a pole

Features +/-90° tilt

and 75° swivel

Open design for greater airflow

to keep the device cool

Features security locking bar

and screws to help

prevent unauthorised

removal of the device

Compatible with single

collars

(sold separately)

Apple TV

*

Mount

Digital Signage Box Cradle

Cradle designed to mount

a digital signage player to a

BT7522, BT8431 and BT8432

Max load 1kg

Open design for greater

airflow to keep the player cool

Security screws help

prevent unauthorised

removal of the player

Made to order based on the

dimensions of your device,

please ask for details

1kg

Digital Signage Cradle

BT6010

Security Camera Mount

Security Dome

Camera Mount

Designed for use with CCTV cameras

Distance between any 2 fixing

points on CCTV camera:

Min:

63.5mm

Max:

103.5mm

including VESA® 75 x 75mm

Unique carousel mount for simple

installation with all

mounting hardware included

Maximum weight 25kg

Available in Zinc finish

25kg

BT7860

BT7867

*TM and ©2013 Apple Inc. All rights reserved.

90˚

90˚

75˚

Universal

Projector Mount

Updated

Product
