*Important: Screen size and weight limit dependant onmount to which the adaptor is attached.
Mounting
Adaptors Flat ScreenVESA® Mounting Adaptors
*
BT7502
 Converts VESA® 75 x 75mm, 100 x 100mm
or 200 x 100mm to VESA® 200 x 200mm
 Can also convert to 200 x 100mm
VESA 200 x 200
RegisteredDesignNumber:001713280-0001
VESA
200
VESA® Adaptor Plate * Universal Flat Screen Adaptor
BT7505 Universal
 Converts VESA® 75 x 75 or 100 x 100mm
to a universal interface with maximum screen fixings
of H:123mm (4.8”) - 570mm (22.4”) x V: 300mm (11.8”)
VESA
400
x
300
VESA® Adaptor Arms
 Converts VESA® 200 x 200mm to VESA®
300 x 200 or 400 x 200mm
 Use two sets to convert to VESA®
300 x 300, 400 x 300 or 400 x 400
RegisteredDesignNumber:001713280-0016
VESA
400
x
200
VESA 400 x 200 BT7540
*
BT7542
 ConvertsVESA® 100 x 100mm toVESA® 200 x 100mmor
convertsVESA® 200 x 100mm toVESA® 200 x 200mm
VESA200
RegisteredDesignNumber: 001713280-0017
VESA 200 x 100
VESA 200 x 200 VESA® Adaptor Arms
VESA® Adaptor Arms
*
*
BT7564 VESA 600 x 400
VESA
600
x
400
 ConvertsVESA® 400 x 400mm toVESA® 600 x 400mm
 Ideal for use with B-Tech video wall mounts, simply
attach to BT8310, BT8311, BT8350 or BT8351 to allow
use with screens with VESA mounting patterns of
600 x 400mm
MountedVertically MountedHorizontally
IDEALFORUSEWITHBT8310,BT8311&BT8350
NEW
