Digital Signage
Mounting
VideoWall Mount Spacers
Mounting with Spacers - Landscape
Wall plate spacers are available for the
BT8310
and
BT8311
that eliminate tedious alignment
calculations, meaning less time is wasted throughmeasuring and‘guesswork’. These spacers
are available to order separately and are screen specific for all popular brands.
To find out
which spacer kit is needed for a specific screen please see the table below.
If your screen is not listed in
the table below please go to
www.btechavmounts.com/BT8310or scan the QR code above to view the
most up to date list.
Mounting with Spacers - Portrait
Spacer Kits
Eliminate tedious alignment calculations and guess work
Spacers available for all video wall screen brands
such as LG, Samsung, Sharp, Philips, NEC, and Orion
Only one spacer kit is required per install and can be re-used for multiple installations
See table below to find out which spacer is required for your installation
CustomWall Plate Spacers for BT8310
and BT8311 VideoWall Mount
BT8310-SP
VESA Adaptors and Spacers for BT8310 and BT8311
Screen Brand
Model
Screen Size
Spacer Available
Adaptor Required
LG
42WS50B
42”(961 x 555mm)
BT8310-SP422/N
Not Required
NEC
X461UN
46" (1026 x 580mm)
BT8310-SP461/N
Not Required
NEC
X462UN
46" (1026 x 580mm)
BT8310-SP461/N
Not Required
NEC
X463UN
46" (1026 x 580mm)
BT8310-SP461/N
Not Required
ORION
46RNCS
46" (1026 x 580mm)
BT8310-SP461/N
BT8310-AD64/B
HANTAREX
46-UNB
46" (1026 x 580mm)
BT8310-SP461/N
Contact us for details
PHILIPS
BDL4675XU
46" (1026 x 578mm)
BT8310-SP461/N
Not Required
PHILIPS
BDL4681XU
46" (1026 x 578mm)
BT8310-SP461/N
Not Required
SAMSUNG
460UT-2
46" (1026 x 578mm)
BT8310-SP461/N
BT8310-AD64/B
SAMSUNG
UD46A
46" (1024 x 578mm)
BT8310-SP461/N
BT8310-AD64/B
SAMSUNG
UE46A
46" (1030 x 585mm)
BT8310-SP462/N
Not Required
SAMSUNG
ME46B
46" (1056 x 612mm)
BT8310-SP463/N
Not Required
LG
47WV50
47" (1045 x 590mm)
BT8310-SP471/N
BT8310-AD64/B
LG
47WV30
47" (1047 x 592mm)
BT8310-SP471/N
BT8310-AD86/B
LG
4720C
47" (1080 x 625mm)
BT8310-SP472/N
BT8310-AD64/B
LG
55WV70
55" (1215 x 686mm)
BT8310-SP551/N
BT8310-AD64/B
CHRISTIE
FHD551-X
55" (1215 x 686mm)
BT8310-SP551/N
BT8310-AD64/B
PHILIPS
BDL5585XL
55" (1215 x 686mm)
BT8310-SP551/N
Not Required
NEC
X551UN
55" (1215 x 686mm)
BT8310-SP551/N
Not Required
ORION
55RNCS
55" (1215 x 686mm)
BT8310-SP551/N
BT8310-AD64/B
SAMSUNG
UD55A
55" (1215 x 686mm)
BT8310-SP551/N
BT8310-AD64/B
SAMSUNG
UE55A
55" (1222 x 693mm)
BT8310-SP552/N
Not Required
SAMSUNG
UE55C
55" (1222 x 693mm)
BT8310-SP552/N
Not Required
MITSUBISHI
MDT552S
55" (1248 x 719mm)
BT8310-SP553/N
Not Required
SHARP
PN-V601
60" (1336 x 755mm)
BT8310-SP601/N
Not Required
*
This screen and spacer is not suitable for portrait mounting.
*
*
