If you have a bespoke spacer requirement we are also able tomake these to order with noM.O.Q.
Digital Signage
Mounting VideoWall Mount Spacers
Mounting with Spacers - Landscape
Wallplatespacersareavailable forthe BT8310 andBT8311 thateliminatetediousalignment
calculations, meaning less time is wasted throughmeasuring and‘guesswork’.These spacers
are available to order separately and are screen specific for all popular brands. To find out
which spacer kit is needed for a specific screen please see the table below.
If your screen is not listed in
the table below please go to
or scan the QR code above to view the
most up to date list. Mounting with Spacers - Portrait
Spacer Kits
 Eliminate tedious alignment calculations and guess work
 Spacers available for all video wall screen brands
such as LG, Samsung, Sharp, Philips, NEC, and Orion
 Only one spacer kit is required per install and can be re-used for multiple installations
 See table below to find out which spacer is required for your installation
CustomWall Plate Spacers for BT8310
and BT8311 VideoWall Mount
BT8310-SP
* Thisscreenandspacer isnot
suitable forportraitmounting.
Screen Brand Model Screen Size Spacer Available Adaptor Required
LG 42WS50B 42”(961 x 555mm) BT8310-SP422/N Not Required
NEC X464UN-2 46" (1026 x 580mm) BT8310-SP461/N Not Required
PHILIPS BDL4675XU 46" (1026 x 578mm) BT8310-SP461/N Not Required
SAMSUNG UD46D 46”(1022 x 577mm) BT8310-SP461/N BT8310-AD64/B
SAMSUNG UD46C 46" (1024 x 578mm) BT8310-SP461/N BT8310-AD64/B
SAMSUNG UE46C 46" (1030 x 585mm) BT8310-SP462/N Not Required
SAMSUNG UE46D 46”(1031 x 585mm) BT8310-SP462/N Not Required
LG 47WV50 47" (1045 x 590mm) BT8310-SP471/N BT8310-AD64/B
LG 47WV30 47" (1047 x 592mm) BT8310-SP471/N BT8310-AD86/B
LG 47LV35A-5B 47”(1047 x 592mm) BT8310-SP471/N BT8310-AD64/B
PANASONIC TH-47LFV5W 47”(1047 x 592mm) BT8310-SP471/N BT8310-AD64/B
SAMSUNG UD55D 55”(1214 x 684mm) BT8310-SP551/N BT8310-AD64/B
LG 55LV35A-5B 55”(1215 x 686mm) BT8310-SP551/N BT8310-AD64/B
LG 55WV70 55" (1215 x 686mm) BT8310-SP551/N BT8310-AD64/B
CHRISTIE FHD551-X 55" (1215 x 686mm) BT8310-SP551/N BT8310-AD64/B
PHILIPS BDL5585XL 55" (1215 x 686mm) BT8310-SP551/N Not Required
NEC X554UN 55" (1215 x 686mm) BT8310-SP551/N Not Required
SAMSUNG UD55C 55" (1215 x 686mm) BT8310-SP551/N BT8310-AD64/B
SAMSUNG UE55D 55”(1221 x 693mm) BT8310-SP552/N Not Required
MITSUBISHI MDT552S 55" (1248 x 719mm) BT8310-SP553/N Not Required
SHARP PN-V601 60" (1336 x 755mm) BT8310-SP601/N Not Required
* *
This listreflectsthe latestvideowallscreensavailableonthemarket (atthetimeofprinting), foracomplete list, includingoldermodels,pleasesee
Accessories - VESAAdaptors and Spacers for BT8310 and BT8311
