8
Spacers included
for ventilation
and to provide
extra room for
cable inputs
Ultra-Slim design
for a close
to the wall
installation
Designed for medium flat screens
up to 45”(114cm) / 35kg (77lbs)
Fits screens with
mounting patterns up to
H:
240mm (9.6”) x
V:
200mm (7.9”)
including screens using VESA®
fixings up to 200 x 200mm
Ultra-slim design mounts screen
only 14mm (0.6”) from wall
Patent Pending ‘Torsion-Lock’security
BT8200-PRO
Ultra-Slim Universal
Flat ScreenWall Mount
Fixed - Medium
RegisteredDesignNumber:001713280-0037 PatentApplicationNumbers:1013143.1 (UK).11006364.1 (European)
45"
114cm
VESA
200
35kg
Ultra-Slim Universal
Flat ScreenWall Mount
Designed for large flat screens up to
55”(140cm) / 50kg (110lbs)
Fits screens with
mounting patterns up to
H:
440mm (17.4”) x
V:
400mm (15.7”)
including screens using VESA®
fixings up to 400 x 400mm
Ultra-slim design mounts screen
only 14mm (0.6”) from wall
Patent Pending ‘Torsion-Lock’security
Fixed - Large
RegisteredDesignNumber:001713280-0038 PatentApplicationNumbers:1013143.1 (UK).11006364.1 (European)
55"
139cm
VESA
400
50kg
Designed for extra large flat screens
up to 80”(203cm) / 70kg (154lbs)
Fits screens with
mounting patterns up to
H:
840mm (33.2”) x
V:
500mm (19.7”)
including screens using VESA®
fixings up to 800 x 500mm
Ultra-slim design mounts screen
only 14mm (0.6”) from wall
Patent Pending ‘Torsion-Lock’security
Ultra-Slim Universal
Flat ScreenWall Mount
RegisteredDesignNumber:001713280-0018 PatentApplicationNumbers:1013143.1 (UK).11006364.1 (European)
Fixed - X-Large
VESA
800
x
500
80"
203cm
70kg
Fixed - Medium
Universal
Flat ScreenWall Mount
Designed for medium flat screens
up to 55”(140cm) / 35kg (77lbs)
Fits screens with mounting patterns
up to
H:
465mm (18.3”) x
V:
400mm
(15.7”) including screens using
VESA® fixings up to 400 x 400mm
using included extension arms
Mounts screen 30mm (1.2”)
from wall
Locking bar included
for secure installation
*Padlock not included
*
Fixed - X-Large
Universal
Flat ScreenWall Mount
Designed for extra large flat screens
up to 80”(203cm) / 70kg (154lbs)
Fits screens with mounting patterns
up to
H:
825mm (32.5”) x
V:
500mm
(19.7”) including screens using
VESA® fixings up to 800 x 500mm
Mounts screen 30mm (1.2”)
from wall
Locking bar included
for secure installation
*Padlock not included
*
BT9903
Fixed - Heavy Duty
Heavy Duty Universal
Flat ScreenWall Mount
Designed for extraheavy duty flat
screens from 65”upwards
Max weight: 130kg (287lbs)
Fits screens with VESA and
non-VESA® mounting patterns up to
H:
1100mm (43.3”) x
V:
730mm (28.7”)
Mounts screen 30mm (1.2”)
from wall
130kg
Ultra-Slim Features
Unique
‘Torsion-
Lock’
screen locking
mechanism* prevents
unauthorised removal
*PATENT PENDING
UniversalWall Mounts
Universal Flat Screen
Wall Mounts
BT8210-PRO
BT8220-PRO
BT8421-PRO
BT8422-PRO
55"
139cm
35kg
VESA
400
RegisteredDesignNumber:001713280-0033
VESA
800
x
500
80"
203cm
70kg
RegisteredDesignNumber:001713280-0034
