Universal Features
Unique ‘Torsion-Tilt’*
featured on
BT8431 & BT8432
*PATENT PENDING
UniversalWall Mounts Universal Flat Screen
Wall Mounts
Universal Flat ScreenWall MountwithTilt
Tilt - Medium / Large
 Designed for medium/large flats screens up to 55”(140cm) / 35kg (77lbs)
 Simple tilt adjustment +/-18°
 Fits screens with mounting patterns up to H: 465mm (18.3”) x V: 400mm
(15.7”) including screens using VESA® fixings up to 400 x 400mm
 Mounts screen only 80mm (3.1”) from wall
 Unique ‘Torsion-Tilt’mechanism
 Locking bars included for secure installation
 Suitable for concrete / brick or stud walls up to 16”stud walls
 Suitable for pole mounting - see below
RegisteredDesignNumber:001713280-0035 PatentApplicationNumber:817023.5
55"140cm
VESA
400 35kg
18˚
18˚
x2
BT8431-PRO
BT8221 Double Arm - X-Large
Ultra-Slim Double Arm Flat ScreenWall
Mount with Tilt and Swivel
 Designed for large screens up to 65”(165cm) / 36kg (80lbs)
 Fits screens with VESA® and non-VESA® fixings up to 600 x 400mm
 Easy tilt adjustment +/-15˚ (no tools required)
 Distance from wall: Min: 37mm (1.5”) - Max: 560mm (22”)
 Attractive coverplates included to hide fixings
 Integrated cable management and spirit level bubble
 Suitable for concrete / brick or stud walls up to 16”
180˚
VESA
600
x
400
65"165cm 15˚
15˚
36kg
Universal Flat ScreenWall Mount with Tilt
Tilt - X-Large
 Designed for extra large flat screens up to 80”(203cm) / 70kg (154lbs)*
 Simple tilt adjustment +/-15°
 Fits screens with mounting patterns up to H: 825mm (32.5”) x V: 500mm
(19.7”) including screens using VESA® fixings up to 800 x 500mm
 Mounts screen only 80mm (3.1”) from wall
 Unique ‘Torsion-Tilt’mechanism
 Locking bars included for secure installation
 Suitable for concrete / brick or stud walls up to 32”stud walls
 Suitable for pole mounting - see below
RegisteredDesignNumber:001713280-0036 PatentApplicationNumber:817023.5
VESA
800x
500
80"203cm
70kg
15˚
15˚
x2
BT8432-PRO
*
*35kg (77lbs) when pole mounted
Fit BT8431 or BT8432 to
ø50mm or ø60mm poles
BT7841 Collar Mounting
 Allows BT8431 and BT8432 to be mounted
to ø50mm or ø60mm poles
 Use BT7841 for ø50mm poles
 Use BT4041 for ø60mm poles
BT4041
