13 / 72
For More Information Visit
www.btechavmounts.comB-TECH
PROFESSIONAL
13
Customise Your Free Standing VideoWall Mount - Ordering Options
Digital Signage
Mounting
FreestandingVideoWall Mount
Floor Base Fixing Kit
BT8350-FBFK
For a totally secure installation our floor base fixing kit
allows your BT8350 to be bolted down to a concrete floor,
preventing the frame from being moved. Using the floor
base fixing kit will also allow you to build taller video walls
without the need to add ballast to support the floor base.
Each kit comes with 4 brackets per base.
Pop-In, Pop-Out Solution
BT8351
For spaces with limited access the
BT8350
can be
ordered with the
BT8310
Pop-In, Pop-Out
Video
Wall Mount
to create a
BT8351
The BT8350 can be ordered with the BT8310 pop-in/pop-
out wall mount to increase accessibility to the screens when
access to the rear of the video wall is limited. The Push to
open / push to close system provides quick and easy service
access and features 8 tool-less micro-adjustment points for
seamless alignment of the wall display.
Hanging Frame
BT8350-HFA
With our hanging frame the BT8350 can be suspended
from a secure ceiling. The frame attaches to the top and
rear of the BT8350 and can hold up to 5 screens per
column, with a maximum weight of 350kg per column.
Castors
BT8350-CW
The BT8350 comes with height adjustable levelling feet
as standard but we also offer options to fit castors as an
alternative if there is a requirement for the video wall to
be mobile once assembled. Several options are available
depending on your requirement and must be specified
at the time of ordering, please speak to your Area Sales
Manager for more information.
Braked castors
feature swivel
in all directions.
BT8350
perscreen
50kg
perscreen
50kg
