Professional VideoWall Mount
BT8311
Using BT8311 together with the BT8310
In order to access all of the adjustment options when wall mounted in configurations with 3 or more rows, it is recommended that the BT8311
is used together with the BT8310. It is recommended that these mounts should be used in alternating rows to ensure easy access during
installation and throughout any future servicing of the screens.
Example Installations
Applications
In addition to wall mounting, the BT8311 is collar compatible, making possible an endless amount of pole mounted configurations
which utilise either horizontal or vertically mounted poles.
NEW
BT8311
BT8311
BT8311
BT8311
2 x 2 Installation
(No BT8310 required)
BT8310 BT8311
BT8311
BT8310 BT8311
BT8311
BT8310 BT8311
BT8311
PUSH
PUSH
PUSH
3 x 3 Installation
(3 BT8310s recommended)
BT8311 BT8310
BT8310 BT8311
BT8311
BT8310 BT8311
BT8311
PUSH
PUSH
BT8311 BT8310
PUSH
PUSH
2 x 5 Installation
(4 BT8310s recommended)
